Yuken One Way Restrictor (SRCT/SRCG-03/06/10)

Yuken One Way Restrictor (SRCT/SRCG-03/06/10)

Restrictors · One Way Restrictors.

Key features

  • Max. operating pressure: 25 MPa
  • Rated flow: 30 (03) / 85 (06) / 230 (10) L/min (at 0.3 MPa drop)
  • Threaded (T) / sub-plate (G) mounting
  • Controlled flow one way, free reverse flow

Specifications

Type One Way Restrictor
Max. Operating Pressure 25 MPa
Reverse Flow Free (check valve)
Design No. 50
SRCT-03-50 One Way Restrictor SRCT-03, Threaded | Type: One Way Restrictor | Mounting: Threaded | Valve Size: 03 | Rated Flow: 30 L/min (at 0.3 MPa drop) | Max. Operating Pressure: 25 MPa | Reverse Flow: Free (check valve) | Mass: 1.5 kg | Design No.: 50
SRCT-06-50 One Way Restrictor SRCT-06, Threaded | Type: One Way Restrictor | Mounting: Threaded | Valve Size: 06 | Rated Flow: 85 L/min (at 0.3 MPa drop) | Max. Operating Pressure: 25 MPa | Reverse Flow: Free (check valve) | Mass: 3.8 kg | Design No.: 50
SRCT-10-50 One Way Restrictor SRCT-10, Threaded | Type: One Way Restrictor | Mounting: Threaded | Valve Size: 10 | Rated Flow: 230 L/min (at 0.3 MPa drop) | Max. Operating Pressure: 25 MPa | Reverse Flow: Free (check valve) | Mass: 9.1 kg | Design No.: 50
SRCG-03-50 One Way Restrictor SRCG-03, Sub-plate | Type: One Way Restrictor | Mounting: Sub-plate | Valve Size: 03 | Rated Flow: 30 L/min (at 0.3 MPa drop) | Max. Operating Pressure: 25 MPa | Reverse Flow: Free (check valve) | Mass: 2.5 kg | Design No.: 50
SRCG-06-50 One Way Restrictor SRCG-06, Sub-plate | Type: One Way Restrictor | Mounting: Sub-plate | Valve Size: 06 | Rated Flow: 85 L/min (at 0.3 MPa drop) | Max. Operating Pressure: 25 MPa | Reverse Flow: Free (check valve) | Mass: 3.9 kg | Design No.: 50
SRCG-10-50 One Way Restrictor SRCG-10, Sub-plate | Type: One Way Restrictor | Mounting: Sub-plate | Valve Size: 10 | Rated Flow: 230 L/min (at 0.3 MPa drop) | Max. Operating Pressure: 25 MPa | Reverse Flow: Free (check valve) | Mass: 7.5 kg | Design No.: 50
RestrictorsYuken
6 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Yuken One Way Restrictor (SRCT/SRCG-03/06/10)

Brand Yuken·Restrictors

Available part numbers (6)

SRCT-03-50, SRCT-06-50, SRCT-10-50, SRCG-03-50, SRCG-06-50, SRCG-10-50

How to order

Send the Yuken part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
SRCT-03-50One Way Restrictor SRCT-03, Threaded | Type: One Way Restrictor | Mounting: Threaded | Valve Size: 03 | Rated Flow: 30 L/min (at 0.3 MPa drop) | Max. Operating Pressure: 25 MPa | Reverse Flow: Free (check valve) | Mass: 1.5 kg | Design No.: 50
SRCT-06-50One Way Restrictor SRCT-06, Threaded | Type: One Way Restrictor | Mounting: Threaded | Valve Size: 06 | Rated Flow: 85 L/min (at 0.3 MPa drop) | Max. Operating Pressure: 25 MPa | Reverse Flow: Free (check valve) | Mass: 3.8 kg | Design No.: 50
SRCT-10-50One Way Restrictor SRCT-10, Threaded | Type: One Way Restrictor | Mounting: Threaded | Valve Size: 10 | Rated Flow: 230 L/min (at 0.3 MPa drop) | Max. Operating Pressure: 25 MPa | Reverse Flow: Free (check valve) | Mass: 9.1 kg | Design No.: 50
SRCG-03-50One Way Restrictor SRCG-03, Sub-plate | Type: One Way Restrictor | Mounting: Sub-plate | Valve Size: 03 | Rated Flow: 30 L/min (at 0.3 MPa drop) | Max. Operating Pressure: 25 MPa | Reverse Flow: Free (check valve) | Mass: 2.5 kg | Design No.: 50
SRCG-06-50One Way Restrictor SRCG-06, Sub-plate | Type: One Way Restrictor | Mounting: Sub-plate | Valve Size: 06 | Rated Flow: 85 L/min (at 0.3 MPa drop) | Max. Operating Pressure: 25 MPa | Reverse Flow: Free (check valve) | Mass: 3.9 kg | Design No.: 50
SRCG-10-50One Way Restrictor SRCG-10, Sub-plate | Type: One Way Restrictor | Mounting: Sub-plate | Valve Size: 10 | Rated Flow: 230 L/min (at 0.3 MPa drop) | Max. Operating Pressure: 25 MPa | Reverse Flow: Free (check valve) | Mass: 7.5 kg | Design No.: 50
