[GGM] — K22-2032 Series DC Planetary Geared Motor (ø22mm, 12/24V, 1/4–1/1996)
DC GGM

[GGM] — K22-2032 Series DC Planetary Geared Motor (ø22mm, 12/24V, 1/4–1/1996)

Family ID: GGM-K22-2032

GGM K22-2032 DC planetary geared motor, ø22mm round frame, ø4mm shaft, 4-M2 flange mount (PCD ø18). Two windings (12V/24V), 20 planetary ratios 1/4 to 1/1996; 32g.

40 product codes available in this family

RFQ Cart (0)

Product Codes & Specifications

Product Code Description Brand Spec
K22-0004-KD2032R1 GGM K22-2032 DC 12V planetary geared motor, ratio 1/4, 1600 rpm / 0.07 kgf·cm @ max eff. GGM Motor: KD2032R1 | Voltage: DC 12V | Gear Ratio: 1/4 | Output Speed (max eff.): 1600 rpm | Output Torque (max eff.): 0.07 kgf·cm | No-load Speed: 8000 rpm | Stall Torque: 121 gf·cm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 14.4 mm | Type: DC planetary geared motor
K22-0014-KD2032R1 GGM K22-2032 DC 12V planetary geared motor, ratio 1/14, 457 rpm / 0.2 kgf·cm @ max eff. GGM Motor: KD2032R1 | Voltage: DC 12V | Gear Ratio: 1/14 | Output Speed (max eff.): 457 rpm | Output Torque (max eff.): 0.2 kgf·cm | No-load Speed: 8000 rpm | Stall Torque: 121 gf·cm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 18.05 mm | Type: DC planetary geared motor
K22-0016-KD2032R1 GGM K22-2032 DC 12V planetary geared motor, ratio 1/16, 400 rpm / 0.23 kgf·cm @ max eff. GGM Motor: KD2032R1 | Voltage: DC 12V | Gear Ratio: 1/16 | Output Speed (max eff.): 400 rpm | Output Torque (max eff.): 0.23 kgf·cm | No-load Speed: 8000 rpm | Stall Torque: 121 gf·cm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 18.05 mm | Type: DC planetary geared motor
K22-0019-KD2032R1 GGM K22-2032 DC 12V planetary geared motor, ratio 1/19, 337 rpm / 0.27 kgf·cm @ max eff. GGM Motor: KD2032R1 | Voltage: DC 12V | Gear Ratio: 1/19 | Output Speed (max eff.): 337 rpm | Output Torque (max eff.): 0.27 kgf·cm | No-load Speed: 8000 rpm | Stall Torque: 121 gf·cm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 18.05 mm | Type: DC planetary geared motor
K22-0053-KD2032R1 GGM K22-2032 DC 12V planetary geared motor, ratio 1/53, 121 rpm / 0.6 kgf·cm @ max eff. GGM Motor: KD2032R1 | Voltage: DC 12V | Gear Ratio: 1/53 | Output Speed (max eff.): 121 rpm | Output Torque (max eff.): 0.6 kgf·cm | No-load Speed: 8000 rpm | Stall Torque: 121 gf·cm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 21.7 mm | Type: DC planetary geared motor
K22-0062-KD2032R1 GGM K22-2032 DC 12V planetary geared motor, ratio 1/62, 103 rpm / 0.7 kgf·cm @ max eff. GGM Motor: KD2032R1 | Voltage: DC 12V | Gear Ratio: 1/62 | Output Speed (max eff.): 103 rpm | Output Torque (max eff.): 0.7 kgf·cm | No-load Speed: 8000 rpm | Stall Torque: 121 gf·cm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 21.7 mm | Type: DC planetary geared motor
K22-0072-KD2032R1 GGM K22-2032 DC 12V planetary geared motor, ratio 1/72, 89 rpm / 0.8 kgf·cm @ max eff. GGM Motor: KD2032R1 | Voltage: DC 12V | Gear Ratio: 1/72 | Output Speed (max eff.): 89 rpm | Output Torque (max eff.): 0.8 kgf·cm | No-load Speed: 8000 rpm | Stall Torque: 121 gf·cm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 21.7 mm | Type: DC planetary geared motor
