DC
GGM
[GGM] — K35-3429-P DC Planetary Geared Motor (ø35mm, 9500 rpm class, 12/24V, 1/5–1/721)
Family ID: GGM-K35-3429-P
GGM K35-3429 series DC planetary geared motor, ø35mm frame, ø6mm shaft, 4-M3 flange (PCD ø26). P-speed winding (12V/24V), 13 ratios 1/5 to 1/721; 90g. Optional 20-pole/10-pulse incremental encoder (-E) available.
26 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| K35-0005-KD3429P1 | GGM K35-3429-P DC 12V planetary geared motor, ratio 1/5, 1600 rpm / 0.3 kgf·cm @ max eff. | GGM | Motor: KD3429P1 | Voltage: DC 12V | Gear Ratio: 1/5 | Output Speed (max eff.): 1600 rpm | Output Torque (max eff.): 0.3 kgf·cm | No-load Speed: 9500 rpm | Stall Torque: 330 gf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 22.1 mm | Type: DC planetary geared motor | ||
| K35-0014-KD3429P1 | GGM K35-3429-P DC 12V planetary geared motor, ratio 1/14, 571 rpm / 0.7 kgf·cm @ max eff. | GGM | Motor: KD3429P1 | Voltage: DC 12V | Gear Ratio: 1/14 | Output Speed (max eff.): 571 rpm | Output Torque (max eff.): 0.7 kgf·cm | No-load Speed: 9500 rpm | Stall Torque: 330 gf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 28.5 mm | Type: DC planetary geared motor | ||
| K35-0019-KD3429P1 | GGM K35-3429-P DC 12V planetary geared motor, ratio 1/19, 421 rpm / 1 kgf·cm @ max eff. | GGM | Motor: KD3429P1 | Voltage: DC 12V | Gear Ratio: 1/19 | Output Speed (max eff.): 421 rpm | Output Torque (max eff.): 1 kgf·cm | No-load Speed: 9500 rpm | Stall Torque: 330 gf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 28.5 mm | Type: DC planetary geared motor | ||
| K35-0027-KD3429P1 | GGM K35-3429-P DC 12V planetary geared motor, ratio 1/27, 296 rpm / 1.4 kgf·cm @ max eff. | GGM | Motor: KD3429P1 | Voltage: DC 12V | Gear Ratio: 1/27 | Output Speed (max eff.): 296 rpm | Output Torque (max eff.): 1.4 kgf·cm | No-load Speed: 9500 rpm | Stall Torque: 330 gf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 28.5 mm | Type: DC planetary geared motor | ||
| K35-0051-KD3429P1 | GGM K35-3429-P DC 12V planetary geared motor, ratio 1/51, 156 rpm / 2.1 kgf·cm @ max eff. | GGM | Motor: KD3429P1 | Voltage: DC 12V | Gear Ratio: 1/51 | Output Speed (max eff.): 156 rpm | Output Torque (max eff.): 2.1 kgf·cm | No-load Speed: 9500 rpm | Stall Torque: 330 gf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 34.9 mm | Type: DC planetary geared motor | ||
| K35-0071-KD3429P1 | GGM K35-3429-P DC 12V planetary geared motor, ratio 1/71, 112 rpm / 2.9 kgf·cm @ max eff. | GGM | Motor: KD3429P1 | Voltage: DC 12V | Gear Ratio: 1/71 | Output Speed (max eff.): 112 rpm | Output Torque (max eff.): 2.9 kgf·cm | No-load Speed: 9500 rpm | Stall Torque: 330 gf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 34.9 mm | Type: DC planetary geared motor | ||
| K35-0100-KD3429P1 | GGM K35-3429-P DC 12V planetary geared motor, ratio 1/100, 80 rpm / 4.1 kgf·cm @ max eff. | GGM | Motor: KD3429P1 | Voltage: DC 12V | Gear Ratio: 1/100 | Output Speed (max eff.): 80 rpm | Output Torque (max eff.): 4.1 kgf·cm | No-load Speed: 9500 rpm | Stall Torque: 330 gf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 34.9 mm | Type: DC planetary geared motor | ||
| K35-0139-KD3429P1 | GGM K35-3429-P DC 12V planetary geared motor, ratio 1/139, 57 rpm / 5.7 kgf·cm @ max eff. | GGM | Motor: KD3429P1 | Voltage: DC 12V | Gear Ratio: 1/139 | Output Speed (max eff.): 57 rpm | Output Torque (max eff.): 5.7 kgf·cm | No-load Speed: 9500 rpm | Stall Torque: 330 gf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 34.9 mm | Type: DC planetary geared motor | ||
