[GGM] — KGC-2847-T1 DC Spur-Gear Geared Motor (ø34mm motor, 12V, 1/2–1/2430)
DC GGM

[GGM] — KGC-2847-T1 DC Spur-Gear Geared Motor (ø34mm motor, 12V, 1/2–1/2430)

Family ID: GGM-KGC-2847-T1

GGM KGC-2847 DC spur-gear geared motor (motor KD2847T1), ø34mm motor, ø6mm output shaft, 3-M3 flange (PCD ø31). DC 12V, 33 ratios 1/2 to 1/2430; motor 110g. Output rotation varies by gear train (same/reversed vs motor per catalog).

33 product codes available in this family

RFQ Cart (0)

Product Codes & Specifications

Product Code Description Brand Spec
KGC-0002-KD2847T1 GGM KGC-2847 DC 12V spur-gear geared motor, ratio 1/2, 3150 rpm / 0.12 kgf·cm @ max eff. GGM Motor: KD2847T1 | Voltage: DC 12V | Gear Ratio: 1/2 | Output Speed (max eff.): 3150 rpm | Output Torque (max eff.): 0.12 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 830 gf·cm | Gearhead Length L1: 21 mm | Overall Length L2: 96.6 mm | Output Shaft: ø6mm, 3-M3 flange (PCD ø31) | Type: DC spur-gear geared motor
KGC-0003-KD2847T1 GGM KGC-2847 DC 12V spur-gear geared motor, ratio 1/3, 2100 rpm / 0.17 kgf·cm @ max eff. GGM Motor: KD2847T1 | Voltage: DC 12V | Gear Ratio: 1/3 | Output Speed (max eff.): 2100 rpm | Output Torque (max eff.): 0.17 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 830 gf·cm | Gearhead Length L1: 21 mm | Overall Length L2: 96.6 mm | Output Shaft: ø6mm, 3-M3 flange (PCD ø31) | Type: DC spur-gear geared motor
KGC-0005-KD2847T1 GGM KGC-2847 DC 12V spur-gear geared motor, ratio 1/5, 1260 rpm / 0.29 kgf·cm @ max eff. GGM Motor: KD2847T1 | Voltage: DC 12V | Gear Ratio: 1/5 | Output Speed (max eff.): 1260 rpm | Output Torque (max eff.): 0.29 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 830 gf·cm | Gearhead Length L1: 21 mm | Overall Length L2: 96.6 mm | Output Shaft: ø6mm, 3-M3 flange (PCD ø31) | Type: DC spur-gear geared motor
KGC-0010-KD2847T1 GGM KGC-2847 DC 12V spur-gear geared motor, ratio 1/10, 630 rpm / 0.58 kgf·cm @ max eff. GGM Motor: KD2847T1 | Voltage: DC 12V | Gear Ratio: 1/10 | Output Speed (max eff.): 630 rpm | Output Torque (max eff.): 0.58 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 830 gf·cm | Gearhead Length L1: 21 mm | Overall Length L2: 96.6 mm | Output Shaft: ø6mm, 3-M3 flange (PCD ø31) | Type: DC spur-gear geared motor
KGC-0015-KD2847T1 GGM KGC-2847 DC 12V spur-gear geared motor, ratio 1/15, 420 rpm / 0.79 kgf·cm @ max eff. GGM Motor: KD2847T1 | Voltage: DC 12V | Gear Ratio: 1/15 | Output Speed (max eff.): 420 rpm | Output Torque (max eff.): 0.79 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 830 gf·cm | Gearhead Length L1: 21 mm | Overall Length L2: 96.6 mm | Output Shaft: ø6mm, 3-M3 flange (PCD ø31) | Type: DC spur-gear geared motor
KGC-0020-KD2847T1 GGM KGC-2847 DC 12V spur-gear geared motor, ratio 1/20, 315 rpm / 1.05 kgf·cm @ max eff. GGM Motor: KD2847T1 | Voltage: DC 12V | Gear Ratio: 1/20 | Output Speed (max eff.): 315 rpm | Output Torque (max eff.): 1.05 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 830 gf·cm | Gearhead Length L1: 21 mm | Overall Length L2: 96.6 mm | Output Shaft: ø6mm, 3-M3 flange (PCD ø31) | Type: DC spur-gear geared motor
