• Sumitomo Electric Hardmetal Super Multi Drill PHT Type Pilot Drill (Internal Coolant)
1 1

Sumitomo Electric Hardmetal Super Multi Drill PHT Type Pilot Drill (Internal Coolant)

Sumitomo Electric Hardmetal Super Multi Drill PHT Type Pilot Drill (Internal Coolant)

Solid carbide pilot drill for preparing guide holes before deep-hole drilling with the XHGS type.

Key features

  • Dedicated guide-hole drill for XHGS
  • 150 deg point angle
  • Grade ACX20

Specifications

Coolant Internal
Grade ACX20
MDW0210PHT DC (mm): 2.1 | L/D: 3 | LU (mm): 12.2 | LCF (mm): 15.3 | OAL (mm): 68.3 | PL (mm): 0.3 | DCON (mm): 3.0 | Stock: Yes
MDW0220PHT DC (mm): 2.2 | L/D: 3 | LU (mm): 12.0 | LCF (mm): 15.3 | OAL (mm): 68.3 | PL (mm): 0.3 | DCON (mm): 3.0 | Stock: Yes
MDW0230PHT DC (mm): 2.3 | L/D: 3 | LU (mm): 11.9 | LCF (mm): 15.3 | OAL (mm): 68.3 | PL (mm): 0.3 | DCON (mm): 3.0 | Stock: Yes
MDW0240PHT DC (mm): 2.4 | L/D: 3 | LU (mm): 11.7 | LCF (mm): 15.3 | OAL (mm): 68.3 | PL (mm): 0.3 | DCON (mm): 3.0 | Stock: Yes
MDW0250PHT DC (mm): 2.5 | L/D: 3 | LU (mm): 11.6 | LCF (mm): 15.3 | OAL (mm): 68.3 | PL (mm): 0.3 | DCON (mm): 3.0 | Stock: Yes
MDW0260PHT DC (mm): 2.6 | L/D: 3 | LU (mm): 13.9 | LCF (mm): 17.8 | OAL (mm): 68.3 | PL (mm): 0.3 | DCON (mm): 3.0 | Stock: Yes
MDW0270PHT DC (mm): 2.7 | L/D: 3 | LU (mm): 13.9 | LCF (mm): 17.9 | OAL (mm): 68.4 | PL (mm): 0.4 | DCON (mm): 3.0 | Stock: Yes
MDW0280PHT DC (mm): 2.8 | L/D: 3 | LU (mm): 13.7 | LCF (mm): 17.9 | OAL (mm): 68.4 | PL (mm): 0.4 | DCON (mm): 3.0 | Stock: Yes
MDW0290PHT DC (mm): 2.9 | L/D: 3 | LU (mm): 13.6 | LCF (mm): 17.9 | OAL (mm): 68.4 | PL (mm): 0.4 | DCON (mm): 3.0 | Stock: Yes
MDW0300PHT DC (mm): 3.0 | L/D: 3 | LU (mm): 13.4 | LCF (mm): 17.9 | OAL (mm): 68.4 | PL (mm): 0.4 | DCON (mm): 3.0 | Stock: Yes
MDW0310PHT DC (mm): 3.1 | L/D: 3 | LU (mm): 15.8 | LCF (mm): 20.4 | OAL (mm): 72.4 | PL (mm): 0.4 | DCON (mm): 4.0 | Stock: Yes
MDW0320PHT DC (mm): 3.2 | L/D: 3 | LU (mm): 15.6 | LCF (mm): 20.4 | OAL (mm): 72.4 | PL (mm): 0.4 | DCON (mm): 4.0 | Stock: Yes
MDW0330PHT DC (mm): 3.3 | L/D: 3 | LU (mm): 15.5 | LCF (mm): 20.4 | OAL (mm): 72.4 | PL (mm): 0.4 | DCON (mm): 4.0 | Stock: Yes