| K35-0189-KD3429P1 | GGM K35-3429-P DC 12V planetary geared motor, ratio 1/189, 42 rpm / 6.2 kgf·cm @ max eff. | GGM | Motor: KD3429P1 | Voltage: DC 12V | Gear Ratio: 1/189 | Output Speed (max eff.): 42 rpm | Output Torque (max eff.): 6.2 kgf·cm | No-load Speed: 9500 rpm | Stall Torque: 330 gf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 41.3 mm | Type: DC planetary geared motor | ||
| K35-0264-KD3429P1 | GGM K35-3429-P DC 12V planetary geared motor, ratio 1/264, 30 rpm / 8.6 kgf·cm @ max eff. | GGM | Motor: KD3429P1 | Voltage: DC 12V | Gear Ratio: 1/264 | Output Speed (max eff.): 30 rpm | Output Torque (max eff.): 8.6 kgf·cm | No-load Speed: 9500 rpm | Stall Torque: 330 gf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 41.3 mm | Type: DC planetary geared motor | ||
| K35-0369-KD3429P1 | GGM K35-3429-P DC 12V planetary geared motor, ratio 1/369, 21 rpm / 12 kgf·cm @ max eff. | GGM | Motor: KD3429P1 | Voltage: DC 12V | Gear Ratio: 1/369 | Output Speed (max eff.): 21 rpm | Output Torque (max eff.): 12 kgf·cm | No-load Speed: 9500 rpm | Stall Torque: 330 gf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 41.3 mm | Type: DC planetary geared motor | ||
| K35-0516-KD3429P1 | GGM K35-3429-P DC 12V planetary geared motor, ratio 1/516, 15 rpm / 12 kgf·cm @ max eff. | GGM | Motor: KD3429P1 | Voltage: DC 12V | Gear Ratio: 1/516 | Output Speed (max eff.): 15 rpm | Output Torque (max eff.): 12 kgf·cm | No-load Speed: 9500 rpm | Stall Torque: 330 gf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 41.3 mm | Type: DC planetary geared motor | ||
| K35-0721-KD3429P1 | GGM K35-3429-P DC 12V planetary geared motor, ratio 1/721, 11 rpm / 12 kgf·cm @ max eff. | GGM | Motor: KD3429P1 | Voltage: DC 12V | Gear Ratio: 1/721 | Output Speed (max eff.): 11 rpm | Output Torque (max eff.): 12 kgf·cm | No-load Speed: 9500 rpm | Stall Torque: 330 gf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 41.3 mm | Type: DC planetary geared motor | ||
| K35-0005-KD3429P2 | GGM K35-3429-P DC 24V planetary geared motor, ratio 1/5, 1600 rpm / 0.16 kgf·cm @ max eff. | GGM | Motor: KD3429P2 | Voltage: DC 24V | Gear Ratio: 1/5 | Output Speed (max eff.): 1600 rpm | Output Torque (max eff.): 0.16 kgf·cm | No-load Speed: 9500 rpm | Stall Torque: 350 gf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 22.1 mm | Type: DC planetary geared motor | ||
| K35-0014-KD3429P2 | GGM K35-3429-P DC 24V planetary geared motor, ratio 1/14, 571 rpm / 0.35 kgf·cm @ max eff. | GGM | Motor: KD3429P2 | Voltage: DC 24V | Gear Ratio: 1/14 | Output Speed (max eff.): 571 rpm | Output Torque (max eff.): 0.35 kgf·cm | No-load Speed: 9500 rpm | Stall Torque: 350 gf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 28.5 mm | Type: DC planetary geared motor | ||
| K35-0019-KD3429P2 | GGM K35-3429-P DC 24V planetary geared motor, ratio 1/19, 421 rpm / 0.48 kgf·cm @ max eff. | GGM | Motor: KD3429P2 | Voltage: DC 24V | Gear Ratio: 1/19 | Output Speed (max eff.): 421 rpm | Output Torque (max eff.): 0.48 kgf·cm | No-load Speed: 9500 rpm | Stall Torque: 350 gf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 28.5 mm | Type: DC planetary geared motor | ||
| K35-0027-KD3429P2 | GGM K35-3429-P DC 24V planetary geared motor, ratio 1/27, 296 rpm / 0.69 kgf·cm @ max eff. | GGM | Motor: KD3429P2 | Voltage: DC 24V | Gear Ratio: 1/27 | Output Speed (max eff.): 296 rpm | Output Torque (max eff.): 0.69 kgf·cm | No-load Speed: 9500 rpm | Stall Torque: 350 gf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 28.5 mm | Type: DC planetary geared motor | ||