KGC-0025-KD2847T1 GGM KGC-2847 DC 12V spur-gear geared motor, ratio 1/25, 252 rpm / 1.31 kgf·cm @ max eff. GGM Motor: KD2847T1 | Voltage: DC 12V | Gear Ratio: 1/25 | Output Speed (max eff.): 252 rpm | Output Torque (max eff.): 1.31 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 830 gf·cm | Gearhead Length L1: 21 mm | Overall Length L2: 96.6 mm | Output Shaft: ø6mm, 3-M3 flange (PCD ø31) | Type: DC spur-gear geared motor
KGC-0030-KD2847T1 GGM KGC-2847 DC 12V spur-gear geared motor, ratio 1/30, 210 rpm / 1.57 kgf·cm @ max eff. GGM Motor: KD2847T1 | Voltage: DC 12V | Gear Ratio: 1/30 | Output Speed (max eff.): 210 rpm | Output Torque (max eff.): 1.57 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 830 gf·cm | Gearhead Length L1: 21 mm | Overall Length L2: 96.6 mm | Output Shaft: ø6mm, 3-M3 flange (PCD ø31) | Type: DC spur-gear geared motor
KGC-0040-KD2847T1 GGM KGC-2847 DC 12V spur-gear geared motor, ratio 1/40, 157.5 rpm / 1.89 kgf·cm @ max eff. GGM Motor: KD2847T1 | Voltage: DC 12V | Gear Ratio: 1/40 | Output Speed (max eff.): 157.5 rpm | Output Torque (max eff.): 1.89 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 830 gf·cm | Gearhead Length L1: 29 mm | Overall Length L2: 104.6 mm | Output Shaft: ø6mm, 3-M3 flange (PCD ø31) | Type: DC spur-gear geared motor
KGC-0050-KD2847T1 GGM KGC-2847 DC 12V spur-gear geared motor, ratio 1/50, 126 rpm / 2.36 kgf·cm @ max eff. GGM Motor: KD2847T1 | Voltage: DC 12V | Gear Ratio: 1/50 | Output Speed (max eff.): 126 rpm | Output Torque (max eff.): 2.36 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 830 gf·cm | Gearhead Length L1: 29 mm | Overall Length L2: 104.6 mm | Output Shaft: ø6mm, 3-M3 flange (PCD ø31) | Type: DC spur-gear geared motor
KGC-0060-KD2847T1 GGM KGC-2847 DC 12V spur-gear geared motor, ratio 1/60, 105 rpm / 2.83 kgf·cm @ max eff. GGM Motor: KD2847T1 | Voltage: DC 12V | Gear Ratio: 1/60 | Output Speed (max eff.): 105 rpm | Output Torque (max eff.): 2.83 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 830 gf·cm | Gearhead Length L1: 29 mm | Overall Length L2: 104.6 mm | Output Shaft: ø6mm, 3-M3 flange (PCD ø31) | Type: DC spur-gear geared motor
KGC-0070-KD2847T1 GGM KGC-2847 DC 12V spur-gear geared motor, ratio 1/70, 90 rpm / 3.31 kgf·cm @ max eff. GGM Motor: KD2847T1 | Voltage: DC 12V | Gear Ratio: 1/70 | Output Speed (max eff.): 90 rpm | Output Torque (max eff.): 3.31 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 830 gf·cm | Gearhead Length L1: 29 mm | Overall Length L2: 104.6 mm | Output Shaft: ø6mm, 3-M3 flange (PCD ø31) | Type: DC spur-gear geared motor
