[GGM] — K22-2418 BLDC Planetary Geared Motor (ø22mm, 12/24V, 1/4–1/1996)
DC GGM

[GGM] — K22-2418 BLDC Planetary Geared Motor (ø22mm, 12/24V, 1/4–1/1996)

Family ID: GGM-K22-2418

GGM K22-2418 brushless DC planetary geared motor, ø22mm frame, ø4mm shaft, 4-M2 flange mount. 5-lead wire with 9 pulse/rev FG output, GUN-type speed controller; 12V/24V, 20 ratios 1/4 to 1/1996; 30g.

40 product codes available in this family

RFQ Cart (0)

Product Codes & Specifications

Product Code Description Brand Spec
K22-0004-KB2418U1 GGM K22-2418 DC 12V BLDC planetary geared motor, ratio 1/4, 1125 rpm / 0.09 kgf·cm @ max eff. GGM Motor: KB2418U1 | Voltage: DC 12V | Gear Ratio: 1/4 | Output Speed (max eff.): 1125 rpm | Output Torque (max eff.): 0.09 kgf·cm | No-load Speed: 6200 rpm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 14.4 mm | Type: BLDC planetary geared motor
K22-0014-KB2418U1 GGM K22-2418 DC 12V BLDC planetary geared motor, ratio 1/14, 321 rpm / 0.29 kgf·cm @ max eff. GGM Motor: KB2418U1 | Voltage: DC 12V | Gear Ratio: 1/14 | Output Speed (max eff.): 321 rpm | Output Torque (max eff.): 0.29 kgf·cm | No-load Speed: 6200 rpm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 18.05 mm | Type: BLDC planetary geared motor
K22-0016-KB2418U1 GGM K22-2418 DC 12V BLDC planetary geared motor, ratio 1/16, 281 rpm / 0.33 kgf·cm @ max eff. GGM Motor: KB2418U1 | Voltage: DC 12V | Gear Ratio: 1/16 | Output Speed (max eff.): 281 rpm | Output Torque (max eff.): 0.33 kgf·cm | No-load Speed: 6200 rpm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 18.05 mm | Type: BLDC planetary geared motor
K22-0019-KB2418U1 GGM K22-2418 DC 12V BLDC planetary geared motor, ratio 1/19, 237 rpm / 0.39 kgf·cm @ max eff. GGM Motor: KB2418U1 | Voltage: DC 12V | Gear Ratio: 1/19 | Output Speed (max eff.): 237 rpm | Output Torque (max eff.): 0.39 kgf·cm | No-load Speed: 6200 rpm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 18.05 mm | Type: BLDC planetary geared motor
K22-0053-KB2418U1 GGM K22-2418 DC 12V BLDC planetary geared motor, ratio 1/53, 85 rpm / 1 kgf·cm @ max eff. GGM Motor: KB2418U1 | Voltage: DC 12V | Gear Ratio: 1/53 | Output Speed (max eff.): 85 rpm | Output Torque (max eff.): 1 kgf·cm | No-load Speed: 6200 rpm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 21.7 mm | Type: BLDC planetary geared motor
K22-0062-KB2418U1 GGM K22-2418 DC 12V BLDC planetary geared motor, ratio 1/62, 73 rpm / 1.1 kgf·cm @ max eff. GGM Motor: KB2418U1 | Voltage: DC 12V | Gear Ratio: 1/62 | Output Speed (max eff.): 73 rpm | Output Torque (max eff.): 1.1 kgf·cm | No-load Speed: 6200 rpm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 21.7 mm | Type: BLDC planetary geared motor
K22-0072-KB2418U1 GGM K22-2418 DC 12V BLDC planetary geared motor, ratio 1/72, 63 rpm / 1.3 kgf·cm @ max eff. GGM Motor: KB2418U1 | Voltage: DC 12V | Gear Ratio: 1/72 | Output Speed (max eff.): 63 rpm | Output Torque (max eff.): 1.3 kgf·cm | No-load Speed: 6200 rpm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 21.7 mm | Type: BLDC planetary geared motor
K22-0084-KB2418U1 GGM K22-2418 DC 12V BLDC planetary geared motor, ratio 1/84, 54 rpm / 1.6 kgf·cm @ max eff. GGM Motor: KB2418U1 | Voltage: DC 12V | Gear Ratio: 1/84 | Output Speed (max eff.): 54 rpm | Output Torque (max eff.): 1.6 kgf·cm | No-load Speed: 6200 rpm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 21.7 mm | Type: BLDC planetary geared motor
K22-0104-KB2418U1 GGM K22-2418 DC 12V BLDC planetary geared motor, ratio 1/104, 43 rpm / 1.9 kgf·cm @ max eff. GGM Motor: KB2418U1 | Voltage: DC 12V | Gear Ratio: 1/104 | Output Speed (max eff.): 43 rpm | Output Torque (max eff.): 1.9 kgf·cm | No-load Speed: 6200 rpm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 21.7 mm | Type: BLDC planetary geared motor
