Yuken Semiconductor Pressure Switch (JT-02)

Yuken Semiconductor Pressure Switch (JT-02)

Semiconductor Type Pressure Switches.

Key features

  • Pressure setting range 0.1–35 MPa (model dependent)
  • Open collector output (photocoupler isolated), DC 35V max 100 mA
  • Supply DC 10–28V, consumption ≤10 mA
  • Protection IP54 (standard) / IP65 (protective cover -S)
  • Operating temp −20 to +70°C
  • Repeatability approx. 0.5%

Specifications

Type Semiconductor Type Pressure Switch
Output Open collector, photocoupler isolated, DC 35V / 100 mA
Supply DC 10–28V, ≤10 mA
Response 1.5 ms (no damper) / 20 ms (with damper)
Mass 175 g
Design No. 11
JT-02-35-11 Semiconductor Pressure Switch JT-02-35, set 0.1–3.5 MPa | Type: Semiconductor Type Pressure Switch | Max. Operating Pressure: 10 MPa | Withstand Pressure: 20 MPa | Pressure Setting Range: 0.1–3.5 MPa | Protective Cover: No (IP54) | Output: Open collector, photocoupler isolated, DC 35V / 100 mA | Supply: DC 10–28V, ≤10 mA | Response: 1.5 ms (no damper) / 20 ms (with damper) | Protection: IP54 | Mass: 175 g | Design No.: 11
JT-02-35-S-11 Semiconductor Pressure Switch JT-02-35-S, set 0.1–3.5 MPa, protective cover | Type: Semiconductor Type Pressure Switch | Max. Operating Pressure: 10 MPa | Withstand Pressure: 20 MPa | Pressure Setting Range: 0.1–3.5 MPa | Protective Cover: Yes (-S) (IP65) | Output: Open collector, photocoupler isolated, DC 35V / 100 mA | Supply: DC 10–28V, ≤10 mA | Response: 1.5 ms (no damper) / 20 ms (with damper) | Protection: IP65 | Mass: 175 g | Design No.: 11
JT-02-100-11 Semiconductor Pressure Switch JT-02-100, set 1–10 MPa | Type: Semiconductor Type Pressure Switch | Max. Operating Pressure: 10 MPa | Withstand Pressure: 20 MPa | Pressure Setting Range: 1–10 MPa | Protective Cover: No (IP54) | Output: Open collector, photocoupler isolated, DC 35V / 100 mA | Supply: DC 10–28V, ≤10 mA | Response: 1.5 ms (no damper) / 20 ms (with damper) | Protection: IP54 | Mass: 175 g | Design No.: 11
JT-02-100-S-11 Semiconductor Pressure Switch JT-02-100-S, set 1–10 MPa, protective cover | Type: Semiconductor Type Pressure Switch | Max. Operating Pressure: 10 MPa | Withstand Pressure: 20 MPa | Pressure Setting Range: 1–10 MPa | Protective Cover: Yes (-S) (IP65) | Output: Open collector, photocoupler isolated, DC 35V / 100 mA | Supply: DC 10–28V, ≤10 mA | Response: 1.5 ms (no damper) / 20 ms (with damper) | Protection: IP65 | Mass: 175 g | Design No.: 11
JT-02-200-11 Semiconductor Pressure Switch JT-02-200, set 2–20 MPa | Type: Semiconductor Type Pressure Switch | Max. Operating Pressure: 20 MPa | Withstand Pressure: 40 MPa | Pressure Setting Range: 2–20 MPa | Protective Cover: No (IP54) | Output: Open collector, photocoupler isolated, DC 35V / 100 mA | Supply: DC 10–28V, ≤10 mA | Response: 1.5 ms (no damper) / 20 ms (with damper) | Protection: IP54 | Mass: 175 g | Design No.: 11
JT-02-200-S-11 Semiconductor Pressure Switch JT-02-200-S, set 2–20 MPa, protective cover | Type: Semiconductor Type Pressure Switch | Max. Operating Pressure: 20 MPa | Withstand Pressure: 40 MPa | Pressure Setting Range: 2–20 MPa | Protective Cover: Yes (-S) (IP65) | Output: Open collector, photocoupler isolated, DC 35V / 100 mA | Supply: DC 10–28V, ≤10 mA | Response: 1.5 ms (no damper) / 20 ms (with damper) | Protection: IP65 | Mass: 175 g | Design No.: 11
JT-02-350-11 Semiconductor Pressure Switch JT-02-350, set 3.5–35 MPa | Type: Semiconductor Type Pressure Switch | Max. Operating Pressure: 35 MPa | Withstand Pressure: 50 MPa | Pressure Setting Range: 3.5–35 MPa | Protective Cover: No (IP54) | Output: Open collector, photocoupler isolated, DC 35V / 100 mA | Supply: DC 10–28V, ≤10 mA | Response: 1.5 ms (no damper) / 20 ms (with damper) | Protection: IP54 | Mass: 175 g | Design No.: 11
JT-02-350-S-11 Semiconductor Pressure Switch JT-02-350-S, set 3.5–35 MPa, protective cover | Type: Semiconductor Type Pressure Switch | Max. Operating Pressure: 35 MPa | Withstand Pressure: 50 MPa | Pressure Setting Range: 3.5–35 MPa | Protective Cover: Yes (-S) (IP65) | Output: Open collector, photocoupler isolated, DC 35V / 100 mA | Supply: DC 10–28V, ≤10 mA | Response: 1.5 ms (no damper) / 20 ms (with damper) | Protection: IP65 | Mass: 175 g | Design No.: 11
Pressure Switches & MonitoringYuken
8 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Yuken Semiconductor Pressure Switch (JT-02)

