TPC Mechatronics NLCD Series Table Cylinder Stroke Adjusters and Shock Absorbers

TPC Mechatronics NLCD Series Table Cylinder Stroke Adjusters and Shock Absorbers

Stroke adjuster units for NLCD series table cylinders, ordered separately by bore size, adjuster position and adjustment range.

Key features

  • RF units mount at the extend end and RB units at the retract end, each with a rubber damper and an adjustment range of 5 mm (standard), 15 mm or 25 mm
  • Units are available for bore sizes 6 to 25 mm; NLCD32 has no adjuster option and NLCD06 has a 5 or 15 mm range only
  • Matching shock absorbers S0806, S1007 and S1412 are listed for shock-absorber equipped NLCD08 to NLCD25 cylinders
NLCD06-RF Type: Extend-end stroke adjuster, rubber damper | Applicable cylinder: NLCD06 | Adjustment range: 5 mm
NLCD06-RF15 Type: Extend-end stroke adjuster, rubber damper | Applicable cylinder: NLCD06 | Adjustment range: 15 mm
NLCD08-RF Type: Extend-end stroke adjuster, rubber damper | Applicable cylinder: NLCD08 | Adjustment range: 5 mm
NLCD08-RF15 Type: Extend-end stroke adjuster, rubber damper | Applicable cylinder: NLCD08 | Adjustment range: 15 mm
NLCD08-RF25 Type: Extend-end stroke adjuster, rubber damper | Applicable cylinder: NLCD08 | Adjustment range: 25 mm
NLCD12-RF Type: Extend-end stroke adjuster, rubber damper | Applicable cylinder: NLCD12 | Adjustment range: 5 mm
NLCD12-RF15 Type: Extend-end stroke adjuster, rubber damper | Applicable cylinder: NLCD12 | Adjustment range: 15 mm
NLCD12-RF25 Type: Extend-end stroke adjuster, rubber damper | Applicable cylinder: NLCD12 | Adjustment range: 25 mm
NLCD16-RF Type: Extend-end stroke adjuster, rubber damper | Applicable cylinder: NLCD16 | Adjustment range: 5 mm
NLCD16-RF15 Type: Extend-end stroke adjuster, rubber damper | Applicable cylinder: NLCD16 | Adjustment range: 15 mm
NLCD16-RF25 Type: Extend-end stroke adjuster, rubber damper | Applicable cylinder: NLCD16 | Adjustment range: 25 mm
NLCD20-RF Type: Extend-end stroke adjuster, rubber damper | Applicable cylinder: NLCD20 | Adjustment range: 5 mm
NLCD20-RF15 Type: Extend-end stroke adjuster, rubber damper | Applicable cylinder: NLCD20 | Adjustment range: 15 mm
NLCD20-RF25 Type: Extend-end stroke adjuster, rubber damper | Applicable cylinder: NLCD20 | Adjustment range: 25 mm
NLCD25-RF Type: Extend-end stroke adjuster, rubber damper | Applicable cylinder: NLCD25 | Adjustment range: 5 mm
NLCD25-RF15 Type: Extend-end stroke adjuster, rubber damper | Applicable cylinder: NLCD25 | Adjustment range: 15 mm
NLCD25-RF25 Type: Extend-end stroke adjuster, rubber damper | Applicable cylinder: NLCD25 | Adjustment range: 25 mm
