[GGM] — KGC-3640-S2 BLDC Spur Geared Motor (ø36, DC 24V, 5000rpm base, 32 ratios 1/2-1/2430)
Family ID: GGM-KGC3640-S2
GGM KGC-3640-S2 BLDC spur geared motor, ø36 frame, DC 24V (5000 rpm base motor). 32 gear ratios 1/2-1/2430, output torque up to 6 kgf·cm, ø6 output shaft on 3-M3 PCD ø31 flange. Built-in brake and 1FG (6P/R) feedback, 6-lead wire (195mm), CW/CCW reversible, GUN-type PWM speed controller.
32 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| KGC-0002-KB3640S2 | KGC-3640-S2 BLDC spur geared, 1/2, 1950rpm, 0.4kgf·cm | GGM | Gear Ratio: 1/2 | Output Speed: 1950 rpm | Output Torque: 0.4 kgf·cm | Gearhead Length L: 21 mm | ||
| KGC-0003-KB3640S2 | KGC-3640-S2 BLDC spur geared, 1/3, 1300rpm, 0.6kgf·cm | GGM | Gear Ratio: 1/3 | Output Speed: 1300 rpm | Output Torque: 0.6 kgf·cm | Gearhead Length L: 21 mm | ||
| KGC-0005-KB3640S2 | KGC-3640-S2 BLDC spur geared, 1/5, 780rpm, 1kgf·cm | GGM | Gear Ratio: 1/5 | Output Speed: 780 rpm | Output Torque: 1 kgf·cm | Gearhead Length L: 21 mm | ||
| KGC-0010-KB3640S2 | KGC-3640-S2 BLDC spur geared, 1/10, 390rpm, 2kgf·cm | GGM | Gear Ratio: 1/10 | Output Speed: 390 rpm | Output Torque: 2 kgf·cm | Gearhead Length L: 21 mm | ||
| KGC-0015-KB3640S2 | KGC-3640-S2 BLDC spur geared, 1/15, 260rpm, 2.7kgf·cm | GGM | Gear Ratio: 1/15 | Output Speed: 260 rpm | Output Torque: 2.7 kgf·cm | Gearhead Length L: 21 mm | ||
| KGC-0020-KB3640S2 | KGC-3640-S2 BLDC spur geared, 1/20, 195rpm, 3.6kgf·cm | GGM | Gear Ratio: 1/20 | Output Speed: 195 rpm | Output Torque: 3.6 kgf·cm | Gearhead Length L: 21 mm | ||
| KGC-0025-KB3640S2 | KGC-3640-S2 BLDC spur geared, 1/25, 156rpm, 4.5kgf·cm | GGM | Gear Ratio: 1/25 | Output Speed: 156 rpm | Output Torque: 4.5 kgf·cm | Gearhead Length L: 21 mm | ||
| KGC-0030-KB3640S2 | KGC-3640-S2 BLDC spur geared, 1/30, 130rpm, 5.4kgf·cm | GGM | Gear Ratio: 1/30 | Output Speed: 130 rpm | Output Torque: 5.4 kgf·cm | Gearhead Length L: 21 mm | ||
| KGC-0040-KB3640S2 | KGC-3640-S2 BLDC spur geared, 1/40, 97.5rpm, 6kgf·cm | GGM | Gear Ratio: 1/40 | Output Speed: 97.5 rpm | Output Torque: 6 kgf·cm | Gearhead Length L: 29 mm | ||
| KGC-0050-KB3640S2 | KGC-3640-S2 BLDC spur geared, 1/50, 78rpm, 6kgf·cm | GGM | Gear Ratio: 1/50 | Output Speed: 78 rpm | Output Torque: 6 kgf·cm | Gearhead Length L: 29 mm | ||
| KGC-0060-KB3640S2 | KGC-3640-S2 BLDC spur geared, 1/60, 65rpm, 6kgf·cm | GGM | Gear Ratio: 1/60 | Output Speed: 65 rpm | Output Torque: 6 kgf·cm | Gearhead Length L: 29 mm | ||
| KGC-0070-KB3640S2 | KGC-3640-S2 BLDC spur geared, 1/70, 55.7rpm, 6kgf·cm | GGM | Gear Ratio: 1/70 | Output Speed: 55.7 rpm | Output Torque: 6 kgf·cm | Gearhead Length L: 29 mm | ||
| KGC-0083-KB3640S2 | KGC-3640-S2 BLDC spur geared, 1/83, 47rpm, 6kgf·cm | GGM | Gear Ratio: 1/83 | Output Speed: 47 rpm | Output Torque: 6 kgf·cm | Gearhead Length L: 29 mm | ||
| KGC-0090-KB3640S2 | KGC-3640-S2 BLDC spur geared, 1/90, 43.3rpm, 6kgf·cm | GGM | Gear Ratio: 1/90 | Output Speed: 43.3 rpm | Output Torque: 6 kgf·cm | Gearhead Length L: 29 mm | ||
| KGC-0100-KB3640S2 | KGC-3640-S2 BLDC spur geared, 1/100, 39rpm, 6kgf·cm | GGM | Gear Ratio: 1/100 | Output Speed: 39 rpm | Output Torque: 6 kgf·cm | Gearhead Length L: 29 mm | ||
