[GGM] — K42-4260 BLDC Planetary Geared Motor (ø42mm, 12/24V, 1/4–1/3600)
DC GGM

[GGM] — K42-4260 BLDC Planetary Geared Motor (ø42mm, 12/24V, 1/4–1/3600)

Family ID: GGM-K42-4260

GGM K42-4260 brushless DC planetary geared motor, ø42mm frame, ø8mm shaft, 4-M4 flange (PCD ø35). 6-lead wire (280mm), 6 pulse/rev FG, brake lead, no-PCB control, GUN-type controller; 12V/24V, 21 ratios 1/4 to 1/3600; 300g.

42 product codes available in this family

RFQ Cart (0)

Product Codes & Specifications

Product Code Description Brand Spec
K42-0004-KB4260S1 GGM K42-4260 DC 12V BLDC planetary geared motor, ratio 1/4, 1000 rpm / 1.4 kgf·cm @ max eff. GGM Motor: KB4260S1 | Voltage: DC 12V | Gear Ratio: 1/4 | Output Speed (max eff.): 1000 rpm | Output Torque (max eff.): 1.4 kgf·cm | No-load Speed: 5000 rpm | Stall Torque: 1 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 32.5 mm | Type: BLDC planetary geared motor
K42-0014-KB4260S1 GGM K42-4260 DC 12V BLDC planetary geared motor, ratio 1/14, 286 rpm / 4.4 kgf·cm @ max eff. GGM Motor: KB4260S1 | Voltage: DC 12V | Gear Ratio: 1/14 | Output Speed (max eff.): 286 rpm | Output Torque (max eff.): 4.4 kgf·cm | No-load Speed: 5000 rpm | Stall Torque: 1 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 39.2 mm | Type: BLDC planetary geared motor
K42-0017-KB4260S1 GGM K42-4260 DC 12V BLDC planetary geared motor, ratio 1/17, 235 rpm / 5.3 kgf·cm @ max eff. GGM Motor: KB4260S1 | Voltage: DC 12V | Gear Ratio: 1/17 | Output Speed (max eff.): 235 rpm | Output Torque (max eff.): 5.3 kgf·cm | No-load Speed: 5000 rpm | Stall Torque: 1 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 39.2 mm | Type: BLDC planetary geared motor
K42-0024-KB4260S1 GGM K42-4260 DC 12V BLDC planetary geared motor, ratio 1/24, 167 rpm / 7.5 kgf·cm @ max eff. GGM Motor: KB4260S1 | Voltage: DC 12V | Gear Ratio: 1/24 | Output Speed (max eff.): 167 rpm | Output Torque (max eff.): 7.5 kgf·cm | No-load Speed: 5000 rpm | Stall Torque: 1 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 39.2 mm | Type: BLDC planetary geared motor
K42-0049-KB4260S1 GGM K42-4260 DC 12V BLDC planetary geared motor, ratio 1/49, 82 rpm / 14 kgf·cm @ max eff. GGM Motor: KB4260S1 | Voltage: DC 12V | Gear Ratio: 1/49 | Output Speed (max eff.): 82 rpm | Output Torque (max eff.): 14 kgf·cm | No-load Speed: 5000 rpm | Stall Torque: 1 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 45.9 mm | Type: BLDC planetary geared motor
K42-0061-KB4260S1 GGM K42-4260 DC 12V BLDC planetary geared motor, ratio 1/61, 66 rpm / 17 kgf·cm @ max eff. GGM Motor: KB4260S1 | Voltage: DC 12V | Gear Ratio: 1/61 | Output Speed (max eff.): 66 rpm | Output Torque (max eff.): 17 kgf·cm | No-load Speed: 5000 rpm | Stall Torque: 1 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 45.9 mm | Type: BLDC planetary geared motor
K42-0084-KB4260S1 GGM K42-4260 DC 12V BLDC planetary geared motor, ratio 1/84, 48 rpm / 24 kgf·cm @ max eff. GGM Motor: KB4260S1 | Voltage: DC 12V | Gear Ratio: 1/84 | Output Speed (max eff.): 48 rpm | Output Torque (max eff.): 24 kgf·cm | No-load Speed: 5000 rpm | Stall Torque: 1 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 45.9 mm | Type: BLDC planetary geared motor