K22-0198-KB2418U1 GGM K22-2418 DC 12V BLDC planetary geared motor, ratio 1/198, 22.7 rpm / 3 kgf·cm @ max eff. GGM Motor: KB2418U1 | Voltage: DC 12V | Gear Ratio: 1/198 | Output Speed (max eff.): 22.7 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 6200 rpm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 25.35 mm | Type: BLDC planetary geared motor
K22-0231-KB2418U1 GGM K22-2418 DC 12V BLDC planetary geared motor, ratio 1/231, 19.5 rpm / 3 kgf·cm @ max eff. GGM Motor: KB2418U1 | Voltage: DC 12V | Gear Ratio: 1/231 | Output Speed (max eff.): 19.5 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 6200 rpm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 25.35 mm | Type: BLDC planetary geared motor
K22-0270-KB2418U1 GGM K22-2418 DC 12V BLDC planetary geared motor, ratio 1/270, 16.7 rpm / 3 kgf·cm @ max eff. GGM Motor: KB2418U1 | Voltage: DC 12V | Gear Ratio: 1/270 | Output Speed (max eff.): 16.7 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 6200 rpm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 25.35 mm | Type: BLDC planetary geared motor
K22-0316-KB2418U1 GGM K22-2418 DC 12V BLDC planetary geared motor, ratio 1/316, 14.2 rpm / 3 kgf·cm @ max eff. GGM Motor: KB2418U1 | Voltage: DC 12V | Gear Ratio: 1/316 | Output Speed (max eff.): 14.2 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 6200 rpm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 25.35 mm | Type: BLDC planetary geared motor
K22-0370-KB2418U1 GGM K22-2418 DC 12V BLDC planetary geared motor, ratio 1/370, 12.1 rpm / 3 kgf·cm @ max eff. GGM Motor: KB2418U1 | Voltage: DC 12V | Gear Ratio: 1/370 | Output Speed (max eff.): 12.1 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 6200 rpm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 25.35 mm | Type: BLDC planetary geared motor
K22-0455-KB2418U1 GGM K22-2418 DC 12V BLDC planetary geared motor, ratio 1/455, 9.9 rpm / 3 kgf·cm @ max eff. GGM Motor: KB2418U1 | Voltage: DC 12V | Gear Ratio: 1/455 | Output Speed (max eff.): 9.9 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 6200 rpm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 25.35 mm | Type: BLDC planetary geared motor
K22-0742-KB2418U1 GGM K22-2418 DC 12V BLDC planetary geared motor, ratio 1/742, 6 rpm / 3 kgf·cm @ max eff. GGM Motor: KB2418U1 | Voltage: DC 12V | Gear Ratio: 1/742 | Output Speed (max eff.): 6 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 6200 rpm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 29 mm | Type: BLDC planetary geared motor
K22-1014-KB2418U1 GGM K22-2418 DC 12V BLDC planetary geared motor, ratio 1/1014, 4.4 rpm / 3 kgf·cm @ max eff. GGM Motor: KB2418U1 | Voltage: DC 12V | Gear Ratio: 1/1014 | Output Speed (max eff.): 4.4 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 6200 rpm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 29 mm | Type: BLDC planetary geared motor
K22-1249-KB2418U1 GGM K22-2418 DC 12V BLDC planetary geared motor, ratio 1/1249, 3.6 rpm / 3 kgf·cm @ max eff. GGM Motor: KB2418U1 | Voltage: DC 12V | Gear Ratio: 1/1249 | Output Speed (max eff.): 3.6 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 6200 rpm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 29 mm | Type: BLDC planetary geared motor
K22-1621-KB2418U1 GGM K22-2418 DC 12V BLDC planetary geared motor, ratio 1/1621, 2.8 rpm / 3 kgf·cm @ max eff. GGM Motor: KB2418U1 | Voltage: DC 12V | Gear Ratio: 1/1621 | Output Speed (max eff.): 2.8 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 6200 rpm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 29 mm | Type: BLDC planetary geared motor
