[GGM] — K16-1627 Series DC Planetary Geared Motor (ø16mm, 12/24V, 1/4–1/4592)
DC GGM

[GGM] — K16-1627 Series DC Planetary Geared Motor (ø16mm, 12/24V, 1/4–1/4592)

Family ID: GGM-K16-1627

GGM K16-1627 micro DC planetary geared motor, ø16mm frame with ø3mm shaft (2-M2 tapped). Two windings (12V/24V), 29 planetary ratios 1/4 to 1/4592; 16g.

58 product codes available in this family

RFQ Cart (0)

Product Codes & Specifications

Product Code Description Brand Spec
K16-0004-KD1627R1 GGM K16-1627 DC 12V planetary geared motor, ratio 1/4, 1461 rpm / 0.03 kgf·cm @ max eff. GGM Motor: KD1627R1 | Voltage: DC 12V | Gear Ratio: 1/4 | Output Speed (max eff.): 1461 rpm | Output Torque (max eff.): 0.03 kgf·cm | No-load Speed: 8000 rpm | Stall Torque: 32 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 15 mm | Type: DC planetary geared motor
K16-0014-KD1627R1 GGM K16-1627 DC 12V planetary geared motor, ratio 1/14, 417 rpm / 0.07 kgf·cm @ max eff. GGM Motor: KD1627R1 | Voltage: DC 12V | Gear Ratio: 1/14 | Output Speed (max eff.): 417 rpm | Output Torque (max eff.): 0.07 kgf·cm | No-load Speed: 8000 rpm | Stall Torque: 32 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 18.7 mm | Type: DC planetary geared motor
K16-0016-KD1627R1 GGM K16-1627 DC 12V planetary geared motor, ratio 1/16, 365 rpm / 0.09 kgf·cm @ max eff. GGM Motor: KD1627R1 | Voltage: DC 12V | Gear Ratio: 1/16 | Output Speed (max eff.): 365 rpm | Output Torque (max eff.): 0.09 kgf·cm | No-load Speed: 8000 rpm | Stall Torque: 32 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 18.7 mm | Type: DC planetary geared motor
K16-0019-KD1627R1 GGM K16-1627 DC 12V planetary geared motor, ratio 1/19, 307 rpm / 0.1 kgf·cm @ max eff. GGM Motor: KD1627R1 | Voltage: DC 12V | Gear Ratio: 1/19 | Output Speed (max eff.): 307 rpm | Output Torque (max eff.): 0.1 kgf·cm | No-load Speed: 8000 rpm | Stall Torque: 32 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 18.7 mm | Type: DC planetary geared motor
K16-0029-KD1627R1 GGM K16-1627 DC 12V planetary geared motor, ratio 1/29, 201 rpm / 0.15 kgf·cm @ max eff. GGM Motor: KD1627R1 | Voltage: DC 12V | Gear Ratio: 1/29 | Output Speed (max eff.): 201 rpm | Output Torque (max eff.): 0.15 kgf·cm | No-load Speed: 8000 rpm | Stall Torque: 32 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 18.7 mm | Type: DC planetary geared motor
K16-0053-KD1627R1 GGM K16-1627 DC 12V planetary geared motor, ratio 1/53, 110 rpm / 0.23 kgf·cm @ max eff. GGM Motor: KD1627R1 | Voltage: DC 12V | Gear Ratio: 1/53 | Output Speed (max eff.): 110 rpm | Output Torque (max eff.): 0.23 kgf·cm | No-load Speed: 8000 rpm | Stall Torque: 32 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 22.4 mm | Type: DC planetary geared motor
K16-0062-KD1627R1 GGM K16-1627 DC 12V planetary geared motor, ratio 1/62, 94 rpm / 0.27 kgf·cm @ max eff. GGM Motor: KD1627R1 | Voltage: DC 12V | Gear Ratio: 1/62 | Output Speed (max eff.): 94 rpm | Output Torque (max eff.): 0.27 kgf·cm | No-load Speed: 8000 rpm | Stall Torque: 32 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 22.4 mm | Type: DC planetary geared motor