MDW0340PHT DC (mm): 3.4 | L/D: 3 | LU (mm): 15.4 | LCF (mm): 20.5 | OAL (mm): 72.5 | PL (mm): 0.5 | DCON (mm): 4.0 | Stock: Yes
MDW0350PHT DC (mm): 3.5 | L/D: 3 | LU (mm): 15.3 | LCF (mm): 20.5 | OAL (mm): 72.5 | PL (mm): 0.5 | DCON (mm): 4.0 | Stock: Yes
MDW0360PHT DC (mm): 3.6 | L/D: 3 | LU (mm): 17.6 | LCF (mm): 23.0 | OAL (mm): 72.5 | PL (mm): 0.5 | DCON (mm): 4.0 | Stock: Yes
MDW0370PHT DC (mm): 3.7 | L/D: 3 | LU (mm): 17.5 | LCF (mm): 23.0 | OAL (mm): 72.5 | PL (mm): 0.5 | DCON (mm): 4.0 | Stock: Yes
MDW0380PHT DC (mm): 3.8 | L/D: 3 | LU (mm): 17.3 | LCF (mm): 23.0 | OAL (mm): 72.5 | PL (mm): 0.5 | DCON (mm): 4.0 | Stock: Yes
MDW0390PHT DC (mm): 3.9 | L/D: 3 | LU (mm): 17.2 | LCF (mm): 23.0 | OAL (mm): 72.5 | PL (mm): 0.5 | DCON (mm): 4.0 | Stock: Yes
MDW0400PHT DC (mm): 4.0 | L/D: 3 | LU (mm): 17.0 | LCF (mm): 23.0 | OAL (mm): 72.5 | PL (mm): 0.5 | DCON (mm): 4.0 | Stock: Yes
MDW0410PHT DC (mm): 4.1 | L/D: 3 | LU (mm): 19.4 | LCF (mm): 25.5 | OAL (mm): 80.5 | PL (mm): 0.5 | DCON (mm): 5.0 | Stock: Yes
MDW0420PHT DC (mm): 4.2 | L/D: 3 | LU (mm): 19.3 | LCF (mm): 25.6 | OAL (mm): 80.6 | PL (mm): 0.6 | DCON (mm): 5.0 | Stock: Yes
MDW0430PHT DC (mm): 4.3 | L/D: 3 | LU (mm): 19.2 | LCF (mm): 25.6 | OAL (mm): 80.6 | PL (mm): 0.6 | DCON (mm): 5.0 | Stock: Yes
MDW0440PHT DC (mm): 4.4 | L/D: 3 | LU (mm): 19.0 | LCF (mm): 25.6 | OAL (mm): 80.6 | PL (mm): 0.6 | DCON (mm): 5.0 | Stock: Yes
MDW0450PHT DC (mm): 4.5 | L/D: 3 | LU (mm): 18.9 | LCF (mm): 25.6 | OAL (mm): 80.6 | PL (mm): 0.6 | DCON (mm): 5.0 | Stock: Yes
MDW0460PHT DC (mm): 4.6 | L/D: 3 | LU (mm): 21.2 | LCF (mm): 28.1 | OAL (mm): 80.6 | PL (mm): 0.6 | DCON (mm): 5.0 | Stock: Yes
MDW0470PHT DC (mm): 4.7 | L/D: 3 | LU (mm): 21.1 | LCF (mm): 28.1 | OAL (mm): 80.6 | PL (mm): 0.6 | DCON (mm): 5.0 | Stock: Yes
MDW0480PHT DC (mm): 4.8 | L/D: 3 | LU (mm): 20.9 | LCF (mm): 28.1 | OAL (mm): 80.6 | PL (mm): 0.6 | DCON (mm): 5.0 | Stock: Yes
MDW0490PHT DC (mm): 4.9 | L/D: 3 | LU (mm): 20.9 | LCF (mm): 28.2 | OAL (mm): 80.7 | PL (mm): 0.7 | DCON (mm): 5.0 | Stock: Yes
MDW0500PHT DC (mm): 5.0 | L/D: 3 | LU (mm): 20.7 | LCF (mm): 28.2 | OAL (mm): 80.7 | PL (mm): 0.7 | DCON (mm): 5.0 | Stock: Yes