K42-0104-KB4260S1 GGM K42-4260 DC 12V BLDC planetary geared motor, ratio 1/104, 38 rpm / 29 kgf·cm @ max eff. GGM Motor: KB4260S1 | Voltage: DC 12V | Gear Ratio: 1/104 | Output Speed (max eff.): 38 rpm | Output Torque (max eff.): 29 kgf·cm | No-load Speed: 5000 rpm | Stall Torque: 1 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 45.9 mm | Type: BLDC planetary geared motor
K42-0144-KB4260S1 GGM K42-4260 DC 12V BLDC planetary geared motor, ratio 1/144, 28 rpm / 30 kgf·cm @ max eff. GGM Motor: KB4260S1 | Voltage: DC 12V | Gear Ratio: 1/144 | Output Speed (max eff.): 28 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 5000 rpm | Stall Torque: 1 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 45.9 mm | Type: BLDC planetary geared motor
K42-0212-KB4260S1 GGM K42-4260 DC 12V BLDC planetary geared motor, ratio 1/212, 18.9 rpm / 30 kgf·cm @ max eff. GGM Motor: KB4260S1 | Voltage: DC 12V | Gear Ratio: 1/212 | Output Speed (max eff.): 18.9 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 5000 rpm | Stall Torque: 1 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 52.6 mm | Type: BLDC planetary geared motor
K42-0263-KB4260S1 GGM K42-4260 DC 12V BLDC planetary geared motor, ratio 1/263, 15.2 rpm / 30 kgf·cm @ max eff. GGM Motor: KB4260S1 | Voltage: DC 12V | Gear Ratio: 1/263 | Output Speed (max eff.): 15.2 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 5000 rpm | Stall Torque: 1 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 52.6 mm | Type: BLDC planetary geared motor
K42-0294-KB4260S1 GGM K42-4260 DC 12V BLDC planetary geared motor, ratio 1/294, 13.6 rpm / 30 kgf·cm @ max eff. GGM Motor: KB4260S1 | Voltage: DC 12V | Gear Ratio: 1/294 | Output Speed (max eff.): 13.6 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 5000 rpm | Stall Torque: 1 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 52.6 mm | Type: BLDC planetary geared motor
K42-0504-KB4260S1 GGM K42-4260 DC 12V BLDC planetary geared motor, ratio 1/504, 7.9 rpm / 30 kgf·cm @ max eff. GGM Motor: KB4260S1 | Voltage: DC 12V | Gear Ratio: 1/504 | Output Speed (max eff.): 7.9 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 5000 rpm | Stall Torque: 1 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 52.6 mm | Type: BLDC planetary geared motor
K42-0624-KB4260S1 GGM K42-4260 DC 12V BLDC planetary geared motor, ratio 1/624, 6.4 rpm / 30 kgf·cm @ max eff. GGM Motor: KB4260S1 | Voltage: DC 12V | Gear Ratio: 1/624 | Output Speed (max eff.): 6.4 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 5000 rpm | Stall Torque: 1 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 52.6 mm | Type: BLDC planetary geared motor
K42-0720-KB4260S1 GGM K42-4260 DC 12V BLDC planetary geared motor, ratio 1/720, 5.6 rpm / 30 kgf·cm @ max eff. GGM Motor: KB4260S1 | Voltage: DC 12V | Gear Ratio: 1/720 | Output Speed (max eff.): 5.6 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 5000 rpm | Stall Torque: 1 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 52.6 mm | Type: BLDC planetary geared motor
K42-0864-KB4260S1 GGM K42-4260 DC 12V BLDC planetary geared motor, ratio 1/864, 4.6 rpm / 30 kgf·cm @ max eff. GGM Motor: KB4260S1 | Voltage: DC 12V | Gear Ratio: 1/864 | Output Speed (max eff.): 4.6 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 5000 rpm | Stall Torque: 1 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 52.6 mm | Type: BLDC planetary geared motor
