TAUMAX HSK Shank New Power Milling Chuck HSK-NPM

TAUMAX HSK Shank New Power Milling Chuck HSK-NPM

HSK-A shank power milling chuck for medium to heavy roughing with DC/DCS/DCJ straight collets.

Key features

  • Strong clamping force for medium to heavy roughing
  • Dust block function keeps cutting oil and chips out of the chuck
  • Slot design minimizes holder deformation
  • Run-out within 15 µm at 3D
  • Clamping range Ø20 to Ø42 mm with straight collets

Specifications

Clamping force 130 kgf·m (min.) to 500 kgf·m (max.)
HSK50A-NPM20-100 Shank: HSK50A | ØD (mm): 20 | L (mm): 100 | ØD1 (mm): 54 | L1 (mm): 74 | H insertion depth (mm): 75 | Applicable collet: DC20, DCS20, DCJ20 | Weight (kg): 1 | Stock: No
HSK63A-NPM20-100 Shank: HSK63A | ØD (mm): 20 | L (mm): 100 | ØD1 (mm): 54 | L1 (mm): 74 | H insertion depth (mm): 75 | Applicable collet: DC20, DCS20, DCJ20 | Weight (kg): 1.6 | Stock: Yes
HSK63A-NPM25-100 Shank: HSK63A | ØD (mm): 25 | L (mm): 100 | ØD1 (mm): 61 | L1 (mm): 74 | H insertion depth (mm): 75 | Applicable collet: DC25, DCS25 | Weight (kg): 1.9 | Stock: No
HSK63A-NPM32-110 Shank: HSK63A | ØD (mm): 32 | L (mm): 110 | ØD1 (mm): 75 | L1 (mm): 84 | H insertion depth (mm): 82 | Applicable collet: DC32, DCS32, DCJ32 | Weight (kg): 2.5 | Stock: No
HSK63A-NPM32-120 Shank: HSK63A | ØD (mm): 32 | L (mm): 120 | ØD1 (mm): 75 | L1 (mm): 94 | H insertion depth (mm): 90 | Applicable collet: DC32, DCS32, DCJ32 | Weight (kg): 2.9 | Stock: Yes
HSK100A-NPM20-110 Shank: HSK100A | ØD (mm): 20 | L (mm): 110 | ØD1 (mm): 54 | L1 (mm): 81 | H insertion depth (mm): 75 | Applicable collet: DC20, DCS20, DCJ20 | Weight (kg): 3 | Stock: No
HSK100A-NPM25-110 Shank: HSK100A | ØD (mm): 25 | L (mm): 110 | ØD1 (mm): 61 | L1 (mm): 81 | H insertion depth (mm): 75 | Applicable collet: DC25, DCS25, DCJ25 | Weight (kg): 3.2 | Stock: No
HSK100A-NPM32-115 Shank: HSK100A | ØD (mm): 32 | L (mm): 115 | ØD1 (mm): 75 | L1 (mm): 86 | H insertion depth (mm): 80 | Applicable collet: DC32, DCS32, DCJ32 | Weight (kg): 4.1 | Stock: No
HSK100A-NPM32-130 Shank: HSK100A | ØD (mm): 32 | L (mm): 130 | ØD1 (mm): 75 | L1 (mm): 101 | H insertion depth (mm): 90 | Applicable collet: DC32, DCS32, DCJ32 | Weight (kg): 4 | Stock: Yes
HSK100A-NPM42-135 Shank: HSK100A | ØD (mm): 42 | L (mm): 135 | ØD1 (mm): 90 | L1 (mm): 106 | H insertion depth (mm): 100 | Applicable collet: DC42, DCS42 | Weight (kg): 5.7 | Stock: No
Milling ChucksTAUMAX
10 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

TAUMAX HSK Shank New Power Milling Chuck HSK-NPM

Brand TAUMAX·Milling Chucks

Available part numbers (10)

HSK50A-NPM20-100, HSK63A-NPM20-100, HSK63A-NPM25-100, HSK63A-NPM32-110, HSK63A-NPM32-120, HSK100A-NPM20-110, HSK100A-NPM25-110, HSK100A-NPM32-115, HSK100A-NPM32-130, HSK100A-NPM42-135

How to order

Send the TAUMAX part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.
