YASKAWA CDBR Braking Unit (D Series)

YASKAWA CDBR Braking Unit (D Series)

Stand-alone CDBR braking units used with LKEB braking resistor units to shorten deceleration time on drives without (or beyond) a built-in braking transistor.

Key features

  • Used with LKEB braking resistor units
  • Units can be paralleled (master/slave)
  • Fault relay and transistor short-circuit detection outputs

Specifications

Use Stand-alone braking unit for 1000-series drives
CDBR-2022D Voltage class: 200 V | Code no: IP20: 100-091-707 / UL Type 1: 100-091-754 | Watt loss: 27 W | Weight: 2 kg (IP20)
CDBR-2037D Voltage class: 200 V | Code no: IP20: 100-091-712 / UL Type 1: 100-091-759 | Watt loss: 38 W | Weight: 2 kg (IP20)
CDBR-2110D Voltage class: 200 V | Code no: IP00: 100-091-524 / UL Type 1: 100-091-530 | Watt loss: 152 W | Weight: 7.5 kg (IP00)
CDBR-4030D Voltage class: 400 V | Code no: IP20: 100-091-717 / UL Type 1: 100-091-764 | Watt loss: 24 W | Weight: 2 kg (IP20)
CDBR-4045D Voltage class: 400 V | Code no: IP20: 100-091-722 / UL Type 1: 100-091-769 | Watt loss: 36 W | Weight: 2 kg (IP20)
CDBR-4220D Voltage class: 400 V | Code no: IP00: 100-091-526 / UL Type 1: 100-091-532 | Watt loss: 152 W | Weight: 7.5 kg (IP00)
Braking UnitsYASKAWA
6 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

YASKAWA CDBR Braking Unit (D Series)

Brand YASKAWA·Braking Units

Available part numbers (6)

CDBR-2022D, CDBR-2037D, CDBR-2110D, CDBR-4030D, CDBR-4045D, CDBR-4220D