| K35-0051-KD3429P2 | GGM K35-3429-P DC 24V planetary geared motor, ratio 1/51, 156 rpm / 1 kgf·cm @ max eff. | GGM | Motor: KD3429P2 | Voltage: DC 24V | Gear Ratio: 1/51 | Output Speed (max eff.): 156 rpm | Output Torque (max eff.): 1 kgf·cm | No-load Speed: 9500 rpm | Stall Torque: 350 gf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 34.9 mm | Type: DC planetary geared motor | ||
| K35-0071-KD3429P2 | GGM K35-3429-P DC 24V planetary geared motor, ratio 1/71, 112 rpm / 1.5 kgf·cm @ max eff. | GGM | Motor: KD3429P2 | Voltage: DC 24V | Gear Ratio: 1/71 | Output Speed (max eff.): 112 rpm | Output Torque (max eff.): 1.5 kgf·cm | No-load Speed: 9500 rpm | Stall Torque: 350 gf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 34.9 mm | Type: DC planetary geared motor | ||
| K35-0100-KD3429P2 | GGM K35-3429-P DC 24V planetary geared motor, ratio 1/100, 80 rpm / 2 kgf·cm @ max eff. | GGM | Motor: KD3429P2 | Voltage: DC 24V | Gear Ratio: 1/100 | Output Speed (max eff.): 80 rpm | Output Torque (max eff.): 2 kgf·cm | No-load Speed: 9500 rpm | Stall Torque: 350 gf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 34.9 mm | Type: DC planetary geared motor | ||
| K35-0139-KD3429P2 | GGM K35-3429-P DC 24V planetary geared motor, ratio 1/139, 57 rpm / 2.8 kgf·cm @ max eff. | GGM | Motor: KD3429P2 | Voltage: DC 24V | Gear Ratio: 1/139 | Output Speed (max eff.): 57 rpm | Output Torque (max eff.): 2.8 kgf·cm | No-load Speed: 9500 rpm | Stall Torque: 350 gf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 34.9 mm | Type: DC planetary geared motor | ||
| K35-0189-KD3429P2 | GGM K35-3429-P DC 24V planetary geared motor, ratio 1/189, 42 rpm / 3.1 kgf·cm @ max eff. | GGM | Motor: KD3429P2 | Voltage: DC 24V | Gear Ratio: 1/189 | Output Speed (max eff.): 42 rpm | Output Torque (max eff.): 3.1 kgf·cm | No-load Speed: 9500 rpm | Stall Torque: 350 gf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 41.3 mm | Type: DC planetary geared motor | ||
| K35-0264-KD3429P2 | GGM K35-3429-P DC 24V planetary geared motor, ratio 1/264, 30 rpm / 4.3 kgf·cm @ max eff. | GGM | Motor: KD3429P2 | Voltage: DC 24V | Gear Ratio: 1/264 | Output Speed (max eff.): 30 rpm | Output Torque (max eff.): 4.3 kgf·cm | No-load Speed: 9500 rpm | Stall Torque: 350 gf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 41.3 mm | Type: DC planetary geared motor | ||
| K35-0369-KD3429P2 | GGM K35-3429-P DC 24V planetary geared motor, ratio 1/369, 21 rpm / 6 kgf·cm @ max eff. | GGM | Motor: KD3429P2 | Voltage: DC 24V | Gear Ratio: 1/369 | Output Speed (max eff.): 21 rpm | Output Torque (max eff.): 6 kgf·cm | No-load Speed: 9500 rpm | Stall Torque: 350 gf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 41.3 mm | Type: DC planetary geared motor | ||
| K35-0516-KD3429P2 | GGM K35-3429-P DC 24V planetary geared motor, ratio 1/516, 15 rpm / 8.5 kgf·cm @ max eff. | GGM | Motor: KD3429P2 | Voltage: DC 24V | Gear Ratio: 1/516 | Output Speed (max eff.): 15 rpm | Output Torque (max eff.): 8.5 kgf·cm | No-load Speed: 9500 rpm | Stall Torque: 350 gf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 41.3 mm | Type: DC planetary geared motor | ||
| K35-0721-KD3429P2 | GGM K35-3429-P DC 24V planetary geared motor, ratio 1/721, 11 rpm / 11.8 kgf·cm @ max eff. | GGM | Motor: KD3429P2 | Voltage: DC 24V | Gear Ratio: 1/721 | Output Speed (max eff.): 11 rpm | Output Torque (max eff.): 11.8 kgf·cm | No-load Speed: 9500 rpm | Stall Torque: 350 gf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 41.3 mm | Type: DC planetary geared motor |
