[GGM] — K42-4932 BLDC Planetary Geared Motor (ø42mm, 24V, 1/4–1/3600)
Family ID: GGM-K42-4932
GGM K42-4932 brushless DC planetary geared motor, ø42mm frame, ø8mm shaft, 4-M4 flange (PCD ø35). 7-lead wire (195mm) with 20 pulse/rev FG; requires 24V main + 5V control supply, GUN-type controller; 24V, 21 ratios 1/4 to 1/3600; 210g.
21 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| K42-0004-KB4932S2 | GGM K42-4932 DC 24V BLDC planetary geared motor, ratio 1/4, 950 rpm / 1.4 kgf·cm @ max eff. | GGM | Motor: KB4932S2 | Voltage: DC 24V | Gear Ratio: 1/4 | Output Speed (max eff.): 950 rpm | Output Torque (max eff.): 1.4 kgf·cm | No-load Speed: 5000 rpm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 32.5 mm | Type: BLDC planetary geared motor | ||
| K42-0014-KB4932S2 | GGM K42-4932 DC 24V BLDC planetary geared motor, ratio 1/14, 271 rpm / 4.4 kgf·cm @ max eff. | GGM | Motor: KB4932S2 | Voltage: DC 24V | Gear Ratio: 1/14 | Output Speed (max eff.): 271 rpm | Output Torque (max eff.): 4.4 kgf·cm | No-load Speed: 5000 rpm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 39.2 mm | Type: BLDC planetary geared motor | ||
| K42-0017-KB4932S2 | GGM K42-4932 DC 24V BLDC planetary geared motor, ratio 1/17, 224 rpm / 5.3 kgf·cm @ max eff. | GGM | Motor: KB4932S2 | Voltage: DC 24V | Gear Ratio: 1/17 | Output Speed (max eff.): 224 rpm | Output Torque (max eff.): 5.3 kgf·cm | No-load Speed: 5000 rpm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 39.2 mm | Type: BLDC planetary geared motor | ||
| K42-0024-KB4932S2 | GGM K42-4932 DC 24V BLDC planetary geared motor, ratio 1/24, 158 rpm / 7.5 kgf·cm @ max eff. | GGM | Motor: KB4932S2 | Voltage: DC 24V | Gear Ratio: 1/24 | Output Speed (max eff.): 158 rpm | Output Torque (max eff.): 7.5 kgf·cm | No-load Speed: 5000 rpm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 39.2 mm | Type: BLDC planetary geared motor | ||
| K42-0049-KB4932S2 | GGM K42-4932 DC 24V BLDC planetary geared motor, ratio 1/49, 78 rpm / 14 kgf·cm @ max eff. | GGM | Motor: KB4932S2 | Voltage: DC 24V | Gear Ratio: 1/49 | Output Speed (max eff.): 78 rpm | Output Torque (max eff.): 14 kgf·cm | No-load Speed: 5000 rpm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 45.9 mm | Type: BLDC planetary geared motor | ||
| K42-0061-KB4932S2 | GGM K42-4932 DC 24V BLDC planetary geared motor, ratio 1/61, 62 rpm / 17 kgf·cm @ max eff. | GGM | Motor: KB4932S2 | Voltage: DC 24V | Gear Ratio: 1/61 | Output Speed (max eff.): 62 rpm | Output Torque (max eff.): 17 kgf·cm | No-load Speed: 5000 rpm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 45.9 mm | Type: BLDC planetary geared motor | ||
| K42-0084-KB4932S2 | GGM K42-4932 DC 24V BLDC planetary geared motor, ratio 1/84, 45 rpm / 24 kgf·cm @ max eff. | GGM | Motor: KB4932S2 | Voltage: DC 24V | Gear Ratio: 1/84 | Output Speed (max eff.): 45 rpm | Output Torque (max eff.): 24 kgf·cm | No-load Speed: 5000 rpm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 45.9 mm | Type: BLDC planetary geared motor | ||
| K42-0104-KB4932S2 | GGM K42-4932 DC 24V BLDC planetary geared motor, ratio 1/104, 37 rpm / 29 kgf·cm @ max eff. | GGM | Motor: KB4932S2 | Voltage: DC 24V | Gear Ratio: 1/104 | Output Speed (max eff.): 37 rpm | Output Torque (max eff.): 29 kgf·cm | No-load Speed: 5000 rpm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 45.9 mm | Type: BLDC planetary geared motor | ||
| K42-0144-KB4932S2 | GGM K42-4932 DC 24V BLDC planetary geared motor, ratio 1/144, 26 rpm / 30 kgf·cm @ max eff. | GGM | Motor: KB4932S2 | Voltage: DC 24V | Gear Ratio: 1/144 | Output Speed (max eff.): 26 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 5000 rpm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 45.9 mm | Type: BLDC planetary geared motor | ||
| K42-0212-KB4932S2 | GGM K42-4932 DC 24V BLDC planetary geared motor, ratio 1/212, 18 rpm / 30 kgf·cm @ max eff. | GGM | Motor: KB4932S2 | Voltage: DC 24V | Gear Ratio: 1/212 | Output Speed (max eff.): 18 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 5000 rpm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 52.6 mm | Type: BLDC planetary geared motor | ||