K16-0072-KD1627R1 GGM K16-1627 DC 12V planetary geared motor, ratio 1/72, 81 rpm / 0.31 kgf·cm @ max eff. GGM Motor: KD1627R1 | Voltage: DC 12V | Gear Ratio: 1/72 | Output Speed (max eff.): 81 rpm | Output Torque (max eff.): 0.31 kgf·cm | No-load Speed: 8000 rpm | Stall Torque: 32 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 22.4 mm | Type: DC planetary geared motor
K16-0084-KD1627R1 GGM K16-1627 DC 12V planetary geared motor, ratio 1/84, 69 rpm / 0.36 kgf·cm @ max eff. GGM Motor: KD1627R1 | Voltage: DC 12V | Gear Ratio: 1/84 | Output Speed (max eff.): 69 rpm | Output Torque (max eff.): 0.36 kgf·cm | No-load Speed: 8000 rpm | Stall Torque: 32 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 22.4 mm | Type: DC planetary geared motor
K16-0104-KD1627R1 GGM K16-1627 DC 12V planetary geared motor, ratio 1/104, 56 rpm / 0.45 kgf·cm @ max eff. GGM Motor: KD1627R1 | Voltage: DC 12V | Gear Ratio: 1/104 | Output Speed (max eff.): 56 rpm | Output Torque (max eff.): 0.45 kgf·cm | No-load Speed: 8000 rpm | Stall Torque: 32 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 22.4 mm | Type: DC planetary geared motor
K16-0128-KD1627R1 GGM K16-1627 DC 12V planetary geared motor, ratio 1/128, 45 rpm / 0.55 kgf·cm @ max eff. GGM Motor: KD1627R1 | Voltage: DC 12V | Gear Ratio: 1/128 | Output Speed (max eff.): 45 rpm | Output Torque (max eff.): 0.55 kgf·cm | No-load Speed: 8000 rpm | Stall Torque: 32 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 22.4 mm | Type: DC planetary geared motor
K16-0157-KD1627R1 GGM K16-1627 DC 12V planetary geared motor, ratio 1/157, 37 rpm / 0.68 kgf·cm @ max eff. GGM Motor: KD1627R1 | Voltage: DC 12V | Gear Ratio: 1/157 | Output Speed (max eff.): 37 rpm | Output Torque (max eff.): 0.68 kgf·cm | No-load Speed: 8000 rpm | Stall Torque: 32 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 22.4 mm | Type: DC planetary geared motor
K16-0198-KD1627R1 GGM K16-1627 DC 12V planetary geared motor, ratio 1/198, 29 rpm / 0.69 kgf·cm @ max eff. GGM Motor: KD1627R1 | Voltage: DC 12V | Gear Ratio: 1/198 | Output Speed (max eff.): 29 rpm | Output Torque (max eff.): 0.69 kgf·cm | No-load Speed: 8000 rpm | Stall Torque: 32 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 26.1 mm | Type: DC planetary geared motor
K16-0231-KD1627R1 GGM K16-1627 DC 12V planetary geared motor, ratio 1/231, 25 rpm / 0.81 kgf·cm @ max eff. GGM Motor: KD1627R1 | Voltage: DC 12V | Gear Ratio: 1/231 | Output Speed (max eff.): 25 rpm | Output Torque (max eff.): 0.81 kgf·cm | No-load Speed: 8000 rpm | Stall Torque: 32 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 26.1 mm | Type: DC planetary geared motor
K16-0270-KD1627R1 GGM K16-1627 DC 12V planetary geared motor, ratio 1/270, 21 rpm / 0.94 kgf·cm @ max eff. GGM Motor: KD1627R1 | Voltage: DC 12V | Gear Ratio: 1/270 | Output Speed (max eff.): 21 rpm | Output Torque (max eff.): 0.94 kgf·cm | No-load Speed: 8000 rpm | Stall Torque: 32 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 26.1 mm | Type: DC planetary geared motor
K16-0316-KD1627R1 GGM K16-1627 DC 12V planetary geared motor, ratio 1/316, 18 rpm / 1.1 kgf·cm @ max eff. GGM Motor: KD1627R1 | Voltage: DC 12V | Gear Ratio: 1/316 | Output Speed (max eff.): 18 rpm | Output Torque (max eff.): 1.1 kgf·cm | No-load Speed: 8000 rpm | Stall Torque: 32 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 26.1 mm | Type: DC planetary geared motor
