Round flange-type supported-side ball screw support unit with a deep-groove ball bearing and snap ring; pairs with FK fixed-side units.

Key features

  • Deep-groove ball bearing with snap ring
  • Pairs with FK fixed-side units
  • Round flange housing
  • Black oxide standard finish

Specifications

Series FF
Position round flange, supported side
Shaft d1 6-40 mm
Housing finish Black oxide (standard); RA Raydent option
Bearing Deep-groove ball bearing + snap ring
Grease options Standard, LG2 AG, AFE-CA AE, AFF AF, HT-Z1 AH, NBU-15 AN, XL-600 AX
Source SUNGIL Catalogue (EN), Support Unit section
FF-6 Shaft d1: 6 mm | Screw OD: 8 mm | Bearing: 606ZZ | Snap ring: C6 | Mass: 30 g
FF-8 Shaft d1: 6 mm | Screw OD: 10-12 mm | Bearing: 606ZZ | Snap ring: C6 | Mass: 30 g
FF-10 Shaft d1: 8 mm | Screw OD: 10-15 mm | Bearing: 608ZZ | Snap ring: C8 | Mass: 60 g
FF-12 Shaft d1: 10 mm | Screw OD: 14-18 mm | Bearing: 6000ZZ | Snap ring: C10 | Mass: 100 g
FF-15 Shaft d1: 15 mm | Screw OD: 20 mm | Bearing: 6002ZZ | Snap ring: C15 | Mass: 140 g
FF-17 Shaft d1: 17 mm | Screw OD: 25-28 mm | Bearing: 6203ZZ | Snap ring: C17 | Mass: 290 g
FF-20 Shaft d1: 20 mm | Screw OD: 25-28 mm | Bearing: 6204ZZ | Snap ring: C20 | Mass: 380 g
FF-25 Shaft d1: 25 mm | Screw OD: 30-36 mm | Bearing: 6205ZZ | Snap ring: C25 | Mass: 590 g
FF-30 Shaft d1: 30 mm | Screw OD: 40 mm | Bearing: 6206ZZ | Snap ring: C30 | Mass: 930 g
FF-25D Shaft d1: 25 mm | Bearing: 6205ZZ | Snap ring: C25 | Mass: 1,400 g
FF-30D Shaft d1: 30 mm | Bearing: 6206ZZ | Snap ring: C30 | Mass: 1,800 g
FF-35 Shaft d1: 35 mm | Screw OD: 45 mm | Bearing: 6207ZZ | Snap ring: C35 | Mass: 2,050 g
FF-40 Shaft d1: 40 mm | Screw OD: 50-55 mm | Bearing: 6208ZZ | Snap ring: C40 | Mass: 3,050 g
Ball Screw Support UnitSUNGIL
13 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SUNGIL FF Ball Screw Supported-Side Support Unit (round flange, suppor

Brand SUNGIL·Ball Screw Support Unit

Available part numbers (13)

FF-6, FF-8, FF-10, FF-12, FF-15, FF-17, FF-20, FF-25, FF-30, FF-25D + 3 more — see full table ↓

How to order

Send the SUNGIL part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
FF-6Shaft d1: 6 mm | Screw OD: 8 mm | Bearing: 606ZZ | Snap ring: C6 | Mass: 30 g
FF-8Shaft d1: 6 mm | Screw OD: 10-12 mm | Bearing: 606ZZ | Snap ring: C6 | Mass: 30 g
FF-10Shaft d1: 8 mm | Screw OD: 10-15 mm | Bearing: 608ZZ | Snap ring: C8 | Mass: 60 g
FF-12Shaft d1: 10 mm | Screw OD: 14-18 mm | Bearing: 6000ZZ | Snap ring: C10 | Mass: 100 g
FF-15Shaft d1: 15 mm | Screw OD: 20 mm | Bearing: 6002ZZ | Snap ring: C15 | Mass: 140 g
FF-17Shaft d1: 17 mm | Screw OD: 25-28 mm | Bearing: 6203ZZ | Snap ring: C17 | Mass: 290 g
FF-20Shaft d1: 20 mm | Screw OD: 25-28 mm | Bearing: 6204ZZ | Snap ring: C20 | Mass: 380 g
FF-25Shaft d1: 25 mm | Screw OD: 30-36 mm | Bearing: 6205ZZ | Snap ring: C25 | Mass: 590 g
FF-30Shaft d1: 30 mm | Screw OD: 40 mm | Bearing: 6206ZZ | Snap ring: C30 | Mass: 930 g
FF-25DShaft d1: 25 mm | Bearing: 6205ZZ | Snap ring: C25 | Mass: 1,400 g
FF-30DShaft d1: 30 mm | Bearing: 6206ZZ | Snap ring: C30 | Mass: 1,800 g
FF-35Shaft d1: 35 mm | Screw OD: 45 mm | Bearing: 6207ZZ | Snap ring: C35 | Mass: 2,050 g
FF-40Shaft d1: 40 mm | Screw OD: 50-55 mm | Bearing: 6208ZZ | Snap ring: C40 | Mass: 3,050 g
