TAUMAX HSK Shank Power Hydraulic Expansion Chuck DHE/P

TAUMAX HSK Shank Power Hydraulic Expansion Chuck DHE/P

Power hydraulic expansion chuck that combines hydraulic-chuck precision with high clamping force for medium and rough machining.

Key features

  • High clamping force for medium and rough machining
  • Max. clamping torque 1,400 Nm (Ø32)
  • Run-out within 3 um at 3 x D, better than milling chucks
  • Stable tool clamping with little effort
  • Tool clamping range Ø20-Ø32 mm

Specifications

Shank HSK-A (DIN 69893-1)
Balance Grade G6.3
Internal Coolant Optional (coolant nozzle set sold separately)
HSK63A-DHE20P-90 Tool Dia. ØD (mm): 20 | Length L (mm): 90 | ØD1 (mm): 54 | ØD2 (mm): 70 | L1 (mm): 30 | Tool Insertion Depth H (mm): 48-58 | Adjust Screw: M5 | Max RPM: 20,000 | Weight (kg): 1.7 | Stock: Non-stock item
HSK63A-DHE25P-105 Tool Dia. ØD (mm): 25 | Length L (mm): 105 | ØD1 (mm): 66 | ØD2 (mm): 75 | L1 (mm): 45 | Tool Insertion Depth H (mm): 58-68 | Adjust Screw: M5 | Max RPM: 20,000 | Weight (kg): 2.2 | Stock: Non-stock item
HSK63A-DHE32P-105 Tool Dia. ØD (mm): 32 | Length L (mm): 105 | ØD1 (mm): 74 | ØD2 (mm): 85 | L1 (mm): 45 | Tool Insertion Depth H (mm): 58-68 | Adjust Screw: M5 | Max RPM: 20,000 | Weight (kg): 2.4 | Stock: Non-stock item
HSK100A-DHE20P-90 Tool Dia. ØD (mm): 20 | Length L (mm): 90 | ØD1 (mm): 54 | ØD2 (mm): 70 | L1 (mm): 43 | Tool Insertion Depth H (mm): 58 | Max RPM: 15,000 | Weight (kg): 3.0 | Stock: Non-stock item
HSK100A-DHE25P-100 Tool Dia. ØD (mm): 25 | Length L (mm): 100 | ØD1 (mm): 66 | ØD2 (mm): 75 | L1 (mm): 53 | Tool Insertion Depth H (mm): 68 | Max RPM: 15,000 | Weight (kg): 3.6 | Stock: Non-stock item
HSK100A-DHE32P-100 Tool Dia. ØD (mm): 32 | Length L (mm): 100 | ØD1 (mm): 74 | ØD2 (mm): 85 | L1 (mm): 53 | Tool Insertion Depth H (mm): 68 | Max RPM: 15,000 | Weight (kg): 3.9 | Stock: Non-stock item
Hydraulic ChucksTAUMAX
6 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

TAUMAX HSK Shank Power Hydraulic Expansion Chuck DHE/P

Brand TAUMAX·Hydraulic Chucks

Available part numbers (6)

HSK63A-DHE20P-90, HSK63A-DHE25P-105, HSK63A-DHE32P-105, HSK100A-DHE20P-90, HSK100A-DHE25P-100, HSK100A-DHE32P-100
