[GGM] — KGB Gearhead for KA61 Shaded-Pole Motors (□60, F-Type, 1/10–1/825)
Shaded-Pole Motors GGM

[GGM] — KGB Gearhead for KA61 Shaded-Pole Motors (□60, F-Type, 1/10–1/825)

Family ID: GGM-KGB

GGM KGB reduction gearhead for □60 KA61 shaded-pole brake-type motors, 24 gear ratios from 1/10 to 1/825. Max permissible output torque 20 kgf·cm, F-TYPE standard, body 60×97mm, Ø8 shaft, 4-M4 mounting.

24 product codes available in this family

RFQ Cart (0)

Product Codes & Specifications

Product Code Description Brand Spec
KGB-0010 KGB gearhead, 1/10, output 240/290 rpm (50/60Hz) GGM Gear Ratio: 1/10 | Output Speed: 240 rpm (50Hz) / 290 rpm (60Hz) | Max Permissible Output Torque: 20 kgf·cm
KGB-0015 KGB gearhead, 1/15, output 160/193.3 rpm (50/60Hz) GGM Gear Ratio: 1/15 | Output Speed: 160 rpm (50Hz) / 193.3 rpm (60Hz) | Max Permissible Output Torque: 20 kgf·cm
KGB-0021 KGB gearhead, 1/21, output 114.3/138.1 rpm (50/60Hz) GGM Gear Ratio: 1/21 | Output Speed: 114.3 rpm (50Hz) / 138.1 rpm (60Hz) | Max Permissible Output Torque: 20 kgf·cm
KGB-0027 KGB gearhead, 1/27, output 88.9/107.4 rpm (50/60Hz) GGM Gear Ratio: 1/27 | Output Speed: 88.9 rpm (50Hz) / 107.4 rpm (60Hz) | Max Permissible Output Torque: 20 kgf·cm
KGB-0036 KGB gearhead, 1/36, output 66.7/80.6 rpm (50/60Hz) GGM Gear Ratio: 1/36 | Output Speed: 66.7 rpm (50Hz) / 80.6 rpm (60Hz) | Max Permissible Output Torque: 20 kgf·cm
KGB-0043 KGB gearhead, 1/43, output 55.8/67.4 rpm (50/60Hz) GGM Gear Ratio: 1/43 | Output Speed: 55.8 rpm (50Hz) / 67.4 rpm (60Hz) | Max Permissible Output Torque: 20 kgf·cm
KGB-0047 KGB gearhead, 1/47, output 51.1/61.7 rpm (50/60Hz) GGM Gear Ratio: 1/47 | Output Speed: 51.1 rpm (50Hz) / 61.7 rpm (60Hz) | Max Permissible Output Torque: 20 kgf·cm
KGB-0055 KGB gearhead, 1/55, output 43.6/52.7 rpm (50/60Hz) GGM Gear Ratio: 1/55 | Output Speed: 43.6 rpm (50Hz) / 52.7 rpm (60Hz) | Max Permissible Output Torque: 20 kgf·cm
KGB-0060 KGB gearhead, 1/60, output 40/48.3 rpm (50/60Hz) GGM Gear Ratio: 1/60 | Output Speed: 40 rpm (50Hz) / 48.3 rpm (60Hz) | Max Permissible Output Torque: 20 kgf·cm
KGB-0075 KGB gearhead, 1/75, output 32/38.7 rpm (50/60Hz) GGM Gear Ratio: 1/75 | Output Speed: 32 rpm (50Hz) / 38.7 rpm (60Hz) | Max Permissible Output Torque: 20 kgf·cm
KGB-0086 KGB gearhead, 1/86, output 27.9/33.7 rpm (50/60Hz) GGM Gear Ratio: 1/86 | Output Speed: 27.9 rpm (50Hz) / 33.7 rpm (60Hz) | Max Permissible Output Torque: 20 kgf·cm
KGB-0100 KGB gearhead, 1/100, output 24/29 rpm (50/60Hz) GGM Gear Ratio: 1/100 | Output Speed: 24 rpm (50Hz) / 29 rpm (60Hz) | Max Permissible Output Torque: 20 kgf·cm
KGB-0115 KGB gearhead, 1/115, output 20.9/25.2 rpm (50/60Hz) GGM Gear Ratio: 1/115 | Output Speed: 20.9 rpm (50Hz) / 25.2 rpm (60Hz) | Max Permissible Output Torque: 20 kgf·cm
KGB-0126 KGB gearhead, 1/126, output 19/23 rpm (50/60Hz) GGM Gear Ratio: 1/126 | Output Speed: 19 rpm (50Hz) / 23 rpm (60Hz) | Max Permissible Output Torque: 20 kgf·cm
KGB-0131 KGB gearhead, 1/131, output 18.3/22.1 rpm (50/60Hz) GGM Gear Ratio: 1/131 | Output Speed: 18.3 rpm (50Hz) / 22.1 rpm (60Hz) | Max Permissible Output Torque: 20 kgf·cm
KGB-0154 KGB gearhead, 1/154, output 15.6/18.8 rpm (50/60Hz) GGM Gear Ratio: 1/154 | Output Speed: 15.6 rpm (50Hz) / 18.8 rpm (60Hz) | Max Permissible Output Torque: 20 kgf·cm
KGB-0172 KGB gearhead, 1/172, output 14/16.9 rpm (50/60Hz) GGM Gear Ratio: 1/172 | Output Speed: 14 rpm (50Hz) / 16.9 rpm (60Hz) | Max Permissible Output Torque: 20 kgf·cm
KGB-0215 KGB gearhead, 1/215, output 11.2/13.5 rpm (50/60Hz) GGM Gear Ratio: 1/215 | Output Speed: 11.2 rpm (50Hz) / 13.5 rpm (60Hz) | Max Permissible Output Torque: 20 kgf·cm
KGB-0300 KGB gearhead, 1/300, output 8/9.7 rpm (50/60Hz) GGM Gear Ratio: 1/300 | Output Speed: 8 rpm (50Hz) / 9.7 rpm (60Hz) | Max Permissible Output Torque: 20 kgf·cm
KGB-0380 KGB gearhead, 1/380, output 6.3/7.6 rpm (50/60Hz) GGM Gear Ratio: 1/380 | Output Speed: 6.3 rpm (50Hz) / 7.6 rpm (60Hz) | Max Permissible Output Torque: 20 kgf·cm
KGB-0408 KGB gearhead, 1/408, output 5.9/7.1 rpm (50/60Hz) GGM Gear Ratio: 1/408 | Output Speed: 5.9 rpm (50Hz) / 7.1 rpm (60Hz) | Max Permissible Output Torque: 20 kgf·cm
KGB-0532 KGB gearhead, 1/532, output 4.5/5.5 rpm (50/60Hz) GGM Gear Ratio: 1/532 | Output Speed: 4.5 rpm (50Hz) / 5.5 rpm (60Hz) | Max Permissible Output Torque: 20 kgf·cm
KGB-0673 KGB gearhead, 1/673, output 3.6/4.3 rpm (50/60Hz) GGM Gear Ratio: 1/673 | Output Speed: 3.6 rpm (50Hz) / 4.3 rpm (60Hz) | Max Permissible Output Torque: 20 kgf·cm
KGB-0825 KGB gearhead, 1/825, output 2.9/3.5 rpm (50/60Hz) GGM Gear Ratio: 1/825 | Output Speed: 2.9 rpm (50Hz) / 3.5 rpm (60Hz) | Max Permissible Output Torque: 20 kgf·cm