NLCD06-RB Type: Retract-end stroke adjuster, rubber damper | Applicable cylinder: NLCD06 | Adjustment range: 5 mm
NLCD06-RB15 Type: Retract-end stroke adjuster, rubber damper | Applicable cylinder: NLCD06 | Adjustment range: 15 mm
NLCD08-RB Type: Retract-end stroke adjuster, rubber damper | Applicable cylinder: NLCD08 | Adjustment range: 5 mm
NLCD08-RB15 Type: Retract-end stroke adjuster, rubber damper | Applicable cylinder: NLCD08 | Adjustment range: 15 mm
NLCD08-RB25 Type: Retract-end stroke adjuster, rubber damper | Applicable cylinder: NLCD08 | Adjustment range: 25 mm
NLCD12-RB Type: Retract-end stroke adjuster, rubber damper | Applicable cylinder: NLCD12 | Adjustment range: 5 mm
NLCD12-RB15 Type: Retract-end stroke adjuster, rubber damper | Applicable cylinder: NLCD12 | Adjustment range: 15 mm
NLCD12-RB25 Type: Retract-end stroke adjuster, rubber damper | Applicable cylinder: NLCD12 | Adjustment range: 25 mm
NLCD16-RB Type: Retract-end stroke adjuster, rubber damper | Applicable cylinder: NLCD16 | Adjustment range: 5 mm
NLCD16-RB15 Type: Retract-end stroke adjuster, rubber damper | Applicable cylinder: NLCD16 | Adjustment range: 15 mm
NLCD16-RB25 Type: Retract-end stroke adjuster, rubber damper | Applicable cylinder: NLCD16 | Adjustment range: 25 mm
NLCD20-RB Type: Retract-end stroke adjuster, rubber damper | Applicable cylinder: NLCD20 | Adjustment range: 5 mm
NLCD20-RB15 Type: Retract-end stroke adjuster, rubber damper | Applicable cylinder: NLCD20 | Adjustment range: 15 mm
NLCD20-RB25 Type: Retract-end stroke adjuster, rubber damper | Applicable cylinder: NLCD20 | Adjustment range: 25 mm
NLCD25-RB Type: Retract-end stroke adjuster, rubber damper | Applicable cylinder: NLCD25 | Adjustment range: 5 mm
NLCD25-RB15 Type: Retract-end stroke adjuster, rubber damper | Applicable cylinder: NLCD25 | Adjustment range: 15 mm
NLCD25-RB25 Type: Retract-end stroke adjuster, rubber damper | Applicable cylinder: NLCD25 | Adjustment range: 25 mm
S0806 Type: Shock absorber | Applicable cylinder: NLCD08 / NLCD12 | Max absorbed energy: 5 J | Absorption stroke: 6 mm | Max impact speed: 2-3.5 m/s | Max frequency: 27 cycles/min | Ambient temperature: -10 to +80 C | Mass: 10 g
S1007 Type: Shock absorber | Applicable cylinder: NLCD16 | Max absorbed energy: 11 J | Absorption stroke: 7 mm | Max impact speed: 2-3.5 m/s | Max frequency: 22 cycles/min | Ambient temperature: -10 to +80 C | Mass: 15.5 g
S1412 Type: Shock absorber | Applicable cylinder: NLCD20 / NLCD25 | Max absorbed energy: 34 J | Absorption stroke: 12 mm | Max impact speed: 0.3-1 m/s | Max frequency: 25 cycles/min | Ambient temperature: -10 to +80 C | Mass: 43 g
Cylinder AccessoriesTPC Mechatronics
37 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

