TAUMAX SK Shank New Power Milling Chuck SK-NPM

SK (DIN 69871) shank power milling chuck for medium to heavy roughing with straight collets.

Key features

Strong clamping force for medium to heavy roughing
Dust block function keeps cutting oil and chips out of the chuck
Slot design minimizes holder deformation
Run-out within 15 µm at 3D
Clamping range Ø20 to Ø42 mm with straight collets
Optional CTC internal coolant system

Specifications

Clamping force	130 kgf·m (min.) to 500 kgf·m (max.)

SK40-NPM20-95		Shank: SK40 \| ØD (mm): 20 \| L (mm): 95 \| ØD1 (mm): 54 \| H insertion depth (mm): 85 \| G thread: M16 \| Applicable collet: DC20, DCS20, DCJ20 \| Weight (kg): 2.4 \| Stock: Yes
SK40-NPM32-95		Shank: SK40 \| ØD (mm): 32 \| L (mm): 95 \| ØD1 (mm): 75 \| H insertion depth (mm): 87 \| G thread: M16 \| Applicable collet: DC32, DCS32, DCJ32 \| Weight (kg): 2.4 \| Stock: Yes
SK40-NPM32-110		Shank: SK40 \| ØD (mm): 32 \| L (mm): 110 \| ØD1 (mm): 75 \| H insertion depth (mm): 95 \| G thread: M16 \| Applicable collet: DC32, DCS32, DCJ32 \| Weight (kg): 2.8 \| Stock: Yes
SK40-NPM32-135		Shank: SK40 \| ØD (mm): 32 \| L (mm): 135 \| ØD1 (mm): 75 \| H insertion depth (mm): 95 \| G thread: M16 \| Applicable collet: DC32, DCS32, DCJ32 \| Weight (kg): 3.2 \| Stock: Yes
SK50-NPM20-100		Shank: SK50 \| ØD (mm): 20 \| L (mm): 100 \| ØD1 (mm): 54 \| H insertion depth (mm): 85 \| G thread: M16 \| Applicable collet: DC20, DCS20, DCJ20 \| Weight (kg): 3.6 \| Stock: Yes
SK50-NPM32-100		Shank: SK50 \| ØD (mm): 32 \| L (mm): 100 \| ØD1 (mm): 75 \| H insertion depth (mm): 105 \| G thread: M24 \| Applicable collet: DC32, DCS32, DCJ32 \| Weight (kg): 4.3 \| Stock: Yes
SK50-NPM32-130		Shank: SK50 \| ØD (mm): 32 \| L (mm): 130 \| ØD1 (mm): 75 \| H insertion depth (mm): 105 \| G thread: M24 \| Applicable collet: DC32, DCS32, DCJ32 \| Weight (kg): 5.2 \| Stock: Yes
SK50-NPM42-110		Shank: SK50 \| ØD (mm): 42 \| L (mm): 110 \| ØD1 (mm): 90 \| H insertion depth (mm): 125 \| G thread: M24 \| Applicable collet: DC42, DCS42 \| Weight (kg): 5.2 \| Stock: Yes
SK50-NPM42-135		Shank: SK50 \| ØD (mm): 42 \| L (mm): 135 \| ØD1 (mm): 90 \| H insertion depth (mm): 125 \| G thread: M24 \| Applicable collet: DC42, DCS42 \| Weight (kg): 6.1 \| Stock: Yes

Milling ChucksTAUMAX

9 product codes available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

TAUMAX SK Shank New Power Milling Chuck SK-NPM

Brand TAUMAX·Milling Chucks

Available part numbers (9)

SK40-NPM20-95, SK40-NPM32-95, SK40-NPM32-110, SK40-NPM32-135, SK50-NPM20-100, SK50-NPM32-100, SK50-NPM32-130, SK50-NPM42-110, SK50-NPM42-135

How to order

Send the TAUMAX part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.