KGC-0080-KD2847T1 GGM KGC-2847 DC 12V spur-gear geared motor, ratio 1/80, 78.8 rpm / 3.4 kgf·cm @ max eff. GGM Motor: KD2847T1 | Voltage: DC 12V | Gear Ratio: 1/80 | Output Speed (max eff.): 78.8 rpm | Output Torque (max eff.): 3.4 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 830 gf·cm | Gearhead Length L1: 29 mm | Overall Length L2: 104.6 mm | Output Shaft: ø6mm, 3-M3 flange (PCD ø31) | Type: DC spur-gear geared motor
KGC-0083-KD2847T1 GGM KGC-2847 DC 12V spur-gear geared motor, ratio 1/83, 75.9 rpm / 3.53 kgf·cm @ max eff. GGM Motor: KD2847T1 | Voltage: DC 12V | Gear Ratio: 1/83 | Output Speed (max eff.): 75.9 rpm | Output Torque (max eff.): 3.53 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 830 gf·cm | Gearhead Length L1: 29 mm | Overall Length L2: 104.6 mm | Output Shaft: ø6mm, 3-M3 flange (PCD ø31) | Type: DC spur-gear geared motor
KGC-0090-KD2847T1 GGM KGC-2847 DC 12V spur-gear geared motor, ratio 1/90, 70 rpm / 4.25 kgf·cm @ max eff. GGM Motor: KD2847T1 | Voltage: DC 12V | Gear Ratio: 1/90 | Output Speed (max eff.): 70 rpm | Output Torque (max eff.): 4.25 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 830 gf·cm | Gearhead Length L1: 29 mm | Overall Length L2: 104.6 mm | Output Shaft: ø6mm, 3-M3 flange (PCD ø31) | Type: DC spur-gear geared motor
KGC-0100-KD2847T1 GGM KGC-2847 DC 12V spur-gear geared motor, ratio 1/100, 63 rpm / 4.25 kgf·cm @ max eff. GGM Motor: KD2847T1 | Voltage: DC 12V | Gear Ratio: 1/100 | Output Speed (max eff.): 63 rpm | Output Torque (max eff.): 4.25 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 830 gf·cm | Gearhead Length L1: 29 mm | Overall Length L2: 104.6 mm | Output Shaft: ø6mm, 3-M3 flange (PCD ø31) | Type: DC spur-gear geared motor
KGC-0120-KD2847T1 GGM KGC-2847 DC 12V spur-gear geared motor, ratio 1/120, 52.5 rpm / 5.1 kgf·cm @ max eff. GGM Motor: KD2847T1 | Voltage: DC 12V | Gear Ratio: 1/120 | Output Speed (max eff.): 52.5 rpm | Output Torque (max eff.): 5.1 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 830 gf·cm | Gearhead Length L1: 29 mm | Overall Length L2: 104.6 mm | Output Shaft: ø6mm, 3-M3 flange (PCD ø31) | Type: DC spur-gear geared motor
KGC-0150-KD2847T1 GGM KGC-2847 DC 12V spur-gear geared motor, ratio 1/150, 42 rpm / 6 kgf·cm @ max eff. GGM Motor: KD2847T1 | Voltage: DC 12V | Gear Ratio: 1/150 | Output Speed (max eff.): 42 rpm | Output Torque (max eff.): 6 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 830 gf·cm | Gearhead Length L1: 29 mm | Overall Length L2: 104.6 mm | Output Shaft: ø6mm, 3-M3 flange (PCD ø31) | Type: DC spur-gear geared motor
KGC-0180-KD2847T1 GGM KGC-2847 DC 12V spur-gear geared motor, ratio 1/180, 35 rpm / 6 kgf·cm @ max eff. GGM Motor: KD2847T1 | Voltage: DC 12V | Gear Ratio: 1/180 | Output Speed (max eff.): 35 rpm | Output Torque (max eff.): 6 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 830 gf·cm | Gearhead Length L1: 29 mm | Overall Length L2: 104.6 mm | Output Shaft: ø6mm, 3-M3 flange (PCD ø31) | Type: DC spur-gear geared motor