TPC Mechatronics NLCD Series Table Cylinder Stroke Adjusters and Shock Absorbers

Brand TPC Mechatronics·Cylinder Accessories

Available part numbers (37)

NLCD06-RF, NLCD06-RF15, NLCD08-RF, NLCD08-RF15, NLCD08-RF25, NLCD12-RF, NLCD12-RF15, NLCD12-RF25, NLCD16-RF, NLCD16-RF15 + 27 more — see full table ↓

How to order

Send the TPC Mechatronics part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
NLCD06-RFType: Extend-end stroke adjuster, rubber damper | Applicable cylinder: NLCD06 | Adjustment range: 5 mm
NLCD06-RF15Type: Extend-end stroke adjuster, rubber damper | Applicable cylinder: NLCD06 | Adjustment range: 15 mm
NLCD08-RFType: Extend-end stroke adjuster, rubber damper | Applicable cylinder: NLCD08 | Adjustment range: 5 mm
NLCD08-RF15Type: Extend-end stroke adjuster, rubber damper | Applicable cylinder: NLCD08 | Adjustment range: 15 mm
NLCD08-RF25Type: Extend-end stroke adjuster, rubber damper | Applicable cylinder: NLCD08 | Adjustment range: 25 mm
NLCD12-RFType: Extend-end stroke adjuster, rubber damper | Applicable cylinder: NLCD12 | Adjustment range: 5 mm
NLCD12-RF15Type: Extend-end stroke adjuster, rubber damper | Applicable cylinder: NLCD12 | Adjustment range: 15 mm
NLCD12-RF25Type: Extend-end stroke adjuster, rubber damper | Applicable cylinder: NLCD12 | Adjustment range: 25 mm
NLCD16-RFType: Extend-end stroke adjuster, rubber damper | Applicable cylinder: NLCD16 | Adjustment range: 5 mm
NLCD16-RF15Type: Extend-end stroke adjuster, rubber damper | Applicable cylinder: NLCD16 | Adjustment range: 15 mm
NLCD16-RF25Type: Extend-end stroke adjuster, rubber damper | Applicable cylinder: NLCD16 | Adjustment range: 25 mm
NLCD20-RFType: Extend-end stroke adjuster, rubber damper | Applicable cylinder: NLCD20 | Adjustment range: 5 mm
NLCD20-RF15Type: Extend-end stroke adjuster, rubber damper | Applicable cylinder: NLCD20 | Adjustment range: 15 mm
NLCD20-RF25Type: Extend-end stroke adjuster, rubber damper | Applicable cylinder: NLCD20 | Adjustment range: 25 mm
NLCD25-RFType: Extend-end stroke adjuster, rubber damper | Applicable cylinder: NLCD25 | Adjustment range: 5 mm
NLCD25-RF15Type: Extend-end stroke adjuster, rubber damper | Applicable cylinder: NLCD25 | Adjustment range: 15 mm
NLCD25-RF25Type: Extend-end stroke adjuster, rubber damper | Applicable cylinder: NLCD25 | Adjustment range: 25 mm
NLCD06-RBType: Retract-end stroke adjuster, rubber damper | Applicable cylinder: NLCD06 | Adjustment range: 5 mm
NLCD06-RB15Type: Retract-end stroke adjuster, rubber damper | Applicable cylinder: NLCD06 | Adjustment range: 15 mm
NLCD08-RBType: Retract-end stroke adjuster, rubber damper | Applicable cylinder: NLCD08 | Adjustment range: 5 mm
NLCD08-RB15Type: Retract-end stroke adjuster, rubber damper | Applicable cylinder: NLCD08 | Adjustment range: 15 mm
NLCD08-RB25Type: Retract-end stroke adjuster, rubber damper | Applicable cylinder: NLCD08 | Adjustment range: 25 mm
NLCD12-RBType: Retract-end stroke adjuster, rubber damper | Applicable cylinder: NLCD12 | Adjustment range: 5 mm
NLCD12-RB15Type: Retract-end stroke adjuster, rubber damper | Applicable cylinder: NLCD12 | Adjustment range: 15 mm
NLCD12-RB25Type: Retract-end stroke adjuster, rubber damper | Applicable cylinder: NLCD12 | Adjustment range: 25 mm
NLCD16-RBType: Retract-end stroke adjuster, rubber damper | Applicable cylinder: NLCD16 | Adjustment range: 5 mm
NLCD16-RB15Type: Retract-end stroke adjuster, rubber damper | Applicable cylinder: NLCD16 | Adjustment range: 15 mm
NLCD16-RB25Type: Retract-end stroke adjuster, rubber damper | Applicable cylinder: NLCD16 | Adjustment range: 25 mm
NLCD20-RBType: Retract-end stroke adjuster, rubber damper | Applicable cylinder: NLCD20 | Adjustment range: 5 mm
NLCD20-RB15Type: Retract-end stroke adjuster, rubber damper | Applicable cylinder: NLCD20 | Adjustment range: 15 mm
NLCD20-RB25Type: Retract-end stroke adjuster, rubber damper | Applicable cylinder: NLCD20 | Adjustment range: 25 mm
NLCD25-RBType: Retract-end stroke adjuster, rubber damper | Applicable cylinder: NLCD25 | Adjustment range: 5 mm
NLCD25-RB15Type: Retract-end stroke adjuster, rubber damper | Applicable cylinder: NLCD25 | Adjustment range: 15 mm
NLCD25-RB25Type: Retract-end stroke adjuster, rubber damper | Applicable cylinder: NLCD25 | Adjustment range: 25 mm
S0806Type: Shock absorber | Applicable cylinder: NLCD08 / NLCD12 | Max absorbed energy: 5 J | Absorption stroke: 6 mm | Max impact speed: 2-3.5 m/s | Max frequency: 27 cycles/min | Ambient temperature: -10 to +80 C | Mass: 10 g
S1007Type: Shock absorber | Applicable cylinder: NLCD16 | Max absorbed energy: 11 J | Absorption stroke: 7 mm | Max impact speed: 2-3.5 m/s | Max frequency: 22 cycles/min | Ambient temperature: -10 to +80 C | Mass: 15.5 g
S1412Type: Shock absorber | Applicable cylinder: NLCD20 / NLCD25 | Max absorbed energy: 34 J | Absorption stroke: 12 mm | Max impact speed: 0.3-1 m/s | Max frequency: 25 cycles/min | Ambient temperature: -10 to +80 C | Mass: 43 g
