[GGM] — KGR5 Gearhead for KA61 Shaded-Pole Motors (□60, 1/124–1/192)
Family ID: GGM-KGR5
GGM KGR5 gearhead for □60 KA61 shaded-pole general-type motors, 2 gear ratios (1/124, 1/192); output rotates opposite to motor. Body 63.5×65.79mm, Ø9.5 shaft with M8 thread, 3-Ø3.6 mounting holes.
2 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| KGR5-0124 | KGR5 gearhead, 1/124, output 19.3/23.3 rpm (50/60Hz), reverse rotation | GGM | Gear Ratio: 1/124 | Output Speed: 19.3 rpm (50Hz) / 23.3 rpm (60Hz) | Rotation: Opposite to motor | ||
| KGR5-0192 | KGR5 gearhead, 1/192, output 12.5/15.1 rpm (50/60Hz), reverse rotation | GGM | Gear Ratio: 1/192 | Output Speed: 12.5 rpm (50Hz) / 15.1 rpm (60Hz) | Rotation: Opposite to motor |