K22-0084-KD2032R1 GGM K22-2032 DC 12V planetary geared motor, ratio 1/84, 76 rpm / 1 kgf·cm @ max eff. GGM Motor: KD2032R1 | Voltage: DC 12V | Gear Ratio: 1/84 | Output Speed (max eff.): 76 rpm | Output Torque (max eff.): 1 kgf·cm | No-load Speed: 8000 rpm | Stall Torque: 121 gf·cm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 21.7 mm | Type: DC planetary geared motor
K22-0104-KD2032R1 GGM K22-2032 DC 12V planetary geared motor, ratio 1/104, 62 rpm / 1.2 kgf·cm @ max eff. GGM Motor: KD2032R1 | Voltage: DC 12V | Gear Ratio: 1/104 | Output Speed (max eff.): 62 rpm | Output Torque (max eff.): 1.2 kgf·cm | No-load Speed: 8000 rpm | Stall Torque: 121 gf·cm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 21.7 mm | Type: DC planetary geared motor
K22-0198-KD2032R1 GGM K22-2032 DC 12V planetary geared motor, ratio 1/198, 32 rpm / 1.9 kgf·cm @ max eff. GGM Motor: KD2032R1 | Voltage: DC 12V | Gear Ratio: 1/198 | Output Speed (max eff.): 32 rpm | Output Torque (max eff.): 1.9 kgf·cm | No-load Speed: 8000 rpm | Stall Torque: 121 gf·cm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 25.35 mm | Type: DC planetary geared motor
K22-0231-KD2032R1 GGM K22-2032 DC 12V planetary geared motor, ratio 1/231, 28 rpm / 2.2 kgf·cm @ max eff. GGM Motor: KD2032R1 | Voltage: DC 12V | Gear Ratio: 1/231 | Output Speed (max eff.): 28 rpm | Output Torque (max eff.): 2.2 kgf·cm | No-load Speed: 8000 rpm | Stall Torque: 121 gf·cm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 25.35 mm | Type: DC planetary geared motor
K22-0270-KD2032R1 GGM K22-2032 DC 12V planetary geared motor, ratio 1/270, 23.7 rpm / 2.6 kgf·cm @ max eff. GGM Motor: KD2032R1 | Voltage: DC 12V | Gear Ratio: 1/270 | Output Speed (max eff.): 23.7 rpm | Output Torque (max eff.): 2.6 kgf·cm | No-load Speed: 8000 rpm | Stall Torque: 121 gf·cm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 25.35 mm | Type: DC planetary geared motor
K22-0316-KD2032R1 GGM K22-2032 DC 12V planetary geared motor, ratio 1/316, 20.2 rpm / 3 kgf·cm @ max eff. GGM Motor: KD2032R1 | Voltage: DC 12V | Gear Ratio: 1/316 | Output Speed (max eff.): 20.2 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 8000 rpm | Stall Torque: 121 gf·cm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 25.35 mm | Type: DC planetary geared motor
K22-0370-KD2032R1 GGM K22-2032 DC 12V planetary geared motor, ratio 1/370, 17.3 rpm / 3 kgf·cm @ max eff. GGM Motor: KD2032R1 | Voltage: DC 12V | Gear Ratio: 1/370 | Output Speed (max eff.): 17.3 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 8000 rpm | Stall Torque: 121 gf·cm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 25.35 mm | Type: DC planetary geared motor
K22-0455-KD2032R1 GGM K22-2032 DC 12V planetary geared motor, ratio 1/455, 14 rpm / 3 kgf·cm @ max eff. GGM Motor: KD2032R1 | Voltage: DC 12V | Gear Ratio: 1/455 | Output Speed (max eff.): 14 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 8000 rpm | Stall Torque: 121 gf·cm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 25.35 mm | Type: DC planetary geared motor
