![[GGM] — KME-3429-P1 DC Geared Motor (DC 12V, F/R output, 1/22–1/67)](https://img.prosourcemro.com/2026/06/0609-1024x700.png)
DC
GGM
[GGM] — KME-3429-P1 DC Geared Motor (DC 12V, F/R output, 1/22–1/67)
Family ID: GGM-KME-3429-P1
GGM KME-3429 P1 right-angle DC geared motor, KD3429P1 base, DC 12V. Gear ratios 1/22 to 1/67, output torque 1.3–3.5 kgf·cm; F-TYPE (standard) and R-TYPE output shaft.
24 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| KME-0022-KD3429P1 | KME-3429 KD3429P1, 1/22, F-TYPE, DC 12V | GGM | Gear Ratio: 1/22 · Output Speed: 364 rpm · Output Torque: 1.3 kgf·cm · Output Shaft: F-TYPE | ||
| KME-0034-KD3429P1 | KME-3429 KD3429P1, 1/34, F-TYPE, DC 12V | GGM | Gear Ratio: 1/34 · Output Speed: 235 rpm · Output Torque: 2 kgf·cm · Output Shaft: F-TYPE | ||
| KME-0043-KD3429P1 | KME-3429 KD3429P1, 1/43, F-TYPE, DC 12V | GGM | Gear Ratio: 1/43 · Output Speed: 186 rpm · Output Torque: 2.5 kgf·cm · Output Shaft: F-TYPE | ||
| KME-0053-KD3429P1 | KME-3429 KD3429P1, 1/53, F-TYPE, DC 12V | GGM | Gear Ratio: 1/53 · Output Speed: 150 rpm · Output Torque: 2.6 kgf·cm · Output Shaft: F-TYPE | ||
| KME-0060-KD3429P1 | KME-3429 KD3429P1, 1/60, F-TYPE, DC 12V | GGM | Gear Ratio: 1/60 · Output Speed: 133 rpm · Output Torque: 3.1 kgf·cm · Output Shaft: F-TYPE | ||
| KME-0067-KD3429P1 | KME-3429 KD3429P1, 1/67, F-TYPE, DC 12V | GGM | Gear Ratio: 1/67 · Output Speed: 119 rpm · Output Torque: 3.5 kgf·cm · Output Shaft: F-TYPE | ||
| KME-0022-KD3429P1-R | KME-3429 KD3429P1, 1/22, R-TYPE, DC 12V | GGM | Gear Ratio: 1/22 · Output Speed: 364 rpm · Output Torque: 1.3 kgf·cm · Output Shaft: R-TYPE | ||
| KME-0034-KD3429P1-R | KME-3429 KD3429P1, 1/34, R-TYPE, DC 12V | GGM | Gear Ratio: 1/34 · Output Speed: 235 rpm · Output Torque: 2 kgf·cm · Output Shaft: R-TYPE | ||
| KME-0043-KD3429P1-R | KME-3429 KD3429P1, 1/43, R-TYPE, DC 12V | GGM | Gear Ratio: 1/43 · Output Speed: 186 rpm · Output Torque: 2.5 kgf·cm · Output Shaft: R-TYPE | ||
| KME-0053-KD3429P1-R | KME-3429 KD3429P1, 1/53, R-TYPE, DC 12V | GGM | Gear Ratio: 1/53 · Output Speed: 150 rpm · Output Torque: 2.6 kgf·cm · Output Shaft: R-TYPE | ||
| KME-0060-KD3429P1-R | KME-3429 KD3429P1, 1/60, R-TYPE, DC 12V | GGM | Gear Ratio: 1/60 · Output Speed: 133 rpm · Output Torque: 3.1 kgf·cm · Output Shaft: R-TYPE | ||
| KME-0067-KD3429P1-R | KME-3429 KD3429P1, 1/67, R-TYPE, DC 12V | GGM | Gear Ratio: 1/67 · Output Speed: 119 rpm · Output Torque: 3.5 kgf·cm · Output Shaft: R-TYPE | ||
| KME-0022-KD3429P1 | KME-3429 KD3429P1, 1/22, F-TYPE, DC 12V | GGM | Gear Ratio: 1/22 · Output Speed: 364 rpm · Output Torque: 1.3 kgf·cm · Output Shaft: F-TYPE | ||
| KME-0034-KD3429P1 | KME-3429 KD3429P1, 1/34, F-TYPE, DC 12V | GGM | Gear Ratio: 1/34 · Output Speed: 235 rpm · Output Torque: 2 kgf·cm · Output Shaft: F-TYPE | ||
| KME-0043-KD3429P1 | KME-3429 KD3429P1, 1/43, F-TYPE, DC 12V | GGM | Gear Ratio: 1/43 · Output Speed: 186 rpm · Output Torque: 2.5 kgf·cm · Output Shaft: F-TYPE | ||
| KME-0053-KD3429P1 | KME-3429 KD3429P1, 1/53, F-TYPE, DC 12V | GGM | Gear Ratio: 1/53 · Output Speed: 150 rpm · Output Torque: 2.6 kgf·cm · Output Shaft: F-TYPE | ||
| KME-0060-KD3429P1 | KME-3429 KD3429P1, 1/60, F-TYPE, DC 12V | GGM | Gear Ratio: 1/60 · Output Speed: 133 rpm · Output Torque: 3.1 kgf·cm · Output Shaft: F-TYPE | ||
| KME-0067-KD3429P1 | KME-3429 KD3429P1, 1/67, F-TYPE, DC 12V | GGM | Gear Ratio: 1/67 · Output Speed: 119 rpm · Output Torque: 3.5 kgf·cm · Output Shaft: F-TYPE | ||
| KME-0022-KD3429P1-R | KME-3429 KD3429P1, 1/22, R-TYPE, DC 12V | GGM | Gear Ratio: 1/22 · Output Speed: 364 rpm · Output Torque: 1.3 kgf·cm · Output Shaft: R-TYPE | ||
| KME-0034-KD3429P1-R | KME-3429 KD3429P1, 1/34, R-TYPE, DC 12V | GGM | Gear Ratio: 1/34 · Output Speed: 235 rpm · Output Torque: 2 kgf·cm · Output Shaft: R-TYPE | ||
| KME-0043-KD3429P1-R | KME-3429 KD3429P1, 1/43, R-TYPE, DC 12V | GGM | Gear Ratio: 1/43 · Output Speed: 186 rpm · Output Torque: 2.5 kgf·cm · Output Shaft: R-TYPE | ||
| KME-0053-KD3429P1-R | KME-3429 KD3429P1, 1/53, R-TYPE, DC 12V | GGM | Gear Ratio: 1/53 · Output Speed: 150 rpm · Output Torque: 2.6 kgf·cm · Output Shaft: R-TYPE | ||
| KME-0060-KD3429P1-R | KME-3429 KD3429P1, 1/60, R-TYPE, DC 12V | GGM | Gear Ratio: 1/60 · Output Speed: 133 rpm · Output Torque: 3.1 kgf·cm · Output Shaft: R-TYPE | ||
| KME-0067-KD3429P1-R | KME-3429 KD3429P1, 1/67, R-TYPE, DC 12V | GGM | Gear Ratio: 1/67 · Output Speed: 119 rpm · Output Torque: 3.5 kgf·cm · Output Shaft: R-TYPE |