MDW0510PHT DC (mm): 5.1 | L/D: 3 | LU (mm): 20.6 | LCF (mm): 28.2 | OAL (mm): 82.7 | PL (mm): 0.7 | DCON (mm): 6.0 | Stock: Yes
MDW0520PHT DC (mm): 5.2 | L/D: 3 | LU (mm): 20.4 | LCF (mm): 28.2 | OAL (mm): 82.7 | PL (mm): 0.7 | DCON (mm): 6.0 | Stock: Yes
MDW0530PHT DC (mm): 5.3 | L/D: 3 | LU (mm): 20.3 | LCF (mm): 28.2 | OAL (mm): 82.7 | PL (mm): 0.7 | DCON (mm): 6.0 | Stock: Yes
MDW0540PHT DC (mm): 5.4 | L/D: 3 | LU (mm): 20.1 | LCF (mm): 28.2 | OAL (mm): 82.7 | PL (mm): 0.7 | DCON (mm): 6.0 | Stock: Yes
MDW0550PHT DC (mm): 5.5 | L/D: 3 | LU (mm): 20.0 | LCF (mm): 28.2 | OAL (mm): 82.7 | PL (mm): 0.7 | DCON (mm): 6.0 | Stock: Yes
MDW0560PHT DC (mm): 5.6 | L/D: 3 | LU (mm): 22.4 | LCF (mm): 30.8 | OAL (mm): 82.8 | PL (mm): 0.8 | DCON (mm): 6.0 | Stock: Yes
MDW0570PHT DC (mm): 5.7 | L/D: 3 | LU (mm): 22.3 | LCF (mm): 30.8 | OAL (mm): 82.8 | PL (mm): 0.8 | DCON (mm): 6.0 | Stock: Yes
MDW0580PHT DC (mm): 5.8 | L/D: 3 | LU (mm): 22.1 | LCF (mm): 30.8 | OAL (mm): 82.8 | PL (mm): 0.8 | DCON (mm): 6.0 | Stock: Yes
MDW0590PHT DC (mm): 5.9 | L/D: 3 | LU (mm): 22.0 | LCF (mm): 30.8 | OAL (mm): 82.8 | PL (mm): 0.8 | DCON (mm): 6.0 | Stock: Yes
MDW0600PHT DC (mm): 6.0 | L/D: 3 | LU (mm): 21.8 | LCF (mm): 30.8 | OAL (mm): 82.8 | PL (mm): 0.8 | DCON (mm): 6.0 | Stock: Yes
MDW0610PHT DC (mm): 6.1 | L/D: 3 | LU (mm): 24.2 | LCF (mm): 33.3 | OAL (mm): 88.8 | PL (mm): 0.8 | DCON (mm): 7.0 | Stock: Yes
MDW0620PHT DC (mm): 6.2 | L/D: 3 | LU (mm): 24.0 | LCF (mm): 33.3 | OAL (mm): 88.8 | PL (mm): 0.8 | DCON (mm): 7.0 | Stock: Yes
MDW0630PHT DC (mm): 6.3 | L/D: 3 | LU (mm): 23.9 | LCF (mm): 33.3 | OAL (mm): 88.8 | PL (mm): 0.8 | DCON (mm): 7.0 | Stock: Yes
MDW0640PHT DC (mm): 6.4 | L/D: 3 | LU (mm): 23.8 | LCF (mm): 33.4 | OAL (mm): 88.9 | PL (mm): 0.9 | DCON (mm): 7.0 | Stock: Yes
MDW0650PHT DC (mm): 6.5 | L/D: 3 | LU (mm): 23.7 | LCF (mm): 33.4 | OAL (mm): 88.9 | PL (mm): 0.9 | DCON (mm): 7.0 | Stock: Yes
MDW0660PHT DC (mm): 6.6 | L/D: 3 | LU (mm): 26.0 | LCF (mm): 35.9 | OAL (mm): 88.9 | PL (mm): 0.9 | DCON (mm): 7.0 | Stock: Yes
MDW0670PHT DC (mm): 6.7 | L/D: 3 | LU (mm): 25.9 | LCF (mm): 35.9 | OAL (mm): 88.9 | PL (mm): 0.9 | DCON (mm): 7.0 | Stock: Yes