K16-0370-KD1627R1 GGM K16-1627 DC 12V planetary geared motor, ratio 1/370, 15 rpm / 1.3 kgf·cm @ max eff. GGM Motor: KD1627R1 | Voltage: DC 12V | Gear Ratio: 1/370 | Output Speed (max eff.): 15 rpm | Output Torque (max eff.): 1.3 kgf·cm | No-load Speed: 8000 rpm | Stall Torque: 32 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 26.1 mm | Type: DC planetary geared motor
K16-0455-KD1627R1 GGM K16-1627 DC 12V planetary geared motor, ratio 1/455, 13 rpm / 1.6 kgf·cm @ max eff. GGM Motor: KD1627R1 | Voltage: DC 12V | Gear Ratio: 1/455 | Output Speed (max eff.): 13 rpm | Output Torque (max eff.): 1.6 kgf·cm | No-load Speed: 8000 rpm | Stall Torque: 32 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 26.1 mm | Type: DC planetary geared motor
K16-0561-KD1627R1 GGM K16-1627 DC 12V planetary geared motor, ratio 1/561, 10.4 rpm / 1.96 kgf·cm @ max eff. GGM Motor: KD1627R1 | Voltage: DC 12V | Gear Ratio: 1/561 | Output Speed (max eff.): 10.4 rpm | Output Torque (max eff.): 1.96 kgf·cm | No-load Speed: 8000 rpm | Stall Torque: 32 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 26.1 mm | Type: DC planetary geared motor
K16-0690-KD1627R1 GGM K16-1627 DC 12V planetary geared motor, ratio 1/690, 8.5 rpm / 2.4 kgf·cm @ max eff. GGM Motor: KD1627R1 | Voltage: DC 12V | Gear Ratio: 1/690 | Output Speed (max eff.): 8.5 rpm | Output Torque (max eff.): 2.4 kgf·cm | No-load Speed: 8000 rpm | Stall Torque: 32 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 26.1 mm | Type: DC planetary geared motor
K16-0850-KD1627R1 GGM K16-1627 DC 12V planetary geared motor, ratio 1/850, 6.9 rpm / 2.9 kgf·cm @ max eff. GGM Motor: KD1627R1 | Voltage: DC 12V | Gear Ratio: 1/850 | Output Speed (max eff.): 6.9 rpm | Output Torque (max eff.): 2.9 kgf·cm | No-load Speed: 8000 rpm | Stall Torque: 32 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 26.1 mm | Type: DC planetary geared motor
K16-1014-KD1627R1 GGM K16-1627 DC 12V planetary geared motor, ratio 1/1014, 5.8 rpm / 3 kgf·cm @ max eff. GGM Motor: KD1627R1 | Voltage: DC 12V | Gear Ratio: 1/1014 | Output Speed (max eff.): 5.8 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 8000 rpm | Stall Torque: 32 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 29.8 mm | Type: DC planetary geared motor
K16-1249-KD1627R1 GGM K16-1627 DC 12V planetary geared motor, ratio 1/1249, 4.7 rpm / 3 kgf·cm @ max eff. GGM Motor: KD1627R1 | Voltage: DC 12V | Gear Ratio: 1/1249 | Output Speed (max eff.): 4.7 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 8000 rpm | Stall Torque: 32 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 29.8 mm | Type: DC planetary geared motor
K16-1621-KD1627R1 GGM K16-1627 DC 12V planetary geared motor, ratio 1/1621, 3.6 rpm / 3 kgf·cm @ max eff. GGM Motor: KD1627R1 | Voltage: DC 12V | Gear Ratio: 1/1621 | Output Speed (max eff.): 3.6 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 8000 rpm | Stall Torque: 32 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 29.8 mm | Type: DC planetary geared motor
