[GGM] — KGH Gearhead for KA61 Shaded-Pole Motors (□60, F-Type, 1/15–1/220)
Family ID: GGM-KGH
GGM KGH gearhead for □60 KA61 shaded-pole general-type motors, 7 gear ratios from 1/15 to 1/220. F-TYPE standard, body 64×76mm, Ø7.5 output shaft, 4-#8-32 UNC mounting.
7 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| KGH-0015 | KGH gearhead, 1/15, output 160/193 rpm (50/60Hz) | GGM | Gear Ratio: 1/15 | Output Speed: 160 rpm (50Hz) / 193 rpm (60Hz) | ||
| KGH-0023 | KGH gearhead, 1/23, output 104/126 rpm (50/60Hz) | GGM | Gear Ratio: 1/23 | Output Speed: 104 rpm (50Hz) / 126 rpm (60Hz) | ||
| KGH-0036 | KGH gearhead, 1/36, output 67/81 rpm (50/60Hz) | GGM | Gear Ratio: 1/36 | Output Speed: 67 rpm (50Hz) / 81 rpm (60Hz) | ||
| KGH-0058 | KGH gearhead, 1/58, output 41/50 rpm (50/60Hz) | GGM | Gear Ratio: 1/58 | Output Speed: 41 rpm (50Hz) / 50 rpm (60Hz) | ||
| KGH-0075 | KGH gearhead, 1/75, output 32/39 rpm (50/60Hz) | GGM | Gear Ratio: 1/75 | Output Speed: 32 rpm (50Hz) / 39 rpm (60Hz) | ||
| KGH-0133 | KGH gearhead, 1/133, output 18/22 rpm (50/60Hz) | GGM | Gear Ratio: 1/133 | Output Speed: 18 rpm (50Hz) / 22 rpm (60Hz) | ||
| KGH-0220 | KGH gearhead, 1/220, output 11/13 rpm (50/60Hz) | GGM | Gear Ratio: 1/220 | Output Speed: 11 rpm (50Hz) / 13 rpm (60Hz) |