K22-1996-KB2418U1 GGM K22-2418 DC 12V BLDC planetary geared motor, ratio 1/1996, 2.3 rpm / 3 kgf·cm @ max eff. GGM Motor: KB2418U1 | Voltage: DC 12V | Gear Ratio: 1/1996 | Output Speed (max eff.): 2.3 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 6200 rpm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 29 mm | Type: BLDC planetary geared motor
K22-0004-KB2418R2 GGM K22-2418 DC 24V BLDC planetary geared motor, ratio 1/4, 1800 rpm / 0.06 kgf·cm @ max eff. GGM Motor: KB2418R2 | Voltage: DC 24V | Gear Ratio: 1/4 | Output Speed (max eff.): 1800 rpm | Output Torque (max eff.): 0.06 kgf·cm | No-load Speed: 8700 rpm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 14.4 mm | Type: BLDC planetary geared motor
K22-0014-KB2418R2 GGM K22-2418 DC 24V BLDC planetary geared motor, ratio 1/14, 514 rpm / 0.2 kgf·cm @ max eff. GGM Motor: KB2418R2 | Voltage: DC 24V | Gear Ratio: 1/14 | Output Speed (max eff.): 514 rpm | Output Torque (max eff.): 0.2 kgf·cm | No-load Speed: 8700 rpm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 18.05 mm | Type: BLDC planetary geared motor
K22-0016-KB2418R2 GGM K22-2418 DC 24V BLDC planetary geared motor, ratio 1/16, 450 rpm / 0.23 kgf·cm @ max eff. GGM Motor: KB2418R2 | Voltage: DC 24V | Gear Ratio: 1/16 | Output Speed (max eff.): 450 rpm | Output Torque (max eff.): 0.23 kgf·cm | No-load Speed: 8700 rpm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 18.05 mm | Type: BLDC planetary geared motor
K22-0019-KB2418R2 GGM K22-2418 DC 24V BLDC planetary geared motor, ratio 1/19, 379 rpm / 0.27 kgf·cm @ max eff. GGM Motor: KB2418R2 | Voltage: DC 24V | Gear Ratio: 1/19 | Output Speed (max eff.): 379 rpm | Output Torque (max eff.): 0.27 kgf·cm | No-load Speed: 8700 rpm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 18.05 mm | Type: BLDC planetary geared motor
K22-0053-KB2418R2 GGM K22-2418 DC 24V BLDC planetary geared motor, ratio 1/53, 136 rpm / 0.68 kgf·cm @ max eff. GGM Motor: KB2418R2 | Voltage: DC 24V | Gear Ratio: 1/53 | Output Speed (max eff.): 136 rpm | Output Torque (max eff.): 0.68 kgf·cm | No-load Speed: 8700 rpm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 21.7 mm | Type: BLDC planetary geared motor
K22-0062-KB2418R2 GGM K22-2418 DC 24V BLDC planetary geared motor, ratio 1/62, 116 rpm / 0.8 kgf·cm @ max eff. GGM Motor: KB2418R2 | Voltage: DC 24V | Gear Ratio: 1/62 | Output Speed (max eff.): 116 rpm | Output Torque (max eff.): 0.8 kgf·cm | No-load Speed: 8700 rpm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 21.7 mm | Type: BLDC planetary geared motor
K22-0072-KB2418R2 GGM K22-2418 DC 24V BLDC planetary geared motor, ratio 1/72, 100 rpm / 0.93 kgf·cm @ max eff. GGM Motor: KB2418R2 | Voltage: DC 24V | Gear Ratio: 1/72 | Output Speed (max eff.): 100 rpm | Output Torque (max eff.): 0.93 kgf·cm | No-load Speed: 8700 rpm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 21.7 mm | Type: BLDC planetary geared motor
K22-0084-KB2418R2 GGM K22-2418 DC 24V BLDC planetary geared motor, ratio 1/84, 86 rpm / 1.1 kgf·cm @ max eff. GGM Motor: KB2418R2 | Voltage: DC 24V | Gear Ratio: 1/84 | Output Speed (max eff.): 86 rpm | Output Torque (max eff.): 1.1 kgf·cm | No-load Speed: 8700 rpm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 21.7 mm | Type: BLDC planetary geared motor
K22-0104-KB2418R2 GGM K22-2418 DC 24V BLDC planetary geared motor, ratio 1/104, 69 rpm / 1.3 kgf·cm @ max eff. GGM Motor: KB2418R2 | Voltage: DC 24V | Gear Ratio: 1/104 | Output Speed (max eff.): 69 rpm | Output Torque (max eff.): 1.3 kgf·cm | No-load Speed: 8700 rpm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 21.7 mm | Type: BLDC planetary geared motor
K22-0198-KB2418R2 GGM K22-2418 DC 24V BLDC planetary geared motor, ratio 1/198, 36 rpm / 2.3 kgf·cm @ max eff. GGM Motor: KB2418R2 | Voltage: DC 24V | Gear Ratio: 1/198 | Output Speed (max eff.): 36 rpm | Output Torque (max eff.): 2.3 kgf·cm | No-load Speed: 8700 rpm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 25.35 mm | Type: BLDC planetary geared motor