K16-1996-KD1627R1 GGM K16-1627 DC 12V planetary geared motor, ratio 1/1996, 2.9 rpm / 3 kgf·cm @ max eff. GGM Motor: KD1627R1 | Voltage: DC 12V | Gear Ratio: 1/1996 | Output Speed (max eff.): 2.9 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 8000 rpm | Stall Torque: 32 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 29.8 mm | Type: DC planetary geared motor
K16-2458-KD1627R1 GGM K16-1627 DC 12V planetary geared motor, ratio 1/2458, 2.4 rpm / 3 kgf·cm @ max eff. GGM Motor: KD1627R1 | Voltage: DC 12V | Gear Ratio: 1/2458 | Output Speed (max eff.): 2.4 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 8000 rpm | Stall Torque: 32 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 29.8 mm | Type: DC planetary geared motor
K16-3027-KD1627R1 GGM K16-1627 DC 12V planetary geared motor, ratio 1/3027, 1.9 rpm / 3 kgf·cm @ max eff. GGM Motor: KD1627R1 | Voltage: DC 12V | Gear Ratio: 1/3027 | Output Speed (max eff.): 1.9 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 8000 rpm | Stall Torque: 32 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 29.8 mm | Type: DC planetary geared motor
K16-3728-KD1627R1 GGM K16-1627 DC 12V planetary geared motor, ratio 1/3728, 1.5 rpm / 3 kgf·cm @ max eff. GGM Motor: KD1627R1 | Voltage: DC 12V | Gear Ratio: 1/3728 | Output Speed (max eff.): 1.5 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 8000 rpm | Stall Torque: 32 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 29.8 mm | Type: DC planetary geared motor
K16-4592-KD1627R1 GGM K16-1627 DC 12V planetary geared motor, ratio 1/4592, 1.2 rpm / 3 kgf·cm @ max eff. GGM Motor: KD1627R1 | Voltage: DC 12V | Gear Ratio: 1/4592 | Output Speed (max eff.): 1.2 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 8000 rpm | Stall Torque: 32 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 29.8 mm | Type: DC planetary geared motor
K16-0004-KD1627M2 GGM K16-1627 DC 24V planetary geared motor, ratio 1/4, 2110 rpm / 0.04 kgf·cm @ max eff. GGM Motor: KD1627M2 | Voltage: DC 24V | Gear Ratio: 1/4 | Output Speed (max eff.): 2110 rpm | Output Torque (max eff.): 0.04 kgf·cm | No-load Speed: 13500 rpm | Stall Torque: 47.6 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 15 mm | Type: DC planetary geared motor
K16-0014-KD1627M2 GGM K16-1627 DC 24V planetary geared motor, ratio 1/14, 600 rpm / 0.12 kgf·cm @ max eff. GGM Motor: KD1627M2 | Voltage: DC 24V | Gear Ratio: 1/14 | Output Speed (max eff.): 600 rpm | Output Torque (max eff.): 0.12 kgf·cm | No-load Speed: 13500 rpm | Stall Torque: 47.6 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 18.7 mm | Type: DC planetary geared motor
K16-0016-KD1627M2 GGM K16-1627 DC 24V planetary geared motor, ratio 1/16, 528 rpm / 0.14 kgf·cm @ max eff. GGM Motor: KD1627M2 | Voltage: DC 24V | Gear Ratio: 1/16 | Output Speed (max eff.): 528 rpm | Output Torque (max eff.): 0.14 kgf·cm | No-load Speed: 13500 rpm | Stall Torque: 47.6 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 18.7 mm | Type: DC planetary geared motor
K16-0019-KD1627M2 GGM K16-1627 DC 24V planetary geared motor, ratio 1/19, 444 rpm / 0.16 kgf·cm @ max eff. GGM Motor: KD1627M2 | Voltage: DC 24V | Gear Ratio: 1/19 | Output Speed (max eff.): 444 rpm | Output Torque (max eff.): 0.16 kgf·cm | No-load Speed: 13500 rpm | Stall Torque: 47.6 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 18.7 mm | Type: DC planetary geared motor