MDW0680PHT DC (mm): 6.8 | L/D: 3 | LU (mm): 25.7 | LCF (mm): 35.9 | OAL (mm): 88.9 | PL (mm): 0.9 | DCON (mm): 7.0 | Stock: Yes
MDW0690PHT DC (mm): 6.9 | L/D: 3 | LU (mm): 25.6 | LCF (mm): 35.9 | OAL (mm): 88.9 | PL (mm): 0.9 | DCON (mm): 7.0 | Stock: Yes
MDW0700PHT DC (mm): 7.0 | L/D: 3 | LU (mm): 25.4 | LCF (mm): 35.9 | OAL (mm): 88.9 | PL (mm): 0.9 | DCON (mm): 7.0 | Stock: Yes
MDW0710PHT DC (mm): 7.1 | L/D: 3 | LU (mm): 27.9 | LCF (mm): 38.5 | OAL (mm): 95.0 | PL (mm): 1.0 | DCON (mm): 8.0 | Stock: Yes
MDW0720PHT DC (mm): 7.2 | L/D: 3 | LU (mm): 27.7 | LCF (mm): 38.5 | OAL (mm): 95.0 | PL (mm): 1.0 | DCON (mm): 8.0 | Stock: Yes
MDW0730PHT DC (mm): 7.3 | L/D: 3 | LU (mm): 27.6 | LCF (mm): 38.5 | OAL (mm): 95.0 | PL (mm): 1.0 | DCON (mm): 8.0 | Stock: Yes
MDW0740PHT DC (mm): 7.4 | L/D: 3 | LU (mm): 27.4 | LCF (mm): 38.5 | OAL (mm): 95.0 | PL (mm): 1.0 | DCON (mm): 8.0 | Stock: Yes
MDW0750PHT DC (mm): 7.5 | L/D: 3 | LU (mm): 27.3 | LCF (mm): 38.5 | OAL (mm): 95.0 | PL (mm): 1.0 | DCON (mm): 8.0 | Stock: Yes
MDW0760PHT DC (mm): 7.6 | L/D: 3 | LU (mm): 29.6 | LCF (mm): 41.0 | OAL (mm): 95.0 | PL (mm): 1.0 | DCON (mm): 8.0 | Stock: Yes
MDW0770PHT DC (mm): 7.7 | L/D: 3 | LU (mm): 29.5 | LCF (mm): 41.0 | OAL (mm): 95.0 | PL (mm): 1.0 | DCON (mm): 8.0 | Stock: Yes
MDW0780PHT DC (mm): 7.8 | L/D: 3 | LU (mm): 29.3 | LCF (mm): 41.0 | OAL (mm): 95.0 | PL (mm): 1.0 | DCON (mm): 8.0 | Stock: Yes
MDW0790PHT DC (mm): 7.9 | L/D: 3 | LU (mm): 29.3 | LCF (mm): 41.1 | OAL (mm): 95.1 | PL (mm): 1.1 | DCON (mm): 8.0 | Stock: Yes
MDW0800PHT DC (mm): 8.0 | L/D: 3 | LU (mm): 29.1 | LCF (mm): 41.1 | OAL (mm): 95.1 | PL (mm): 1.1 | DCON (mm): 8.0 | Stock: Yes
MDW0850PHT DC (mm): 8.5 | L/D: 3 | LU (mm): 30.9 | LCF (mm): 43.6 | OAL (mm): 101.1 | PL (mm): 1.1 | DCON (mm): 9.0 | Stock: Yes
MDW0900PHT DC (mm): 9.0 | L/D: 3 | LU (mm): 32.7 | LCF (mm): 46.2 | OAL (mm): 101.2 | PL (mm): 1.2 | DCON (mm): 9.0 | Stock: Yes
MDW0950PHT DC (mm): 9.5 | L/D: 3 | LU (mm): 34.6 | LCF (mm): 48.8 | OAL (mm): 107.3 | PL (mm): 1.3 | DCON (mm): 10.0 | Stock: Yes
