Product codes & specifications
| Product code | Spec | ||
|---|---|---|---|
| KGMN200-02 | B width (mm): 2.0 | R nose (mm): 0.2 | L (mm): 20 | D (mm): 1.7 | T (mm): 3.5 | Grade: DB2000 | Stock: Yes | ||
| KGMN300-02 | B width (mm): 3.0 | R nose (mm): 0.2 | L (mm): 20 | D (mm): 2.3 | T (mm): 4.0 | Grade: DB2000 | Stock: Yes | ||
| KGMN400-04 | B width (mm): 4.0 | R nose (mm): 0.4 | L (mm): 20 | D (mm): 3.3 | T (mm): 4.0 | Grade: DB2000 | Stock: Yes | ||
| KGMN500-04 | B width (mm): 5.0 | R nose (mm): 0.4 | L (mm): 25 | D (mm): 4.1 | T (mm): 4.5 | Grade: DB2000 |
Need a different model, or a part not listed here? Send us your parts list →
