Cable Carriers
CP SYSTEM
[CP SYSTEM] — Double Cable Clamp (Ø06-34mm, CA2/C2)
Family ID: CPS-CLAMP-DOUBLE
CP SYSTEM Cable Clamp, double type — fixes two stacked cables with a high-strength steel clamp that minimizes cable damage when tightened (holding force approx. 89 Kgf, about 3x a tie wrap). Each part is marked with its product no. Clamp ASM (CA2) and clamp-only (C2) part numbers available per cable diameter (Ø06-34mm).
18 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| CA2.0612 | Double cable clamp ASM, Ø06~12mm | CP SYSTEM | Type: Double Cable Clamp | Part Category: Clamp ASM (assembly w/ bolt) | Applicable Cable: Ø06~12mm | Dimension A: 16.5±0.2mm | Dimension H: 65.0+5mm | Material: High strength steel | ||
| C2.0612 | Double cable clamp body, Ø06~12mm | CP SYSTEM | Type: Double Cable Clamp | Part Category: Clamp (body only) | Applicable Cable: Ø06~12mm | Dimension A: 16.5±0.2mm | Dimension H: 65.0+5mm | Material: High strength steel | ||
| CA2.1214 | Double cable clamp ASM, Ø12~14mm | CP SYSTEM | Type: Double Cable Clamp | Part Category: Clamp ASM (assembly w/ bolt) | Applicable Cable: Ø12~14mm | Dimension A: 17.5±0.2mm | Dimension H: 69.0+5mm | Material: High strength steel | ||
| C2.1214 | Double cable clamp body, Ø12~14mm | CP SYSTEM | Type: Double Cable Clamp | Part Category: Clamp (body only) | Applicable Cable: Ø12~14mm | Dimension A: 17.5±0.2mm | Dimension H: 69.0+5mm | Material: High strength steel | ||
| CA2.1416 | Double cable clamp ASM, Ø14~16mm | CP SYSTEM | Type: Double Cable Clamp | Part Category: Clamp ASM (assembly w/ bolt) | Applicable Cable: Ø14~16mm | Dimension A: 20.0±0.2mm | Dimension H: 73.0+5mm | Material: High strength steel | ||
| C2.1416 | Double cable clamp body, Ø14~16mm | CP SYSTEM | Type: Double Cable Clamp | Part Category: Clamp (body only) | Applicable Cable: Ø14~16mm | Dimension A: 20.0±0.2mm | Dimension H: 73.0+5mm | Material: High strength steel | ||
| CA2.1618 | Double cable clamp ASM, Ø16~18mm | CP SYSTEM | Type: Double Cable Clamp | Part Category: Clamp ASM (assembly w/ bolt) | Applicable Cable: Ø16~18mm | Dimension A: 22.0±0.2mm | Dimension H: 77.0+5mm | Material: High strength steel | ||
| C2.1618 | Double cable clamp body, Ø16~18mm | CP SYSTEM | Type: Double Cable Clamp | Part Category: Clamp (body only) | Applicable Cable: Ø16~18mm | Dimension A: 22.0±0.2mm | Dimension H: 77.0+5mm | Material: High strength steel | ||
| CA2.1820 | Double cable clamp ASM, Ø18~20mm | CP SYSTEM | Type: Double Cable Clamp | Part Category: Clamp ASM (assembly w/ bolt) | Applicable Cable: Ø18~20mm | Dimension A: 24.0±0.2mm | Dimension H: 81.0+5mm | Material: High strength steel | ||
| C2.1820 | Double cable clamp body, Ø18~20mm | CP SYSTEM | Type: Double Cable Clamp | Part Category: Clamp (body only) | Applicable Cable: Ø18~20mm | Dimension A: 24.0±0.2mm | Dimension H: 81.0+5mm | Material: High strength steel | ||
| CA2.2022 | Double cable clamp ASM, Ø20~22mm | CP SYSTEM | Type: Double Cable Clamp | Part Category: Clamp ASM (assembly w/ bolt) | Applicable Cable: Ø20~22mm | Dimension A: 26.0±0.2mm | Dimension H: 85.0+5mm | Material: High strength steel | ||
| C2.2022 | Double cable clamp body, Ø20~22mm | CP SYSTEM | Type: Double Cable Clamp | Part Category: Clamp (body only) | Applicable Cable: Ø20~22mm | Dimension A: 26.0±0.2mm | Dimension H: 85.0+5mm | Material: High strength steel | ||
| CA2.2226 | Double cable clamp ASM, Ø22~26mm | CP SYSTEM | Type: Double Cable Clamp | Part Category: Clamp ASM (assembly w/ bolt) | Applicable Cable: Ø22~26mm | Dimension A: 30.0±0.2mm | Dimension H: 94.5+5mm | Material: High strength steel | ||
| C2.2226 | Double cable clamp body, Ø22~26mm | CP SYSTEM | Type: Double Cable Clamp | Part Category: Clamp (body only) | Applicable Cable: Ø22~26mm | Dimension A: 30.0±0.2mm | Dimension H: 94.5+5mm | Material: High strength steel | ||
| CA2.2630 | Double cable clamp ASM, Ø26~30mm | CP SYSTEM | Type: Double Cable Clamp | Part Category: Clamp ASM (assembly w/ bolt) | Applicable Cable: Ø26~30mm | Dimension A: 34.0±0.2mm | Dimension H: 101.0+5mm | Material: High strength steel | ||
| C2.2630 | Double cable clamp body, Ø26~30mm | CP SYSTEM | Type: Double Cable Clamp | Part Category: Clamp (body only) | Applicable Cable: Ø26~30mm | Dimension A: 34.0±0.2mm | Dimension H: 101.0+5mm | Material: High strength steel | ||
| CA2.3034 | Double cable clamp ASM, Ø30~34mm | CP SYSTEM | Type: Double Cable Clamp | Part Category: Clamp ASM (assembly w/ bolt) | Applicable Cable: Ø30~34mm | Dimension A: 38.0±0.2mm | Dimension H: 110.0+5mm | Material: High strength steel | ||
| C2.3034 | Double cable clamp body, Ø30~34mm | CP SYSTEM | Type: Double Cable Clamp | Part Category: Clamp (body only) | Applicable Cable: Ø30~34mm | Dimension A: 38.0±0.2mm | Dimension H: 110.0+5mm | Material: High strength steel |
