Woonyoung WYMT-SH96SC3 Synchroscope LED Indicator, 3-Phase

LED synchroscope that shows whether generator and bus phase and frequency match, for three-phase 110-440 V systems.

Key features

Rotating LED ring shows faster (+) or slower (-) generator frequency
Centre LED turns off when phase and frequency are synchronized
Three-phase 110, 220, 380 or 440 V
96 x 96 mm panel case

Specifications

Rated voltage	3-phase 110, 220, 380, 440 V
Voltage range	85-115%
Power consumption	5 VA
Frequency	50 or 60 Hz
Working time	Max. 15 min
Operating temperature	-25 to +60 C
Humidity	5-95%
Dimensions	96 x 96 mm (cut-out 92 x 92 mm)
Weight	0.7 kg
Certifications	CE

WYMT-SH96SC3

Phase IndicatorsWoonyoung

1 product code available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Woonyoung WYMT-SH96SC3 Synchroscope LED Indicator, 3-Phase

Brand Woonyoung·Phase Indicators

Available part numbers (1)

WYMT-SH96SC3

How to order

Send the Woonyoung part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.
