Product codes & specifications
| Product code | Spec | ||
|---|---|---|---|
| TC20-1 | Collet size: TC20 | Morse taper: MT1 | L (mm): 60 | ØD1 (mm): 26 | ØD2 (mm): 20 | Weight (kg): 0.1 | Stock: Yes | ||
| TC20-2 | Collet size: TC20 | Morse taper: MT2 | L (mm): 72 | ØD1 (mm): 26 | ØD2 (mm): 20 | Weight (kg): 0.1 | Stock: Yes | ||
| TC25-1 | Collet size: TC25 | Morse taper: MT1 | L (mm): 60 | ØD1 (mm): 32 | ØD2 (mm): 25 | Weight (kg): 0.2 | Stock: Yes (to be switched to NP order after stock depletion) | ||
| TC25-2 | Collet size: TC25 | Morse taper: MT2 | L (mm): 72 | ØD1 (mm): 32 | ØD2 (mm): 25 | Weight (kg): 0.2 | Stock: Yes (to be switched to NP order after stock depletion) | ||
| TC32-1 | Collet size: TC32 | Morse taper: MT1 | L (mm): 60 | ØD1 (mm): 38 | ØD2 (mm): 32 | Weight (kg): 0.4 | Stock: Yes | ||
| TC32-2 | Collet size: TC32 | Morse taper: MT2 | L (mm): 72 | ØD1 (mm): 38 | ØD2 (mm): 32 | Weight (kg): 0.4 | Stock: Yes | ||
| TC32-3 | Collet size: TC32 | Morse taper: MT3 | L (mm): 90 | ØD1 (mm): 38 | ØD2 (mm): 32 | Weight (kg): 0.4 | Stock: Yes | ||
| TC42-1 | Collet size: TC42 | Morse taper: MT1 | L (mm): 60 | ØD1 (mm): 48 | ØD2 (mm): 42 | Weight (kg): 0.6 | Stock: Yes | ||
| TC42-2 | Collet size: TC42 | Morse taper: MT2 | L (mm): 72 | ØD1 (mm): 48 | ØD2 (mm): 42 | Weight (kg): 0.7 | Stock: Yes | ||
| TC42-3 | Collet size: TC42 | Morse taper: MT3 | L (mm): 90 | ØD1 (mm): 48 | ØD2 (mm): 42 | Weight (kg): 0.8 | Stock: Yes | ||
| TC42-4 | Collet size: TC42 | Morse taper: MT4 | L (mm): 113 | ØD1 (mm): 48 | ØD2 (mm): 42 | Weight (kg): 0.9 | Stock: Yes |
Need a different model, or a part not listed here? Send us your parts list →