K42-1062-KB4260S1 GGM K42-4260 DC 12V BLDC planetary geared motor, ratio 1/1062, 3.8 rpm / 30 kgf·cm @ max eff. GGM Motor: KB4260S1 | Voltage: DC 12V | Gear Ratio: 1/1062 | Output Speed (max eff.): 3.8 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 5000 rpm | Stall Torque: 1 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 59.3 mm | Type: BLDC planetary geared motor
K42-1470-KB4260S1 GGM K42-4260 DC 12V BLDC planetary geared motor, ratio 1/1470, 2.7 rpm / 30 kgf·cm @ max eff. GGM Motor: KB4260S1 | Voltage: DC 12V | Gear Ratio: 1/1470 | Output Speed (max eff.): 2.7 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 5000 rpm | Stall Torque: 1 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 59.3 mm | Type: BLDC planetary geared motor
K42-2500-KB4260S1 GGM K42-4260 DC 12V BLDC planetary geared motor, ratio 1/2500, 1.6 rpm / 30 kgf·cm @ max eff. GGM Motor: KB4260S1 | Voltage: DC 12V | Gear Ratio: 1/2500 | Output Speed (max eff.): 1.6 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 5000 rpm | Stall Torque: 1 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 59.3 mm | Type: BLDC planetary geared motor
K42-3000-KB4260S1 GGM K42-4260 DC 12V BLDC planetary geared motor, ratio 1/3000, 1.3 rpm / 30 kgf·cm @ max eff. GGM Motor: KB4260S1 | Voltage: DC 12V | Gear Ratio: 1/3000 | Output Speed (max eff.): 1.3 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 5000 rpm | Stall Torque: 1 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 59.3 mm | Type: BLDC planetary geared motor
K42-3600-KB4260S1 GGM K42-4260 DC 12V BLDC planetary geared motor, ratio 1/3600, 1.1 rpm / 30 kgf·cm @ max eff. GGM Motor: KB4260S1 | Voltage: DC 12V | Gear Ratio: 1/3600 | Output Speed (max eff.): 1.1 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 5000 rpm | Stall Torque: 1 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 59.3 mm | Type: BLDC planetary geared motor
K42-0004-KB4260S2 GGM K42-4260 DC 24V BLDC planetary geared motor, ratio 1/4, 1000 rpm / 1.4 kgf·cm @ max eff. GGM Motor: KB4260S2 | Voltage: DC 24V | Gear Ratio: 1/4 | Output Speed (max eff.): 1000 rpm | Output Torque (max eff.): 1.4 kgf·cm | No-load Speed: 5000 rpm | Stall Torque: 1.4 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 32.5 mm | Type: BLDC planetary geared motor
K42-0014-KB4260S2 GGM K42-4260 DC 24V BLDC planetary geared motor, ratio 1/14, 286 rpm / 4.4 kgf·cm @ max eff. GGM Motor: KB4260S2 | Voltage: DC 24V | Gear Ratio: 1/14 | Output Speed (max eff.): 286 rpm | Output Torque (max eff.): 4.4 kgf·cm | No-load Speed: 5000 rpm | Stall Torque: 1.4 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 39.2 mm | Type: BLDC planetary geared motor
K42-0017-KB4260S2 GGM K42-4260 DC 24V BLDC planetary geared motor, ratio 1/17, 235 rpm / 5.3 kgf·cm @ max eff. GGM Motor: KB4260S2 | Voltage: DC 24V | Gear Ratio: 1/17 | Output Speed (max eff.): 235 rpm | Output Torque (max eff.): 5.3 kgf·cm | No-load Speed: 5000 rpm | Stall Torque: 1.4 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 39.2 mm | Type: BLDC planetary geared motor
K42-0024-KB4260S2 GGM K42-4260 DC 24V BLDC planetary geared motor, ratio 1/24, 167 rpm / 7.5 kgf·cm @ max eff. GGM Motor: KB4260S2 | Voltage: DC 24V | Gear Ratio: 1/24 | Output Speed (max eff.): 167 rpm | Output Torque (max eff.): 7.5 kgf·cm | No-load Speed: 5000 rpm | Stall Torque: 1.4 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 39.2 mm | Type: BLDC planetary geared motor