| KGC-0120-KB3640S2 | KGC-3640-S2 BLDC spur geared, 1/120, 32.5rpm, 6kgf·cm | GGM | Gear Ratio: 1/120 | Output Speed: 32.5 rpm | Output Torque: 6 kgf·cm | Gearhead Length L: 29 mm | ||
| KGC-0150-KB3640S2 | KGC-3640-S2 BLDC spur geared, 1/150, 26rpm, 6kgf·cm | GGM | Gear Ratio: 1/150 | Output Speed: 26 rpm | Output Torque: 6 kgf·cm | Gearhead Length L: 29 mm | ||
| KGC-0180-KB3640S2 | KGC-3640-S2 BLDC spur geared, 1/180, 21.6rpm, 6kgf·cm | GGM | Gear Ratio: 1/180 | Output Speed: 21.6 rpm | Output Torque: 6 kgf·cm | Gearhead Length L: 29 mm | ||
| KGC-0200-KB3640S2 | KGC-3640-S2 BLDC spur geared, 1/200, 19.5rpm, 6kgf·cm | GGM | Gear Ratio: 1/200 | Output Speed: 19.5 rpm | Output Torque: 6 kgf·cm | Gearhead Length L: 33.7 mm | ||
| KGC-0210-KB3640S2 | KGC-3640-S2 BLDC spur geared, 1/210, 18.5rpm, 6kgf·cm | GGM | Gear Ratio: 1/210 | Output Speed: 18.5 rpm | Output Torque: 6 kgf·cm | Gearhead Length L: 33.7 mm | ||
| KGC-0240-KB3640S2 | KGC-3640-S2 BLDC spur geared, 1/240, 16.2rpm, 6kgf·cm | GGM | Gear Ratio: 1/240 | Output Speed: 16.2 rpm | Output Torque: 6 kgf·cm | Gearhead Length L: 33.7 mm | ||
| KGC-0300-KB3640S2 | KGC-3640-S2 BLDC spur geared, 1/300, 13rpm, 6kgf·cm | GGM | Gear Ratio: 1/300 | Output Speed: 13 rpm | Output Torque: 6 kgf·cm | Gearhead Length L: 33.7 mm | ||
| KGC-0360-KB3640S2 | KGC-3640-S2 BLDC spur geared, 1/360, 10.8rpm, 6kgf·cm | GGM | Gear Ratio: 1/360 | Output Speed: 10.8 rpm | Output Torque: 6 kgf·cm | Gearhead Length L: 33.7 mm | ||
| KGC-0400-KB3640S2 | KGC-3640-S2 BLDC spur geared, 1/400, 9.7rpm, 6kgf·cm | GGM | Gear Ratio: 1/400 | Output Speed: 9.7 rpm | Output Torque: 6 kgf·cm | Gearhead Length L: 33.7 mm | ||
| KGC-0500-KB3640S2 | KGC-3640-S2 BLDC spur geared, 1/500, 7.8rpm, 6kgf·cm | GGM | Gear Ratio: 1/500 | Output Speed: 7.8 rpm | Output Torque: 6 kgf·cm | Gearhead Length L: 33.7 mm | ||
| KGC-0600-KB3640S2 | KGC-3640-S2 BLDC spur geared, 1/600, 6.5rpm, 6kgf·cm | GGM | Gear Ratio: 1/600 | Output Speed: 6.5 rpm | Output Torque: 6 kgf·cm | Gearhead Length L: 33.7 mm | ||
| KGC-0750-KB3640S2 | KGC-3640-S2 BLDC spur geared, 1/750, 5.2rpm, 6kgf·cm | GGM | Gear Ratio: 1/750 | Output Speed: 5.2 rpm | Output Torque: 6 kgf·cm | Gearhead Length L: 33.7 mm | ||
| KGC-0900-KB3640S2 | KGC-3640-S2 BLDC spur geared, 1/900, 4.3rpm, 6kgf·cm | GGM | Gear Ratio: 1/900 | Output Speed: 4.3 rpm | Output Torque: 6 kgf·cm | Gearhead Length L: 33.7 mm | ||
| KGC-1080-KB3640S2 | KGC-3640-S2 BLDC spur geared, 1/1080, 3.6rpm, 6kgf·cm | GGM | Gear Ratio: 1/1080 | Output Speed: 3.6 rpm | Output Torque: 6 kgf·cm | Gearhead Length L: 33.7 mm | ||
| KGC-1350-KB3640S2 | KGC-3640-S2 BLDC spur geared, 1/1350, 2.8rpm, 6kgf·cm | GGM | Gear Ratio: 1/1350 | Output Speed: 2.8 rpm | Output Torque: 6 kgf·cm | Gearhead Length L: 33.7 mm | ||
| KGC-1620-KB3640S2 | KGC-3640-S2 BLDC spur geared, 1/1620, 2.4rpm, 6kgf·cm | GGM | Gear Ratio: 1/1620 | Output Speed: 2.4 rpm | Output Torque: 6 kgf·cm | Gearhead Length L: 33.7 mm | ||
| KGC-2430-KB3640S2 | KGC-3640-S2 BLDC spur geared, 1/2430, 1.6rpm, 6kgf·cm | GGM | Gear Ratio: 1/2430 | Output Speed: 1.6 rpm | Output Torque: 6 kgf·cm | Gearhead Length L: 33.7 mm |