Brand Yuken·Pressure Switches & Monitoring

Available part numbers (8)

JT-02-35-11, JT-02-35-S-11, JT-02-100-11, JT-02-100-S-11, JT-02-200-11, JT-02-200-S-11, JT-02-350-11, JT-02-350-S-11

How to order

Send the Yuken part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
JT-02-35-11Semiconductor Pressure Switch JT-02-35, set 0.1–3.5 MPa | Type: Semiconductor Type Pressure Switch | Max. Operating Pressure: 10 MPa | Withstand Pressure: 20 MPa | Pressure Setting Range: 0.1–3.5 MPa | Protective Cover: No (IP54) | Output: Open collector, photocoupler isolated, DC 35V / 100 mA | Supply: DC 10–28V, ≤10 mA | Response: 1.5 ms (no damper) / 20 ms (with damper) | Protection: IP54 | Mass: 175 g | Design No.: 11
JT-02-35-S-11Semiconductor Pressure Switch JT-02-35-S, set 0.1–3.5 MPa, protective cover | Type: Semiconductor Type Pressure Switch | Max. Operating Pressure: 10 MPa | Withstand Pressure: 20 MPa | Pressure Setting Range: 0.1–3.5 MPa | Protective Cover: Yes (-S) (IP65) | Output: Open collector, photocoupler isolated, DC 35V / 100 mA | Supply: DC 10–28V, ≤10 mA | Response: 1.5 ms (no damper) / 20 ms (with damper) | Protection: IP65 | Mass: 175 g | Design No.: 11
JT-02-100-11Semiconductor Pressure Switch JT-02-100, set 1–10 MPa | Type: Semiconductor Type Pressure Switch | Max. Operating Pressure: 10 MPa | Withstand Pressure: 20 MPa | Pressure Setting Range: 1–10 MPa | Protective Cover: No (IP54) | Output: Open collector, photocoupler isolated, DC 35V / 100 mA | Supply: DC 10–28V, ≤10 mA | Response: 1.5 ms (no damper) / 20 ms (with damper) | Protection: IP54 | Mass: 175 g | Design No.: 11
JT-02-100-S-11Semiconductor Pressure Switch JT-02-100-S, set 1–10 MPa, protective cover | Type: Semiconductor Type Pressure Switch | Max. Operating Pressure: 10 MPa | Withstand Pressure: 20 MPa | Pressure Setting Range: 1–10 MPa | Protective Cover: Yes (-S) (IP65) | Output: Open collector, photocoupler isolated, DC 35V / 100 mA | Supply: DC 10–28V, ≤10 mA | Response: 1.5 ms (no damper) / 20 ms (with damper) | Protection: IP65 | Mass: 175 g | Design No.: 11
JT-02-200-11Semiconductor Pressure Switch JT-02-200, set 2–20 MPa | Type: Semiconductor Type Pressure Switch | Max. Operating Pressure: 20 MPa | Withstand Pressure: 40 MPa | Pressure Setting Range: 2–20 MPa | Protective Cover: No (IP54) | Output: Open collector, photocoupler isolated, DC 35V / 100 mA | Supply: DC 10–28V, ≤10 mA | Response: 1.5 ms (no damper) / 20 ms (with damper) | Protection: IP54 | Mass: 175 g | Design No.: 11
JT-02-200-S-11Semiconductor Pressure Switch JT-02-200-S, set 2–20 MPa, protective cover | Type: Semiconductor Type Pressure Switch | Max. Operating Pressure: 20 MPa | Withstand Pressure: 40 MPa | Pressure Setting Range: 2–20 MPa | Protective Cover: Yes (-S) (IP65) | Output: Open collector, photocoupler isolated, DC 35V / 100 mA | Supply: DC 10–28V, ≤10 mA | Response: 1.5 ms (no damper) / 20 ms (with damper) | Protection: IP65 | Mass: 175 g | Design No.: 11
JT-02-350-11Semiconductor Pressure Switch JT-02-350, set 3.5–35 MPa | Type: Semiconductor Type Pressure Switch | Max. Operating Pressure: 35 MPa | Withstand Pressure: 50 MPa | Pressure Setting Range: 3.5–35 MPa | Protective Cover: No (IP54) | Output: Open collector, photocoupler isolated, DC 35V / 100 mA | Supply: DC 10–28V, ≤10 mA | Response: 1.5 ms (no damper) / 20 ms (with damper) | Protection: IP54 | Mass: 175 g | Design No.: 11
JT-02-350-S-11Semiconductor Pressure Switch JT-02-350-S, set 3.5–35 MPa, protective cover | Type: Semiconductor Type Pressure Switch | Max. Operating Pressure: 35 MPa | Withstand Pressure: 50 MPa | Pressure Setting Range: 3.5–35 MPa | Protective Cover: Yes (-S) (IP65) | Output: Open collector, photocoupler isolated, DC 35V / 100 mA | Supply: DC 10–28V, ≤10 mA | Response: 1.5 ms (no damper) / 20 ms (with damper) | Protection: IP65 | Mass: 175 g | Design No.: 11