K42-0049-KB4260S2 GGM K42-4260 DC 24V BLDC planetary geared motor, ratio 1/49, 82 rpm / 14 kgf·cm @ max eff. GGM Motor: KB4260S2 | Voltage: DC 24V | Gear Ratio: 1/49 | Output Speed (max eff.): 82 rpm | Output Torque (max eff.): 14 kgf·cm | No-load Speed: 5000 rpm | Stall Torque: 1.4 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 45.9 mm | Type: BLDC planetary geared motor
K42-0061-KB4260S2 GGM K42-4260 DC 24V BLDC planetary geared motor, ratio 1/61, 66 rpm / 17 kgf·cm @ max eff. GGM Motor: KB4260S2 | Voltage: DC 24V | Gear Ratio: 1/61 | Output Speed (max eff.): 66 rpm | Output Torque (max eff.): 17 kgf·cm | No-load Speed: 5000 rpm | Stall Torque: 1.4 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 45.9 mm | Type: BLDC planetary geared motor
K42-0084-KB4260S2 GGM K42-4260 DC 24V BLDC planetary geared motor, ratio 1/84, 48 rpm / 24 kgf·cm @ max eff. GGM Motor: KB4260S2 | Voltage: DC 24V | Gear Ratio: 1/84 | Output Speed (max eff.): 48 rpm | Output Torque (max eff.): 24 kgf·cm | No-load Speed: 5000 rpm | Stall Torque: 1.4 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 45.9 mm | Type: BLDC planetary geared motor
K42-0104-KB4260S2 GGM K42-4260 DC 24V BLDC planetary geared motor, ratio 1/104, 38 rpm / 29 kgf·cm @ max eff. GGM Motor: KB4260S2 | Voltage: DC 24V | Gear Ratio: 1/104 | Output Speed (max eff.): 38 rpm | Output Torque (max eff.): 29 kgf·cm | No-load Speed: 5000 rpm | Stall Torque: 1.4 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 45.9 mm | Type: BLDC planetary geared motor
K42-0144-KB4260S2 GGM K42-4260 DC 24V BLDC planetary geared motor, ratio 1/144, 28 rpm / 30 kgf·cm @ max eff. GGM Motor: KB4260S2 | Voltage: DC 24V | Gear Ratio: 1/144 | Output Speed (max eff.): 28 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 5000 rpm | Stall Torque: 1.4 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 45.9 mm | Type: BLDC planetary geared motor
K42-0212-KB4260S2 GGM K42-4260 DC 24V BLDC planetary geared motor, ratio 1/212, 18.9 rpm / 30 kgf·cm @ max eff. GGM Motor: KB4260S2 | Voltage: DC 24V | Gear Ratio: 1/212 | Output Speed (max eff.): 18.9 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 5000 rpm | Stall Torque: 1.4 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 52.6 mm | Type: BLDC planetary geared motor
K42-0263-KB4260S2 GGM K42-4260 DC 24V BLDC planetary geared motor, ratio 1/263, 15.2 rpm / 30 kgf·cm @ max eff. GGM Motor: KB4260S2 | Voltage: DC 24V | Gear Ratio: 1/263 | Output Speed (max eff.): 15.2 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 5000 rpm | Stall Torque: 1.4 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 52.6 mm | Type: BLDC planetary geared motor
K42-0294-KB4260S2 GGM K42-4260 DC 24V BLDC planetary geared motor, ratio 1/294, 13.6 rpm / 30 kgf·cm @ max eff. GGM Motor: KB4260S2 | Voltage: DC 24V | Gear Ratio: 1/294 | Output Speed (max eff.): 13.6 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 5000 rpm | Stall Torque: 1.4 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 52.6 mm | Type: BLDC planetary geared motor
