Product codes & specifications
| Product code | Spec | ||
|---|---|---|---|
| DABX025R-01 | DMIN (mm): 3 | DCON (mm): 2.5 | HF (mm): 1.25 | LF (mm): 40 | RE (mm): 0.1 | Stock: Yes | ||
| DABX025R-02 | DMIN (mm): 3 | DCON (mm): 2.5 | HF (mm): 1.25 | LF (mm): 40 | RE (mm): 0.2 | Sleeve: HBX2516 | Stock: Yes | ||
| DABX025R-04 | DMIN (mm): 3 | DCON (mm): 2.5 | HF (mm): 1.25 | LF (mm): 40 | RE (mm): 0.4 | Sleeve: HBX2516 | Stock: Yes | ||
| DABX035R-01 | DMIN (mm): 4 | DCON (mm): 3.5 | HF (mm): 1.75 | LF (mm): 40 | RE (mm): 0.1 | Sleeve: HBX3516 | Stock: Yes | ||
| DABX035R-02 | DMIN (mm): 4 | DCON (mm): 3.5 | HF (mm): 1.75 | LF (mm): 40 | RE (mm): 0.2 | Sleeve: HBX3516 | Stock: Yes | ||
| DABX035R-04 | DMIN (mm): 4 | DCON (mm): 3.5 | HF (mm): 1.75 | LF (mm): 40 | RE (mm): 0.4 | Sleeve: HBX3516 | Stock: Yes |
Need a different model, or a part not listed here? Send us your parts list →