KGC-0200-KD2847T1 GGM KGC-2847 DC 12V spur-gear geared motor, ratio 1/200, 31.5 rpm / 6 kgf·cm @ max eff. GGM Motor: KD2847T1 | Voltage: DC 12V | Gear Ratio: 1/200 | Output Speed (max eff.): 31.5 rpm | Output Torque (max eff.): 6 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 830 gf·cm | Gearhead Length L1: 33.7 mm | Overall Length L2: 109.3 mm | Output Shaft: ø6mm, 3-M3 flange (PCD ø31) | Type: DC spur-gear geared motor
KGC-0210-KD2847T1 GGM KGC-2847 DC 12V spur-gear geared motor, ratio 1/210, 30 rpm / 6 kgf·cm @ max eff. GGM Motor: KD2847T1 | Voltage: DC 12V | Gear Ratio: 1/210 | Output Speed (max eff.): 30 rpm | Output Torque (max eff.): 6 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 830 gf·cm | Gearhead Length L1: 33.7 mm | Overall Length L2: 109.3 mm | Output Shaft: ø6mm, 3-M3 flange (PCD ø31) | Type: DC spur-gear geared motor
KGC-0240-KD2847T1 GGM KGC-2847 DC 12V spur-gear geared motor, ratio 1/240, 26.3 rpm / 6 kgf·cm @ max eff. GGM Motor: KD2847T1 | Voltage: DC 12V | Gear Ratio: 1/240 | Output Speed (max eff.): 26.3 rpm | Output Torque (max eff.): 6 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 830 gf·cm | Gearhead Length L1: 33.7 mm | Overall Length L2: 109.3 mm | Output Shaft: ø6mm, 3-M3 flange (PCD ø31) | Type: DC spur-gear geared motor
KGC-0300-KD2847T1 GGM KGC-2847 DC 12V spur-gear geared motor, ratio 1/300, 21 rpm / 6 kgf·cm @ max eff. GGM Motor: KD2847T1 | Voltage: DC 12V | Gear Ratio: 1/300 | Output Speed (max eff.): 21 rpm | Output Torque (max eff.): 6 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 830 gf·cm | Gearhead Length L1: 33.7 mm | Overall Length L2: 109.3 mm | Output Shaft: ø6mm, 3-M3 flange (PCD ø31) | Type: DC spur-gear geared motor
KGC-0360-KD2847T1 GGM KGC-2847 DC 12V spur-gear geared motor, ratio 1/360, 17.5 rpm / 6 kgf·cm @ max eff. GGM Motor: KD2847T1 | Voltage: DC 12V | Gear Ratio: 1/360 | Output Speed (max eff.): 17.5 rpm | Output Torque (max eff.): 6 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 830 gf·cm | Gearhead Length L1: 33.7 mm | Overall Length L2: 109.3 mm | Output Shaft: ø6mm, 3-M3 flange (PCD ø31) | Type: DC spur-gear geared motor
KGC-0400-KD2847T1 GGM KGC-2847 DC 12V spur-gear geared motor, ratio 1/400, 15.8 rpm / 6 kgf·cm @ max eff. GGM Motor: KD2847T1 | Voltage: DC 12V | Gear Ratio: 1/400 | Output Speed (max eff.): 15.8 rpm | Output Torque (max eff.): 6 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 830 gf·cm | Gearhead Length L1: 33.7 mm | Overall Length L2: 109.3 mm | Output Shaft: ø6mm, 3-M3 flange (PCD ø31) | Type: DC spur-gear geared motor
KGC-0500-KD2847T1 GGM KGC-2847 DC 12V spur-gear geared motor, ratio 1/500, 12.6 rpm / 6 kgf·cm @ max eff. GGM Motor: KD2847T1 | Voltage: DC 12V | Gear Ratio: 1/500 | Output Speed (max eff.): 12.6 rpm | Output Torque (max eff.): 6 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 830 gf·cm | Gearhead Length L1: 33.7 mm | Overall Length L2: 109.3 mm | Output Shaft: ø6mm, 3-M3 flange (PCD ø31) | Type: DC spur-gear geared motor