K22-0742-KD2032R1 GGM K22-2032 DC 12V planetary geared motor, ratio 1/742, 8.6 rpm / 3 kgf·cm @ max eff. GGM Motor: KD2032R1 | Voltage: DC 12V | Gear Ratio: 1/742 | Output Speed (max eff.): 8.6 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 8000 rpm | Stall Torque: 121 gf·cm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 29 mm | Type: DC planetary geared motor
K22-1014-KD2032R1 GGM K22-2032 DC 12V planetary geared motor, ratio 1/1014, 6.3 rpm / 3 kgf·cm @ max eff. GGM Motor: KD2032R1 | Voltage: DC 12V | Gear Ratio: 1/1014 | Output Speed (max eff.): 6.3 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 8000 rpm | Stall Torque: 121 gf·cm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 29 mm | Type: DC planetary geared motor
K22-1249-KD2032R1 GGM K22-2032 DC 12V planetary geared motor, ratio 1/1249, 5.1 rpm / 3 kgf·cm @ max eff. GGM Motor: KD2032R1 | Voltage: DC 12V | Gear Ratio: 1/1249 | Output Speed (max eff.): 5.1 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 8000 rpm | Stall Torque: 121 gf·cm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 29 mm | Type: DC planetary geared motor
K22-1621-KD2032R1 GGM K22-2032 DC 12V planetary geared motor, ratio 1/1621, 3.9 rpm / 3 kgf·cm @ max eff. GGM Motor: KD2032R1 | Voltage: DC 12V | Gear Ratio: 1/1621 | Output Speed (max eff.): 3.9 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 8000 rpm | Stall Torque: 121 gf·cm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 29 mm | Type: DC planetary geared motor
K22-1996-KD2032R1 GGM K22-2032 DC 12V planetary geared motor, ratio 1/1996, 3.2 rpm / 3 kgf·cm @ max eff. GGM Motor: KD2032R1 | Voltage: DC 12V | Gear Ratio: 1/1996 | Output Speed (max eff.): 3.2 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 8000 rpm | Stall Torque: 121 gf·cm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 29 mm | Type: DC planetary geared motor
K22-0004-KD2032P2 GGM K22-2032 DC 24V planetary geared motor, ratio 1/4, 1850 rpm / 0.07 kgf·cm @ max eff. GGM Motor: KD2032P2 | Voltage: DC 24V | Gear Ratio: 1/4 | Output Speed (max eff.): 1850 rpm | Output Torque (max eff.): 0.07 kgf·cm | No-load Speed: 9000 rpm | Stall Torque: 136 gf·cm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 14.4 mm | Type: DC planetary geared motor
K22-0014-KD2032P2 GGM K22-2032 DC 24V planetary geared motor, ratio 1/14, 528 rpm / 0.2 kgf·cm @ max eff. GGM Motor: KD2032P2 | Voltage: DC 24V | Gear Ratio: 1/14 | Output Speed (max eff.): 528 rpm | Output Torque (max eff.): 0.2 kgf·cm | No-load Speed: 9000 rpm | Stall Torque: 136 gf·cm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 18.05 mm | Type: DC planetary geared motor
K22-0016-KD2032P2 GGM K22-2032 DC 24V planetary geared motor, ratio 1/16, 462 rpm / 0.23 kgf·cm @ max eff. GGM Motor: KD2032P2 | Voltage: DC 24V | Gear Ratio: 1/16 | Output Speed (max eff.): 462 rpm | Output Torque (max eff.): 0.23 kgf·cm | No-load Speed: 9000 rpm | Stall Torque: 136 gf·cm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 18.05 mm | Type: DC planetary geared motor