K22-0231-KB2418R2 GGM K22-2418 DC 24V BLDC planetary geared motor, ratio 1/231, 31 rpm / 2.7 kgf·cm @ max eff. GGM Motor: KB2418R2 | Voltage: DC 24V | Gear Ratio: 1/231 | Output Speed (max eff.): 31 rpm | Output Torque (max eff.): 2.7 kgf·cm | No-load Speed: 8700 rpm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 25.35 mm | Type: BLDC planetary geared motor
K22-0270-KB2418R2 GGM K22-2418 DC 24V BLDC planetary geared motor, ratio 1/270, 26.7 rpm / 3 kgf·cm @ max eff. GGM Motor: KB2418R2 | Voltage: DC 24V | Gear Ratio: 1/270 | Output Speed (max eff.): 26.7 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 8700 rpm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 25.35 mm | Type: BLDC planetary geared motor
K22-0316-KB2418R2 GGM K22-2418 DC 24V BLDC planetary geared motor, ratio 1/316, 22.8 rpm / 3 kgf·cm @ max eff. GGM Motor: KB2418R2 | Voltage: DC 24V | Gear Ratio: 1/316 | Output Speed (max eff.): 22.8 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 8700 rpm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 25.35 mm | Type: BLDC planetary geared motor
K22-0370-KB2418R2 GGM K22-2418 DC 24V BLDC planetary geared motor, ratio 1/370, 19.5 rpm / 3 kgf·cm @ max eff. GGM Motor: KB2418R2 | Voltage: DC 24V | Gear Ratio: 1/370 | Output Speed (max eff.): 19.5 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 8700 rpm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 25.35 mm | Type: BLDC planetary geared motor
K22-0455-KB2418R2 GGM K22-2418 DC 24V BLDC planetary geared motor, ratio 1/455, 15.8 rpm / 3 kgf·cm @ max eff. GGM Motor: KB2418R2 | Voltage: DC 24V | Gear Ratio: 1/455 | Output Speed (max eff.): 15.8 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 8700 rpm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 25.35 mm | Type: BLDC planetary geared motor
K22-0742-KB2418R2 GGM K22-2418 DC 24V BLDC planetary geared motor, ratio 1/742, 9.7 rpm / 3 kgf·cm @ max eff. GGM Motor: KB2418R2 | Voltage: DC 24V | Gear Ratio: 1/742 | Output Speed (max eff.): 9.7 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 8700 rpm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 29 mm | Type: BLDC planetary geared motor
K22-1014-KB2418R2 GGM K22-2418 DC 24V BLDC planetary geared motor, ratio 1/1014, 7.1 rpm / 3 kgf·cm @ max eff. GGM Motor: KB2418R2 | Voltage: DC 24V | Gear Ratio: 1/1014 | Output Speed (max eff.): 7.1 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 8700 rpm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 29 mm | Type: BLDC planetary geared motor
K22-1249-KB2418R2 GGM K22-2418 DC 24V BLDC planetary geared motor, ratio 1/1249, 5.7 rpm / 3 kgf·cm @ max eff. GGM Motor: KB2418R2 | Voltage: DC 24V | Gear Ratio: 1/1249 | Output Speed (max eff.): 5.7 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 8700 rpm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 29 mm | Type: BLDC planetary geared motor
K22-1621-KB2418R2 GGM K22-2418 DC 24V BLDC planetary geared motor, ratio 1/1621, 4.4 rpm / 3 kgf·cm @ max eff. GGM Motor: KB2418R2 | Voltage: DC 24V | Gear Ratio: 1/1621 | Output Speed (max eff.): 4.4 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 8700 rpm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 29 mm | Type: BLDC planetary geared motor
K22-1996-KB2418R2 GGM K22-2418 DC 24V BLDC planetary geared motor, ratio 1/1996, 3.6 rpm / 3 kgf·cm @ max eff. GGM Motor: KB2418R2 | Voltage: DC 24V | Gear Ratio: 1/1996 | Output Speed (max eff.): 3.6 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 8700 rpm | Frame: ø22mm | Output Shaft: ø4mm, 4-M2 flange (PCD ø18) | Gearhead Length L: 29 mm | Type: BLDC planetary geared motor