| K42-0263-KB4932S2 | GGM K42-4932 DC 24V BLDC planetary geared motor, ratio 1/263, 14 rpm / 30 kgf·cm @ max eff. | GGM | Motor: KB4932S2 | Voltage: DC 24V | Gear Ratio: 1/263 | Output Speed (max eff.): 14 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 5000 rpm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 52.6 mm | Type: BLDC planetary geared motor | ||
| K42-0294-KB4932S2 | GGM K42-4932 DC 24V BLDC planetary geared motor, ratio 1/294, 13 rpm / 30 kgf·cm @ max eff. | GGM | Motor: KB4932S2 | Voltage: DC 24V | Gear Ratio: 1/294 | Output Speed (max eff.): 13 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 5000 rpm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 52.6 mm | Type: BLDC planetary geared motor | ||
| K42-0504-KB4932S2 | GGM K42-4932 DC 24V BLDC planetary geared motor, ratio 1/504, 7.5 rpm / 30 kgf·cm @ max eff. | GGM | Motor: KB4932S2 | Voltage: DC 24V | Gear Ratio: 1/504 | Output Speed (max eff.): 7.5 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 5000 rpm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 52.6 mm | Type: BLDC planetary geared motor | ||
| K42-0624-KB4932S2 | GGM K42-4932 DC 24V BLDC planetary geared motor, ratio 1/624, 6.1 rpm / 30 kgf·cm @ max eff. | GGM | Motor: KB4932S2 | Voltage: DC 24V | Gear Ratio: 1/624 | Output Speed (max eff.): 6.1 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 5000 rpm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 52.6 mm | Type: BLDC planetary geared motor | ||
| K42-0720-KB4932S2 | GGM K42-4932 DC 24V BLDC planetary geared motor, ratio 1/720, 5.3 rpm / 30 kgf·cm @ max eff. | GGM | Motor: KB4932S2 | Voltage: DC 24V | Gear Ratio: 1/720 | Output Speed (max eff.): 5.3 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 5000 rpm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 52.6 mm | Type: BLDC planetary geared motor | ||
| K42-0864-KB4932S2 | GGM K42-4932 DC 24V BLDC planetary geared motor, ratio 1/864, 4.4 rpm / 30 kgf·cm @ max eff. | GGM | Motor: KB4932S2 | Voltage: DC 24V | Gear Ratio: 1/864 | Output Speed (max eff.): 4.4 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 5000 rpm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 52.6 mm | Type: BLDC planetary geared motor | ||
| K42-1062-KB4932S2 | GGM K42-4932 DC 24V BLDC planetary geared motor, ratio 1/1062, 3.6 rpm / 30 kgf·cm @ max eff. | GGM | Motor: KB4932S2 | Voltage: DC 24V | Gear Ratio: 1/1062 | Output Speed (max eff.): 3.6 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 5000 rpm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 59.3 mm | Type: BLDC planetary geared motor | ||
| K42-1470-KB4932S2 | GGM K42-4932 DC 24V BLDC planetary geared motor, ratio 1/1470, 2.6 rpm / 30 kgf·cm @ max eff. | GGM | Motor: KB4932S2 | Voltage: DC 24V | Gear Ratio: 1/1470 | Output Speed (max eff.): 2.6 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 5000 rpm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 59.3 mm | Type: BLDC planetary geared motor | ||
| K42-2500-KB4932S2 | GGM K42-4932 DC 24V BLDC planetary geared motor, ratio 1/2500, 1.52 rpm / 30 kgf·cm @ max eff. | GGM | Motor: KB4932S2 | Voltage: DC 24V | Gear Ratio: 1/2500 | Output Speed (max eff.): 1.52 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 5000 rpm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 59.3 mm | Type: BLDC planetary geared motor | ||
| K42-3000-KB4932S2 | GGM K42-4932 DC 24V BLDC planetary geared motor, ratio 1/3000, 1.26 rpm / 30 kgf·cm @ max eff. | GGM | Motor: KB4932S2 | Voltage: DC 24V | Gear Ratio: 1/3000 | Output Speed (max eff.): 1.26 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 5000 rpm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 59.3 mm | Type: BLDC planetary geared motor | ||
| K42-3600-KB4932S2 | GGM K42-4932 DC 24V BLDC planetary geared motor, ratio 1/3600, 1.05 rpm / 30 kgf·cm @ max eff. | GGM | Motor: KB4932S2 | Voltage: DC 24V | Gear Ratio: 1/3600 | Output Speed (max eff.): 1.05 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 5000 rpm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 59.3 mm | Type: BLDC planetary geared motor |
