DC Motors
GGM
[GGM] — K8D Brushed DC Motor (□80, 25–40W, 12/24/90V DC, 3000 rpm)
Family ID: GGM-K8D
GGM K8D brushed DC motor, □80mm frame, 25W and 40W outputs at 12/24/90V DC, rated 3000 rpm. Reversible by supply polarity (red lead = CW, black lead = CCW), straight (S) or pinion (G) output shaft; compatible with K8G gearheads.
12 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| K8DS25N1 | K8D brushed DC motor, 25W, DC 12V, Straight shaft, 3000 rpm | GGM | Output: 25W | Voltage: DC 12V | Shaft: Straight | Rated Torque: 0.08 N·m (0.8 kgf·cm) | Rated Current: 5 A | Starting Torque: 1.2 N·m (12 kgf·cm) | Starting Current: 55 A | ||
| K8DG25N1 | K8D brushed DC motor, 25W, DC 12V, Pinion shaft, 3000 rpm | GGM | Output: 25W | Voltage: DC 12V | Shaft: Pinion | Rated Torque: 0.08 N·m (0.8 kgf·cm) | Rated Current: 5 A | Starting Torque: 1.2 N·m (12 kgf·cm) | Starting Current: 55 A | ||
| K8DS25N2 | K8D brushed DC motor, 25W, DC 24V, Straight shaft, 3000 rpm | GGM | Output: 25W | Voltage: DC 24V | Shaft: Straight | Rated Torque: 0.08 N·m (0.8 kgf·cm) | Rated Current: 2.3 A | Starting Torque: 1.3 N·m (13 kgf·cm) | Starting Current: 28 A | ||
| K8DG25N2 | K8D brushed DC motor, 25W, DC 24V, Pinion shaft, 3000 rpm | GGM | Output: 25W | Voltage: DC 24V | Shaft: Pinion | Rated Torque: 0.08 N·m (0.8 kgf·cm) | Rated Current: 2.3 A | Starting Torque: 1.3 N·m (13 kgf·cm) | Starting Current: 28 A | ||
| K8DS25N3 | K8D brushed DC motor, 25W, DC 90V, Straight shaft, 3000 rpm | GGM | Output: 25W | Voltage: DC 90V | Shaft: Straight | Rated Torque: 0.08 N·m (0.8 kgf·cm) | Rated Current: 0.6 A | Starting Torque: 0.8 N·m (8 kgf·cm) | Starting Current: 5 A | ||
| K8DG25N3 | K8D brushed DC motor, 25W, DC 90V, Pinion shaft, 3000 rpm | GGM | Output: 25W | Voltage: DC 90V | Shaft: Pinion | Rated Torque: 0.08 N·m (0.8 kgf·cm) | Rated Current: 0.6 A | Starting Torque: 0.8 N·m (8 kgf·cm) | Starting Current: 5 A | ||
| K8DS40N1 | K8D brushed DC motor, 40W, DC 12V, Straight shaft, 3000 rpm | GGM | Output: 40W | Voltage: DC 12V | Shaft: Straight | Rated Torque: 0.13 N·m (1.3 kgf·cm) | Rated Current: 6.1 A | Starting Torque: 1.43 N·m (14.3 kgf·cm) | Starting Current: 64 A | ||
| K8DG40N1 | K8D brushed DC motor, 40W, DC 12V, Pinion shaft, 3000 rpm | GGM | Output: 40W | Voltage: DC 12V | Shaft: Pinion | Rated Torque: 0.13 N·m (1.3 kgf·cm) | Rated Current: 6.1 A | Starting Torque: 1.43 N·m (14.3 kgf·cm) | Starting Current: 64 A | ||
| K8DS40N2 | K8D brushed DC motor, 40W, DC 24V, Straight shaft, 3000 rpm | GGM | Output: 40W | Voltage: DC 24V | Shaft: Straight | Rated Torque: 0.13 N·m (1.3 kgf·cm) | Rated Current: 3 A | Starting Torque: 1.82 N·m (18.2 kgf·cm) | Starting Current: 40 A | ||
| K8DG40N2 | K8D brushed DC motor, 40W, DC 24V, Pinion shaft, 3000 rpm | GGM | Output: 40W | Voltage: DC 24V | Shaft: Pinion | Rated Torque: 0.13 N·m (1.3 kgf·cm) | Rated Current: 3 A | Starting Torque: 1.82 N·m (18.2 kgf·cm) | Starting Current: 40 A | ||
| K8DS40N3 | K8D brushed DC motor, 40W, DC 90V, Straight shaft, 3000 rpm | GGM | Output: 40W | Voltage: DC 90V | Shaft: Straight | Rated Torque: 0.13 N·m (1.3 kgf·cm) | Rated Current: 0.9 A | Starting Torque: 1.44 N·m (14.4 kgf·cm) | Starting Current: 9 A | ||
| K8DG40N3 | K8D brushed DC motor, 40W, DC 90V, Pinion shaft, 3000 rpm | GGM | Output: 40W | Voltage: DC 90V | Shaft: Pinion | Rated Torque: 0.13 N·m (1.3 kgf·cm) | Rated Current: 0.9 A | Starting Torque: 1.44 N·m (14.4 kgf·cm) | Starting Current: 9 A |