K16-0029-KD1627M2 GGM K16-1627 DC 24V planetary geared motor, ratio 1/29, 291 rpm / 0.25 kgf·cm @ max eff. GGM Motor: KD1627M2 | Voltage: DC 24V | Gear Ratio: 1/29 | Output Speed (max eff.): 291 rpm | Output Torque (max eff.): 0.25 kgf·cm | No-load Speed: 13500 rpm | Stall Torque: 47.6 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 18.7 mm | Type: DC planetary geared motor
K16-0053-KD1627M2 GGM K16-1627 DC 24V planetary geared motor, ratio 1/53, 159 rpm / 0.37 kgf·cm @ max eff. GGM Motor: KD1627M2 | Voltage: DC 24V | Gear Ratio: 1/53 | Output Speed (max eff.): 159 rpm | Output Torque (max eff.): 0.37 kgf·cm | No-load Speed: 13500 rpm | Stall Torque: 47.6 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 22.4 mm | Type: DC planetary geared motor
K16-0062-KD1627M2 GGM K16-1627 DC 24V planetary geared motor, ratio 1/62, 136 rpm / 0.43 kgf·cm @ max eff. GGM Motor: KD1627M2 | Voltage: DC 24V | Gear Ratio: 1/62 | Output Speed (max eff.): 136 rpm | Output Torque (max eff.): 0.43 kgf·cm | No-load Speed: 13500 rpm | Stall Torque: 47.6 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 22.4 mm | Type: DC planetary geared motor
K16-0072-KD1627M2 GGM K16-1627 DC 24V planetary geared motor, ratio 1/72, 117 rpm / 0.49 kgf·cm @ max eff. GGM Motor: KD1627M2 | Voltage: DC 24V | Gear Ratio: 1/72 | Output Speed (max eff.): 117 rpm | Output Torque (max eff.): 0.49 kgf·cm | No-load Speed: 13500 rpm | Stall Torque: 47.6 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 22.4 mm | Type: DC planetary geared motor
K16-0084-KD1627M2 GGM K16-1627 DC 24V planetary geared motor, ratio 1/84, 100 rpm / 0.58 kgf·cm @ max eff. GGM Motor: KD1627M2 | Voltage: DC 24V | Gear Ratio: 1/84 | Output Speed (max eff.): 100 rpm | Output Torque (max eff.): 0.58 kgf·cm | No-load Speed: 13500 rpm | Stall Torque: 47.6 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 22.4 mm | Type: DC planetary geared motor
K16-0104-KD1627M2 GGM K16-1627 DC 24V planetary geared motor, ratio 1/104, 81 rpm / 0.72 kgf·cm @ max eff. GGM Motor: KD1627M2 | Voltage: DC 24V | Gear Ratio: 1/104 | Output Speed (max eff.): 81 rpm | Output Torque (max eff.): 0.72 kgf·cm | No-load Speed: 13500 rpm | Stall Torque: 47.6 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 22.4 mm | Type: DC planetary geared motor
K16-0128-KD1627M2 GGM K16-1627 DC 24V planetary geared motor, ratio 1/128, 66 rpm / 0.88 kgf·cm @ max eff. GGM Motor: KD1627M2 | Voltage: DC 24V | Gear Ratio: 1/128 | Output Speed (max eff.): 66 rpm | Output Torque (max eff.): 0.88 kgf·cm | No-load Speed: 13500 rpm | Stall Torque: 47.6 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 22.4 mm | Type: DC planetary geared motor
K16-0157-KD1627M2 GGM K16-1627 DC 24V planetary geared motor, ratio 1/157, 53 rpm / 1.08 kgf·cm @ max eff. GGM Motor: KD1627M2 | Voltage: DC 24V | Gear Ratio: 1/157 | Output Speed (max eff.): 53 rpm | Output Torque (max eff.): 1.08 kgf·cm | No-load Speed: 13500 rpm | Stall Torque: 47.6 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 22.4 mm | Type: DC planetary geared motor
