Shaded-Pole Motors GGM

[GGM] — KA61 Pivot-Type Shaded-Pole Motor (□60, Continuous)

Family ID: GGM-KA61-P

GGM KA61 pivot-type shaded-pole AC motor, □60 frame with 20–50mm stator. Continuous-duty, 2–6.3W output, single-phase 100/110V & 220V, 50/60Hz.

8 product codes available in this family

Product Codes & Specifications

	Product Code	Description	Brand	Spec
	KA6120PU	GGM KA6120PU shaded-pole motor, pivot type, 20mm stator, single-phase AC 100V/50Hz, 110V/60Hz	GGM	Type: Pivot (continuous) \| Stator: 20mm \| Voltage: 100V/50Hz, 110V/60Hz \| Output: 2W/1.9W (50/60Hz) \| Rated torque: 80/64 gf·cm \| Rated speed: 2400/2900 rpm \| Start torque: 90/72 gf·cm
	KA6130PU	GGM KA6130PU shaded-pole motor, pivot type, 30mm stator, single-phase AC 100V/50Hz, 110V/60Hz	GGM	Type: Pivot (continuous) \| Stator: 30mm \| Voltage: 100V/50Hz, 110V/60Hz \| Output: 3.7W/3.2W (50/60Hz) \| Rated torque: 150/108 gf·cm \| Rated speed: 2400/2900 rpm \| Start torque: 143/87 gf·cm
	KA6140PU	GGM KA6140PU shaded-pole motor, pivot type, 40mm stator, single-phase AC 100V/50Hz, 110V/60Hz	GGM	Type: Pivot (continuous) \| Stator: 40mm \| Voltage: 100V/50Hz, 110V/60Hz \| Output: 4.8W/4.4W (50/60Hz) \| Rated torque: 197/149 gf·cm \| Rated speed: 2400/2900 rpm \| Start torque: 165/115 gf·cm
	KA6150PU	GGM KA6150PU shaded-pole motor, pivot type, 50mm stator, single-phase AC 100V/50Hz, 110V/60Hz	GGM	Type: Pivot (continuous) \| Stator: 50mm \| Voltage: 100V/50Hz, 110V/60Hz \| Output: 6.1W/5.9W (50/60Hz) \| Rated torque: 248/200 gf·cm \| Rated speed: 2400/2900 rpm \| Start torque: 207/162 gf·cm
	KA6120PE	GGM KA6120PE shaded-pole motor, pivot type, 20mm stator, single-phase AC 220V 50/60Hz	GGM	Type: Pivot (continuous) \| Stator: 20mm \| Voltage: 220V 50/60Hz \| Output: 2W/1.9W (50/60Hz) \| Rated torque: 80/64 gf·cm \| Rated speed: 2400/2900 rpm \| Start torque: 102/74 gf·cm
	KA6130PE	GGM KA6130PE shaded-pole motor, pivot type, 30mm stator, single-phase AC 220V 50/60Hz	GGM	Type: Pivot (continuous) \| Stator: 30mm \| Voltage: 220V 50/60Hz \| Output: 4.1W/3.3W (50/60Hz) \| Rated torque: 168/113 gf·cm \| Rated speed: 2400/2900 rpm \| Start torque: 137/88 gf·cm
	KA6140PE	GGM KA6140PE shaded-pole motor, pivot type, 40mm stator, single-phase AC 220V 50/60Hz	GGM	Type: Pivot (continuous) \| Stator: 40mm \| Voltage: 220V 50/60Hz \| Output: 4.6W/4.3W (50/60Hz) \| Rated torque: 186/145 gf·cm \| Rated speed: 2400/2900 rpm \| Start torque: 130/116 gf·cm
	KA6150PE	GGM KA6150PE shaded-pole motor, pivot type, 50mm stator, single-phase AC 220V 50/60Hz	GGM	Type: Pivot (continuous) \| Stator: 50mm \| Voltage: 220V 50/60Hz \| Output: 6.3W/5.6W (50/60Hz) \| Rated torque: 264/188 gf·cm \| Rated speed: 2400/2900 rpm \| Start torque: 215/144 gf·cm