K42-0504-KB4260S2 GGM K42-4260 DC 24V BLDC planetary geared motor, ratio 1/504, 7.9 rpm / 30 kgf·cm @ max eff. GGM Motor: KB4260S2 | Voltage: DC 24V | Gear Ratio: 1/504 | Output Speed (max eff.): 7.9 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 5000 rpm | Stall Torque: 1.4 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 52.6 mm | Type: BLDC planetary geared motor
K42-0624-KB4260S2 GGM K42-4260 DC 24V BLDC planetary geared motor, ratio 1/624, 6.4 rpm / 30 kgf·cm @ max eff. GGM Motor: KB4260S2 | Voltage: DC 24V | Gear Ratio: 1/624 | Output Speed (max eff.): 6.4 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 5000 rpm | Stall Torque: 1.4 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 52.6 mm | Type: BLDC planetary geared motor
K42-0720-KB4260S2 GGM K42-4260 DC 24V BLDC planetary geared motor, ratio 1/720, 5.6 rpm / 30 kgf·cm @ max eff. GGM Motor: KB4260S2 | Voltage: DC 24V | Gear Ratio: 1/720 | Output Speed (max eff.): 5.6 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 5000 rpm | Stall Torque: 1.4 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 52.6 mm | Type: BLDC planetary geared motor
K42-0864-KB4260S2 GGM K42-4260 DC 24V BLDC planetary geared motor, ratio 1/864, 4.6 rpm / 30 kgf·cm @ max eff. GGM Motor: KB4260S2 | Voltage: DC 24V | Gear Ratio: 1/864 | Output Speed (max eff.): 4.6 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 5000 rpm | Stall Torque: 1.4 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 52.6 mm | Type: BLDC planetary geared motor
K42-1062-KB4260S2 GGM K42-4260 DC 24V BLDC planetary geared motor, ratio 1/1062, 3.8 rpm / 30 kgf·cm @ max eff. GGM Motor: KB4260S2 | Voltage: DC 24V | Gear Ratio: 1/1062 | Output Speed (max eff.): 3.8 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 5000 rpm | Stall Torque: 1.4 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 59.3 mm | Type: BLDC planetary geared motor
K42-1470-KB4260S2 GGM K42-4260 DC 24V BLDC planetary geared motor, ratio 1/1470, 2.7 rpm / 30 kgf·cm @ max eff. GGM Motor: KB4260S2 | Voltage: DC 24V | Gear Ratio: 1/1470 | Output Speed (max eff.): 2.7 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 5000 rpm | Stall Torque: 1.4 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 59.3 mm | Type: BLDC planetary geared motor
K42-2500-KB4260S2 GGM K42-4260 DC 24V BLDC planetary geared motor, ratio 1/2500, 1.6 rpm / 30 kgf·cm @ max eff. GGM Motor: KB4260S2 | Voltage: DC 24V | Gear Ratio: 1/2500 | Output Speed (max eff.): 1.6 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 5000 rpm | Stall Torque: 1.4 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 59.3 mm | Type: BLDC planetary geared motor
K42-3000-KB4260S2 GGM K42-4260 DC 24V BLDC planetary geared motor, ratio 1/3000, 1.3 rpm / 30 kgf·cm @ max eff. GGM Motor: KB4260S2 | Voltage: DC 24V | Gear Ratio: 1/3000 | Output Speed (max eff.): 1.3 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 5000 rpm | Stall Torque: 1.4 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 59.3 mm | Type: BLDC planetary geared motor
K42-3600-KB4260S2 GGM K42-4260 DC 24V BLDC planetary geared motor, ratio 1/3600, 1.1 rpm / 30 kgf·cm @ max eff. GGM Motor: KB4260S2 | Voltage: DC 24V | Gear Ratio: 1/3600 | Output Speed (max eff.): 1.1 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 5000 rpm | Stall Torque: 1.4 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 59.3 mm | Type: BLDC planetary geared motor
