• Sumitomo Electric Hardmetal SumiReamer SR Type Extension B12/B13
1 1

Sumitomo Electric Hardmetal SumiReamer SR Type Extension B12/B13

Sumitomo Electric Hardmetal SumiReamer SR Type Extension B12/B13

Extension for the BETA modular system used with SumiReamer SR type heads and shanks.

B12-40-32-045 BD (mm): 32 | DCB: BM-32 | DF (mm): 42 | DCON: BM-40 | LPR (mm): 45 | LBX (mm): 30 | Weight (kg): 0.3
B12-50-40-050 BD (mm): 42 | DCB: BM-40 | DF (mm): 50 | DCON: BM-50 | LPR (mm): 50 | LBX (mm): 35 | Weight (kg): 0.5
B12-63-32-050 BD (mm): 32 | DCB: BM-32 | DF (mm): 63 | DCON: BM-63 | LPR (mm): 50 | LBX (mm): 30 | Weight (kg): 0.9
B12-63-40-055 BD (mm): 42 | DCB: BM-40 | DF (mm): 63 | DCON: BM-63 | LPR (mm): 55 | LBX (mm): 35 | Weight (kg): 1.1
B12-80-40-060 BD (mm): 42 | DCB: BM-40 | DF (mm): 80 | DCON: BM-80 | LPR (mm): 60 | LBX (mm): 35 | Weight (kg): 2.2
B12-80-63-060 BD (mm): 63 | DCB: BM-63 | DF (mm): 80 | DCON: BM-80 | LPR (mm): 60 | LBX (mm): 35 | Weight (kg): 2.4
B12-100-40-060 BD (mm): 42 | DCB: BM-40 | DF (mm): 100 | DCON: BM-100 | LPR (mm): 60 | LBX (mm): 35 | Weight (kg): 3.1
B12-100-63-060 BD (mm): 63 | DCB: BM-63 | DF (mm): 100 | DCON: BM-100 | LPR (mm): 60 | LBX (mm): 35 | Weight (kg): 3.3
B12-100-80-075 BD (mm): 80 | DCB: BM-80 | DF (mm): 100 | DCON: BM-100 | LPR (mm): 75 | LBX (mm): 50 | Weight (kg): 3.5
B13-32-32-035 BD (mm): 32 | DCB: BM-32 | DF (mm): 32 | DCON: BM-32 | LPR (mm): 35 | Weight (kg): 0.2
B13-32-32-070 BD (mm): 32 | DCB: BM-32 | DF (mm): 32 | DCON: BM-32 | LPR (mm): 70 | Weight (kg): 0.4
B13-40-40-045 BD (mm): 42 | DCB: BM-40 | DF (mm): 42 | DCON: BM-40 | LPR (mm): 45 | Weight (kg): 0.4
B13-40-40-070 BD (mm): 42 | DCB: BM-40 | DF (mm): 42 | DCON: BM-40 | LPR (mm): 70 | Weight (kg): 0.7
B13-50-50-065 BD (mm): 50 | DCB: BM-50 | DF (mm): 50 | DCON: BM-50 | LPR (mm): 65 | Weight (kg): 1.0
B13-50-50-100 BD (mm): 50 | DCB: BM-50 | DF (mm): 50 | DCON: BM-50 | LPR (mm): 100 | Weight (kg): 1.5
B13-63-63-060 BD (mm): 63 | DCB: BM-63 | DF (mm): 63 | DCON: BM-63 | LPR (mm): 60 | Weight (kg): 1.3
B13-63-63-125 BD (mm): 63 | DCB: BM-63 | DF (mm): 63 | DCON: BM-63 | LPR (mm): 100 | Weight (kg): 2.9
B13-80-80-080 BD (mm): 80 | DCB: BM-80 | DF (mm): 80 | DCON: BM-80 | LPR (mm): 80 | Weight (kg): 2.9
B13-80-80-160 BD (mm): 80 | DCB: BM-80 | DF (mm): 80 | DCON: BM-80 | LPR (mm): 160 | Weight (kg): 4.9
B13-100-100-080 BD (mm): 100 | DCB: BM-100 | DF (mm): 100 | DCON: BM-100 | LPR (mm): 80 | Weight (kg): 4.9
B13-100-100-180 BD (mm): 100 | DCB: BM-100 | DF (mm): 100 | DCON: BM-100 | LPR (mm): 180 | Weight (kg): 10.9
ReamersSumitomo Electric Hardmetal
21 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Sumitomo Electric Hardmetal SumiReamer SR Type Extension B12/B13