MDW1000PHT DC (mm): 10.0 | L/D: 3 | LU (mm): 36.3 | LCF (mm): 51.3 | OAL (mm): 107.3 | PL (mm): 1.3 | DCON (mm): 10.0 | Stock: Yes
MDW1050PHT DC (mm): 10.5 | L/D: 3 | LU (mm): 38.2 | LCF (mm): 53.9 | OAL (mm): 117.4 | PL (mm): 1.4 | DCON (mm): 11.0 | Stock: Yes
MDW1100PHT DC (mm): 11.0 | L/D: 3 | LU (mm): 40.0 | LCF (mm): 56.5 | OAL (mm): 117.5 | PL (mm): 1.5 | DCON (mm): 11.0 | Stock: Yes
MDW1150PHT DC (mm): 11.5 | L/D: 3 | LU (mm): 41.8 | LCF (mm): 59.0 | OAL (mm): 123.5 | PL (mm): 1.5 | DCON (mm): 12.0 | Stock: Yes
MDW1200PHT DC (mm): 12.0 | L/D: 3 | LU (mm): 43.6 | LCF (mm): 61.6 | OAL (mm): 123.6 | PL (mm): 1.6 | DCON (mm): 12.0 | Stock: Yes
MDW1250PHT DC (mm): 12.5 | L/D: 3 | LU (mm): 45.5 | LCF (mm): 64.2 | OAL (mm): 129.7 | PL (mm): 1.7 | DCON (mm): 13.0 | Stock: Yes
MDW1300PHT DC (mm): 13.0 | L/D: 3 | LU (mm): 47.2 | LCF (mm): 66.7 | OAL (mm): 129.7 | PL (mm): 1.7 | DCON (mm): 13.0 | Stock: Yes
MDW1350PHT DC (mm): 13.5 | L/D: 3 | LU (mm): 49.1 | LCF (mm): 69.3 | OAL (mm): 135.8 | PL (mm): 1.8 | DCON (mm): 14.0 | Stock: Yes
MDW1400PHT DC (mm): 14.0 | L/D: 3 | LU (mm): 50.9 | LCF (mm): 71.9 | OAL (mm): 135.9 | PL (mm): 1.9 | DCON (mm): 14.0 | Stock: Yes
MDW1450PHT DC (mm): 14.5 | L/D: 3 | LU (mm): 52.7 | LCF (mm): 74.4 | OAL (mm): 141.9 | PL (mm): 1.9 | DCON (mm): 15.0 | Stock: Yes
MDW1500PHT DC (mm): 15.0 | L/D: 3 | LU (mm): 54.5 | LCF (mm): 77.0 | OAL (mm): 142.0 | PL (mm): 2.0 | DCON (mm): 15.0 | Stock: Yes
MDW1550PHT DC (mm): 15.5 | L/D: 3 | LU (mm): 56.4 | LCF (mm): 79.6 | OAL (mm): 148.1 | PL (mm): 2.1 | DCON (mm): 16.0 | Stock: Yes
MDW1600PHT DC (mm): 16.0 | L/D: 3 | LU (mm): 58.1 | LCF (mm): 82.1 | OAL (mm): 148.1 | PL (mm): 2.1 | DCON (mm): 16.0 | Stock: Yes
DrillsSumitomo Electric Hardmetal
76 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Sumitomo Electric Hardmetal Super Multi Drill PHT Type Pilot Drill (Internal Coolant)

Brand Sumitomo Electric Hardmetal·Drills

Available part numbers (76)

MDW0210PHT, MDW0220PHT, MDW0230PHT, MDW0240PHT, MDW0250PHT, MDW0260PHT, MDW0270PHT, MDW0280PHT, MDW0290PHT, MDW0300PHT + 66 more — see full table ↓

How to order

Send the Sumitomo Electric Hardmetal part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.
