YASKAWA R1000 Fuse Holders (200 V / 400 V)

YASKAWA R1000 Fuse Holders (200 V / 400 V)

Fuse holders for the specified YASKAWA R1000 input fuses.

Key features

  • Select the holder matching the R1000 model and input fuse
  • One code number supplies a set of three holders
  • HT4017/HT5723 for 200 V 350GH fuses, HT6017/HT7723 for 400 V 660GH fuses
  • 170H1007 and 170H3003 for 170M series fuses on larger capacities

Specifications

For use with YASKAWA R1000 input fuses
Voltage classes 200 V and 400 V
Quantity 3 holders per code No.
Poles 1 per holder
Application R1000 standard configuration
Source YASKAWA R1000 catalogue, p. 15
HT4017 Code No.: 100-133-612 (set of 3) | R1000: 2A03P5 to 2A0020 | Voltage: 200 V | For fuses: 350GH series
HT5723 Code No.: 100-133-613 (set of 3) | R1000: 2A0028, 2A0035, 2A0053 | Voltage: 200 V | For fuses: 350GH series
170H1007 Code No.: 100-110-543 (set of 3) | R1000: 2A0073, 4A0105, 4A0150 | Voltage: 200 V / 400 V | For fuses: 170M2620 / 170M1371
170H3003 Code No.: 100-107-417 (set of 3) | R1000: 2A0105, 4A0210, 4A0300 | Voltage: 200 V / 400 V | For fuses: 170M3021 / 170M4016
HT6017 Code No.: 100-107-411 (set of 3) | R1000: 4A03P5 to 4A0043 | Voltage: 400 V | For fuses: 660GH series
HT7723 Code No.: 100-107-415 (set of 3) | R1000: 4A0053, 4A0073 | Voltage: 400 V | For fuses: 660GH-125ULTC / 660GH-160ULTC
Fuse HoldersYASKAWA
6 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

YASKAWA R1000 Fuse Holders (200 V / 400 V)

Brand YASKAWA·Fuse Holders

Available part numbers (6)

HT4017, HT5723, 170H1007, 170H3003, HT6017, HT7723