Brand Sumitomo Electric Hardmetal·Reamers

Available part numbers (21)

B12-40-32-045, B12-50-40-050, B12-63-32-050, B12-63-40-055, B12-80-40-060, B12-80-63-060, B12-100-40-060, B12-100-63-060, B12-100-80-075, B13-32-32-035 + 11 more — see full table ↓

How to order

Send the Sumitomo Electric Hardmetal part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
B12-40-32-045BD (mm): 32 | DCB: BM-32 | DF (mm): 42 | DCON: BM-40 | LPR (mm): 45 | LBX (mm): 30 | Weight (kg): 0.3
B12-50-40-050BD (mm): 42 | DCB: BM-40 | DF (mm): 50 | DCON: BM-50 | LPR (mm): 50 | LBX (mm): 35 | Weight (kg): 0.5
B12-63-32-050BD (mm): 32 | DCB: BM-32 | DF (mm): 63 | DCON: BM-63 | LPR (mm): 50 | LBX (mm): 30 | Weight (kg): 0.9
B12-63-40-055BD (mm): 42 | DCB: BM-40 | DF (mm): 63 | DCON: BM-63 | LPR (mm): 55 | LBX (mm): 35 | Weight (kg): 1.1
B12-80-40-060BD (mm): 42 | DCB: BM-40 | DF (mm): 80 | DCON: BM-80 | LPR (mm): 60 | LBX (mm): 35 | Weight (kg): 2.2
B12-80-63-060BD (mm): 63 | DCB: BM-63 | DF (mm): 80 | DCON: BM-80 | LPR (mm): 60 | LBX (mm): 35 | Weight (kg): 2.4
B12-100-40-060BD (mm): 42 | DCB: BM-40 | DF (mm): 100 | DCON: BM-100 | LPR (mm): 60 | LBX (mm): 35 | Weight (kg): 3.1
B12-100-63-060BD (mm): 63 | DCB: BM-63 | DF (mm): 100 | DCON: BM-100 | LPR (mm): 60 | LBX (mm): 35 | Weight (kg): 3.3
B12-100-80-075BD (mm): 80 | DCB: BM-80 | DF (mm): 100 | DCON: BM-100 | LPR (mm): 75 | LBX (mm): 50 | Weight (kg): 3.5
B13-32-32-035BD (mm): 32 | DCB: BM-32 | DF (mm): 32 | DCON: BM-32 | LPR (mm): 35 | Weight (kg): 0.2
B13-32-32-070BD (mm): 32 | DCB: BM-32 | DF (mm): 32 | DCON: BM-32 | LPR (mm): 70 | Weight (kg): 0.4
B13-40-40-045BD (mm): 42 | DCB: BM-40 | DF (mm): 42 | DCON: BM-40 | LPR (mm): 45 | Weight (kg): 0.4
B13-40-40-070BD (mm): 42 | DCB: BM-40 | DF (mm): 42 | DCON: BM-40 | LPR (mm): 70 | Weight (kg): 0.7
B13-50-50-065BD (mm): 50 | DCB: BM-50 | DF (mm): 50 | DCON: BM-50 | LPR (mm): 65 | Weight (kg): 1.0
B13-50-50-100BD (mm): 50 | DCB: BM-50 | DF (mm): 50 | DCON: BM-50 | LPR (mm): 100 | Weight (kg): 1.5
B13-63-63-060BD (mm): 63 | DCB: BM-63 | DF (mm): 63 | DCON: BM-63 | LPR (mm): 60 | Weight (kg): 1.3
B13-63-63-125BD (mm): 63 | DCB: BM-63 | DF (mm): 63 | DCON: BM-63 | LPR (mm): 100 | Weight (kg): 2.9
B13-80-80-080BD (mm): 80 | DCB: BM-80 | DF (mm): 80 | DCON: BM-80 | LPR (mm): 80 | Weight (kg): 2.9
B13-80-80-160BD (mm): 80 | DCB: BM-80 | DF (mm): 80 | DCON: BM-80 | LPR (mm): 160 | Weight (kg): 4.9
B13-100-100-080BD (mm): 100 | DCB: BM-100 | DF (mm): 100 | DCON: BM-100 | LPR (mm): 80 | Weight (kg): 4.9
B13-100-100-180BD (mm): 100 | DCB: BM-100 | DF (mm): 100 | DCON: BM-100 | LPR (mm): 180 | Weight (kg): 10.9