K22-0019-KD2032P2 GGM K22-2032 DC 24V planetary geared motor, ratio 1/19, 390 rpm / 0.27 kgf·cm @ max eff. GGM Motor: KD2032P2 | Voltage: DC 24V | Gear Ratio: 1/19 | Output Speed (max eff.): 390 rpm | Output Torque (max eff.): 0.27 kgf·cm | No-load Speed: 9000 rpm | Stall Torque: 136 gf·cm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 18.05 mm | Type: DC planetary geared motor
K22-0053-KD2032P2 GGM K22-2032 DC 24V planetary geared motor, ratio 1/53, 140 rpm / 0.6 kgf·cm @ max eff. GGM Motor: KD2032P2 | Voltage: DC 24V | Gear Ratio: 1/53 | Output Speed (max eff.): 140 rpm | Output Torque (max eff.): 0.6 kgf·cm | No-load Speed: 9000 rpm | Stall Torque: 136 gf·cm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 21.7 mm | Type: DC planetary geared motor
K22-0062-KD2032P2 GGM K22-2032 DC 24V planetary geared motor, ratio 1/62, 119 rpm / 0.7 kgf·cm @ max eff. GGM Motor: KD2032P2 | Voltage: DC 24V | Gear Ratio: 1/62 | Output Speed (max eff.): 119 rpm | Output Torque (max eff.): 0.7 kgf·cm | No-load Speed: 9000 rpm | Stall Torque: 136 gf·cm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 21.7 mm | Type: DC planetary geared motor
K22-0072-KD2032P2 GGM K22-2032 DC 24V planetary geared motor, ratio 1/72, 103 rpm / 0.8 kgf·cm @ max eff. GGM Motor: KD2032P2 | Voltage: DC 24V | Gear Ratio: 1/72 | Output Speed (max eff.): 103 rpm | Output Torque (max eff.): 0.8 kgf·cm | No-load Speed: 9000 rpm | Stall Torque: 136 gf·cm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 21.7 mm | Type: DC planetary geared motor
K22-0084-KD2032P2 GGM K22-2032 DC 24V planetary geared motor, ratio 1/84, 88 rpm / 1 kgf·cm @ max eff. GGM Motor: KD2032P2 | Voltage: DC 24V | Gear Ratio: 1/84 | Output Speed (max eff.): 88 rpm | Output Torque (max eff.): 1 kgf·cm | No-load Speed: 9000 rpm | Stall Torque: 136 gf·cm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 21.7 mm | Type: DC planetary geared motor
K22-0104-KD2032P2 GGM K22-2032 DC 24V planetary geared motor, ratio 1/104, 71 rpm / 1.2 kgf·cm @ max eff. GGM Motor: KD2032P2 | Voltage: DC 24V | Gear Ratio: 1/104 | Output Speed (max eff.): 71 rpm | Output Torque (max eff.): 1.2 kgf·cm | No-load Speed: 9000 rpm | Stall Torque: 136 gf·cm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 21.7 mm | Type: DC planetary geared motor
K22-0198-KD2032P2 GGM K22-2032 DC 24V planetary geared motor, ratio 1/198, 37 rpm / 1.9 kgf·cm @ max eff. GGM Motor: KD2032P2 | Voltage: DC 24V | Gear Ratio: 1/198 | Output Speed (max eff.): 37 rpm | Output Torque (max eff.): 1.9 kgf·cm | No-load Speed: 9000 rpm | Stall Torque: 136 gf·cm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 25.35 mm | Type: DC planetary geared motor
K22-0231-KD2032P2 GGM K22-2032 DC 24V planetary geared motor, ratio 1/231, 32 rpm / 2.2 kgf·cm @ max eff. GGM Motor: KD2032P2 | Voltage: DC 24V | Gear Ratio: 1/231 | Output Speed (max eff.): 32 rpm | Output Torque (max eff.): 2.2 kgf·cm | No-load Speed: 9000 rpm | Stall Torque: 136 gf·cm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 25.35 mm | Type: DC planetary geared motor
K22-0270-KD2032P2 GGM K22-2032 DC 24V planetary geared motor, ratio 1/270, 27.4 rpm / 2.6 kgf·cm @ max eff. GGM Motor: KD2032P2 | Voltage: DC 24V | Gear Ratio: 1/270 | Output Speed (max eff.): 27.4 rpm | Output Torque (max eff.): 2.6 kgf·cm | No-load Speed: 9000 rpm | Stall Torque: 136 gf·cm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 25.35 mm | Type: DC planetary geared motor