K16-0198-KD1627M2 GGM K16-1627 DC 24V planetary geared motor, ratio 1/198, 42 rpm / 1.1 kgf·cm @ max eff. GGM Motor: KD1627M2 | Voltage: DC 24V | Gear Ratio: 1/198 | Output Speed (max eff.): 42 rpm | Output Torque (max eff.): 1.1 kgf·cm | No-load Speed: 13500 rpm | Stall Torque: 47.6 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 26.1 mm | Type: DC planetary geared motor
K16-0231-KD1627M2 GGM K16-1627 DC 24V planetary geared motor, ratio 1/231, 36 rpm / 1.3 kgf·cm @ max eff. GGM Motor: KD1627M2 | Voltage: DC 24V | Gear Ratio: 1/231 | Output Speed (max eff.): 36 rpm | Output Torque (max eff.): 1.3 kgf·cm | No-load Speed: 13500 rpm | Stall Torque: 47.6 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 26.1 mm | Type: DC planetary geared motor
K16-0270-KD1627M2 GGM K16-1627 DC 24V planetary geared motor, ratio 1/270, 31 rpm / 1.5 kgf·cm @ max eff. GGM Motor: KD1627M2 | Voltage: DC 24V | Gear Ratio: 1/270 | Output Speed (max eff.): 31 rpm | Output Torque (max eff.): 1.5 kgf·cm | No-load Speed: 13500 rpm | Stall Torque: 47.6 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 26.1 mm | Type: DC planetary geared motor
K16-0316-KD1627M2 GGM K16-1627 DC 24V planetary geared motor, ratio 1/316, 26 rpm / 1.7 kgf·cm @ max eff. GGM Motor: KD1627M2 | Voltage: DC 24V | Gear Ratio: 1/316 | Output Speed (max eff.): 26 rpm | Output Torque (max eff.): 1.7 kgf·cm | No-load Speed: 13500 rpm | Stall Torque: 47.6 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 26.1 mm | Type: DC planetary geared motor
K16-0370-KD1627M2 GGM K16-1627 DC 24V planetary geared motor, ratio 1/370, 22 rpm / 2.1 kgf·cm @ max eff. GGM Motor: KD1627M2 | Voltage: DC 24V | Gear Ratio: 1/370 | Output Speed (max eff.): 22 rpm | Output Torque (max eff.): 2.1 kgf·cm | No-load Speed: 13500 rpm | Stall Torque: 47.6 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 26.1 mm | Type: DC planetary geared motor
K16-0455-KD1627M2 GGM K16-1627 DC 24V planetary geared motor, ratio 1/455, 18.5 rpm / 2.5 kgf·cm @ max eff. GGM Motor: KD1627M2 | Voltage: DC 24V | Gear Ratio: 1/455 | Output Speed (max eff.): 18.5 rpm | Output Torque (max eff.): 2.5 kgf·cm | No-load Speed: 13500 rpm | Stall Torque: 47.6 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 26.1 mm | Type: DC planetary geared motor
K16-0561-KD1627M2 GGM K16-1627 DC 24V planetary geared motor, ratio 1/561, 15 rpm / 3 kgf·cm @ max eff. GGM Motor: KD1627M2 | Voltage: DC 24V | Gear Ratio: 1/561 | Output Speed (max eff.): 15 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 13500 rpm | Stall Torque: 47.6 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 26.1 mm | Type: DC planetary geared motor
K16-0690-KD1627M2 GGM K16-1627 DC 24V planetary geared motor, ratio 1/690, 12.2 rpm / 3 kgf·cm @ max eff. GGM Motor: KD1627M2 | Voltage: DC 24V | Gear Ratio: 1/690 | Output Speed (max eff.): 12.2 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 13500 rpm | Stall Torque: 47.6 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 26.1 mm | Type: DC planetary geared motor
K16-0850-KD1627M2 GGM K16-1627 DC 24V planetary geared motor, ratio 1/850, 9.9 rpm / 3 kgf·cm @ max eff. GGM Motor: KD1627M2 | Voltage: DC 24V | Gear Ratio: 1/850 | Output Speed (max eff.): 9.9 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 13500 rpm | Stall Torque: 47.6 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 26.1 mm | Type: DC planetary geared motor