KGC-0600-KD2847T1 GGM KGC-2847 DC 12V spur-gear geared motor, ratio 1/600, 10.5 rpm / 6 kgf·cm @ max eff. GGM Motor: KD2847T1 | Voltage: DC 12V | Gear Ratio: 1/600 | Output Speed (max eff.): 10.5 rpm | Output Torque (max eff.): 6 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 830 gf·cm | Gearhead Length L1: 33.7 mm | Overall Length L2: 109.3 mm | Output Shaft: ø6mm, 3-M3 flange (PCD ø31) | Type: DC spur-gear geared motor
KGC-0750-KD2847T1 GGM KGC-2847 DC 12V spur-gear geared motor, ratio 1/750, 8.4 rpm / 6 kgf·cm @ max eff. GGM Motor: KD2847T1 | Voltage: DC 12V | Gear Ratio: 1/750 | Output Speed (max eff.): 8.4 rpm | Output Torque (max eff.): 6 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 830 gf·cm | Gearhead Length L1: 33.7 mm | Overall Length L2: 109.3 mm | Output Shaft: ø6mm, 3-M3 flange (PCD ø31) | Type: DC spur-gear geared motor
KGC-0900-KD2847T1 GGM KGC-2847 DC 12V spur-gear geared motor, ratio 1/900, 7 rpm / 6 kgf·cm @ max eff. GGM Motor: KD2847T1 | Voltage: DC 12V | Gear Ratio: 1/900 | Output Speed (max eff.): 7 rpm | Output Torque (max eff.): 6 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 830 gf·cm | Gearhead Length L1: 33.7 mm | Overall Length L2: 109.3 mm | Output Shaft: ø6mm, 3-M3 flange (PCD ø31) | Type: DC spur-gear geared motor
KGC-1080-KD2847T1 GGM KGC-2847 DC 12V spur-gear geared motor, ratio 1/1080, 5.8 rpm / 6 kgf·cm @ max eff. GGM Motor: KD2847T1 | Voltage: DC 12V | Gear Ratio: 1/1080 | Output Speed (max eff.): 5.8 rpm | Output Torque (max eff.): 6 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 830 gf·cm | Gearhead Length L1: 33.7 mm | Overall Length L2: 109.3 mm | Output Shaft: ø6mm, 3-M3 flange (PCD ø31) | Type: DC spur-gear geared motor
KGC-1350-KD2847T1 GGM KGC-2847 DC 12V spur-gear geared motor, ratio 1/1350, 4.7 rpm / 6 kgf·cm @ max eff. GGM Motor: KD2847T1 | Voltage: DC 12V | Gear Ratio: 1/1350 | Output Speed (max eff.): 4.7 rpm | Output Torque (max eff.): 6 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 830 gf·cm | Gearhead Length L1: 33.7 mm | Overall Length L2: 109.3 mm | Output Shaft: ø6mm, 3-M3 flange (PCD ø31) | Type: DC spur-gear geared motor
KGC-1620-KD2847T1 GGM KGC-2847 DC 12V spur-gear geared motor, ratio 1/1620, 3.9 rpm / 6 kgf·cm @ max eff. GGM Motor: KD2847T1 | Voltage: DC 12V | Gear Ratio: 1/1620 | Output Speed (max eff.): 3.9 rpm | Output Torque (max eff.): 6 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 830 gf·cm | Gearhead Length L1: 33.7 mm | Overall Length L2: 109.3 mm | Output Shaft: ø6mm, 3-M3 flange (PCD ø31) | Type: DC spur-gear geared motor
KGC-2430-KD2847T1 GGM KGC-2847 DC 12V spur-gear geared motor, ratio 1/2430, 2.6 rpm / 6 kgf·cm @ max eff. GGM Motor: KD2847T1 | Voltage: DC 12V | Gear Ratio: 1/2430 | Output Speed (max eff.): 2.6 rpm | Output Torque (max eff.): 6 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 830 gf·cm | Gearhead Length L1: 33.7 mm | Overall Length L2: 109.3 mm | Output Shaft: ø6mm, 3-M3 flange (PCD ø31) | Type: DC spur-gear geared motor