K22-0316-KD2032P2 GGM K22-2032 DC 24V planetary geared motor, ratio 1/316, 23.4 rpm / 3 kgf·cm @ max eff. GGM Motor: KD2032P2 | Voltage: DC 24V | Gear Ratio: 1/316 | Output Speed (max eff.): 23.4 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 9000 rpm | Stall Torque: 136 gf·cm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 25.35 mm | Type: DC planetary geared motor
K22-0370-KD2032P2 GGM K22-2032 DC 24V planetary geared motor, ratio 1/370, 20 rpm / 3 kgf·cm @ max eff. GGM Motor: KD2032P2 | Voltage: DC 24V | Gear Ratio: 1/370 | Output Speed (max eff.): 20 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 9000 rpm | Stall Torque: 136 gf·cm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 25.35 mm | Type: DC planetary geared motor
K22-0455-KD2032P2 GGM K22-2032 DC 24V planetary geared motor, ratio 1/455, 16.3 rpm / 3 kgf·cm @ max eff. GGM Motor: KD2032P2 | Voltage: DC 24V | Gear Ratio: 1/455 | Output Speed (max eff.): 16.3 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 9000 rpm | Stall Torque: 136 gf·cm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 25.35 mm | Type: DC planetary geared motor
K22-0742-KD2032P2 GGM K22-2032 DC 24V planetary geared motor, ratio 1/742, 10 rpm / 3 kgf·cm @ max eff. GGM Motor: KD2032P2 | Voltage: DC 24V | Gear Ratio: 1/742 | Output Speed (max eff.): 10 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 9000 rpm | Stall Torque: 136 gf·cm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 29 mm | Type: DC planetary geared motor
K22-1014-KD2032P2 GGM K22-2032 DC 24V planetary geared motor, ratio 1/1014, 7.3 rpm / 3 kgf·cm @ max eff. GGM Motor: KD2032P2 | Voltage: DC 24V | Gear Ratio: 1/1014 | Output Speed (max eff.): 7.3 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 9000 rpm | Stall Torque: 136 gf·cm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 29 mm | Type: DC planetary geared motor
K22-1249-KD2032P2 GGM K22-2032 DC 24V planetary geared motor, ratio 1/1249, 5.9 rpm / 3 kgf·cm @ max eff. GGM Motor: KD2032P2 | Voltage: DC 24V | Gear Ratio: 1/1249 | Output Speed (max eff.): 5.9 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 9000 rpm | Stall Torque: 136 gf·cm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 29 mm | Type: DC planetary geared motor
K22-1621-KD2032P2 GGM K22-2032 DC 24V planetary geared motor, ratio 1/1621, 4.6 rpm / 3 kgf·cm @ max eff. GGM Motor: KD2032P2 | Voltage: DC 24V | Gear Ratio: 1/1621 | Output Speed (max eff.): 4.6 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 9000 rpm | Stall Torque: 136 gf·cm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 29 mm | Type: DC planetary geared motor
K22-1996-KD2032P2 GGM K22-2032 DC 24V planetary geared motor, ratio 1/1996, 3.7 rpm / 3 kgf·cm @ max eff. GGM Motor: KD2032P2 | Voltage: DC 24V | Gear Ratio: 1/1996 | Output Speed (max eff.): 3.7 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 9000 rpm | Stall Torque: 136 gf·cm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 29 mm | Type: DC planetary geared motor