K16-1014-KD1627M2 GGM K16-1627 DC 24V planetary geared motor, ratio 1/1014, 8.3 rpm / 3 kgf·cm @ max eff. GGM Motor: KD1627M2 | Voltage: DC 24V | Gear Ratio: 1/1014 | Output Speed (max eff.): 8.3 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 13500 rpm | Stall Torque: 47.6 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 29.8 mm | Type: DC planetary geared motor
K16-1249-KD1627M2 GGM K16-1627 DC 24V planetary geared motor, ratio 1/1249, 6.7 rpm / 3 kgf·cm @ max eff. GGM Motor: KD1627M2 | Voltage: DC 24V | Gear Ratio: 1/1249 | Output Speed (max eff.): 6.7 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 13500 rpm | Stall Torque: 47.6 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 29.8 mm | Type: DC planetary geared motor
K16-1621-KD1627M2 GGM K16-1627 DC 24V planetary geared motor, ratio 1/1621, 5.2 rpm / 3 kgf·cm @ max eff. GGM Motor: KD1627M2 | Voltage: DC 24V | Gear Ratio: 1/1621 | Output Speed (max eff.): 5.2 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 13500 rpm | Stall Torque: 47.6 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 29.8 mm | Type: DC planetary geared motor
K16-1996-KD1627M2 GGM K16-1627 DC 24V planetary geared motor, ratio 1/1996, 4.2 rpm / 3 kgf·cm @ max eff. GGM Motor: KD1627M2 | Voltage: DC 24V | Gear Ratio: 1/1996 | Output Speed (max eff.): 4.2 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 13500 rpm | Stall Torque: 47.6 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 29.8 mm | Type: DC planetary geared motor
K16-2458-KD1627M2 GGM K16-1627 DC 24V planetary geared motor, ratio 1/2458, 3.4 rpm / 3 kgf·cm @ max eff. GGM Motor: KD1627M2 | Voltage: DC 24V | Gear Ratio: 1/2458 | Output Speed (max eff.): 3.4 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 13500 rpm | Stall Torque: 47.6 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 29.8 mm | Type: DC planetary geared motor
K16-3027-KD1627M2 GGM K16-1627 DC 24V planetary geared motor, ratio 1/3027, 2.8 rpm / 3 kgf·cm @ max eff. GGM Motor: KD1627M2 | Voltage: DC 24V | Gear Ratio: 1/3027 | Output Speed (max eff.): 2.8 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 13500 rpm | Stall Torque: 47.6 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 29.8 mm | Type: DC planetary geared motor
K16-3728-KD1627M2 GGM K16-1627 DC 24V planetary geared motor, ratio 1/3728, 2.2 rpm / 3 kgf·cm @ max eff. GGM Motor: KD1627M2 | Voltage: DC 24V | Gear Ratio: 1/3728 | Output Speed (max eff.): 2.2 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 13500 rpm | Stall Torque: 47.6 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 29.8 mm | Type: DC planetary geared motor
K16-4592-KD1627M2 GGM K16-1627 DC 24V planetary geared motor, ratio 1/4592, 1.8 rpm / 3 kgf·cm @ max eff. GGM Motor: KD1627M2 | Voltage: DC 24V | Gear Ratio: 1/4592 | Output Speed (max eff.): 1.8 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 13500 rpm | Stall Torque: 47.6 gf·cm | Frame: ø16mm | Output Shaft: ø3mm, 2-M2 TAP DP5 | Gearhead Length L: 29.8 mm | Type: DC planetary geared motor
