TAUMAX FVT Series 5-Axis Self-Centering Vise

TAUMAX FVT Series 5-Axis Self-Centering Vise

Compact self-centering vise for 5-axis machining with a modular structure and low-interference design.

Key features

  • Heat-treated high-alloy steel base for wear resistance
  • Height tolerance and repeatability within 0.01 mm
  • Modular structure for easy assembly and part replacement
  • Minimized interference for 5-axis access
  • Standard serrated jaws with 3.5 mm clamping width; other jaws on request

Specifications

Type 5-axis self-centering vise
Included Wrench, clamp x4, guide key x2, user manual
Jaws Not included (order separately)
Unit mm
FVT-77 Jaw width (A): 77 mm | Base length (B): 130 mm | Overall length (C): 135 mm | Clamping range (J4): 112 mm | Max clamping force: 1,000 kgf | Package weight: 4 kg
FVT-125 Jaw width (A): 125 mm | Base length (B): 210 mm | Overall length (C): 215 mm | Clamping range (J4): 188 mm | Max clamping force: 1,500 kgf | Package weight: 11 kg
Self-Centering VisesTAUMAX
2 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

TAUMAX FVT Series 5-Axis Self-Centering Vise

Brand TAUMAX·Self-Centering Vises

Available part numbers (2)

FVT-77, FVT-125

How to order

Send the TAUMAX part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
FVT-77Jaw width (A): 77 mm | Base length (B): 130 mm | Overall length (C): 135 mm | Clamping range (J4): 112 mm | Max clamping force: 1,000 kgf | Package weight: 4 kg
FVT-125Jaw width (A): 125 mm | Base length (B): 210 mm | Overall length (C): 215 mm | Clamping range (J4): 188 mm | Max clamping force: 1,500 kgf | Package weight: 11 kg
