[GGM] — K12-1230 Series DC Planetary Geared Motor (ø12mm, 2.4/3/13V, 1/4–1/4096)
Family ID: GGM-K12-1230
GGM K12-1230 micro DC planetary geared motor, ø12mm frame with ø3mm shaft (2-M2 tapped). Three windings (2.4V/3V/13V), six planetary ratios 1/4 to 1/4096; 13g.
18 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| K12-0004-KD1230LB | GGM K12-1230 DC 2.4V planetary geared motor, ratio 1/4, 2525 rpm / 20 gf·cm @ max eff. | GGM | Motor: KD1230LB | Voltage: DC 2.4V | Gear Ratio: 1/4 | Output Speed (max eff.): 2525 rpm | Output Torque (max eff.): 20 gf·cm | No-load Speed: 12500 rpm | Stall Torque: 23 gf·cm | Frame: ø12mm | Output Shaft: ø3mm, 2-M2 TAP DP2.5 | Gearhead Length L: 15 mm | Type: DC planetary geared motor | ||
| K12-0016-KD1230LB | GGM K12-1230 DC 2.4V planetary geared motor, ratio 1/16, 631 rpm / 60 gf·cm @ max eff. | GGM | Motor: KD1230LB | Voltage: DC 2.4V | Gear Ratio: 1/16 | Output Speed (max eff.): 631 rpm | Output Torque (max eff.): 60 gf·cm | No-load Speed: 12500 rpm | Stall Torque: 23 gf·cm | Frame: ø12mm | Output Shaft: ø3mm, 2-M2 TAP DP2.5 | Gearhead Length L: 18.3 mm | Type: DC planetary geared motor | ||
| K12-0064-KD1230LB | GGM K12-1230 DC 2.4V planetary geared motor, ratio 1/64, 157 rpm / 200 gf·cm @ max eff. | GGM | Motor: KD1230LB | Voltage: DC 2.4V | Gear Ratio: 1/64 | Output Speed (max eff.): 157 rpm | Output Torque (max eff.): 200 gf·cm | No-load Speed: 12500 rpm | Stall Torque: 23 gf·cm | Frame: ø12mm | Output Shaft: ø3mm, 2-M2 TAP DP2.5 | Gearhead Length L: 21.6 mm | Type: DC planetary geared motor | ||
| K12-0256-KD1230LB | GGM K12-1230 DC 2.4V planetary geared motor, ratio 1/256, 39 rpm / 600 gf·cm @ max eff. | GGM | Motor: KD1230LB | Voltage: DC 2.4V | Gear Ratio: 1/256 | Output Speed (max eff.): 39 rpm | Output Torque (max eff.): 600 gf·cm | No-load Speed: 12500 rpm | Stall Torque: 23 gf·cm | Frame: ø12mm | Output Shaft: ø3mm, 2-M2 TAP DP2.5 | Gearhead Length L: 24.9 mm | Type: DC planetary geared motor | ||
| K12-1024-KD1230LB | GGM K12-1230 DC 2.4V planetary geared motor, ratio 1/1024, 9.8 rpm / 2000 gf·cm @ max eff. | GGM | Motor: KD1230LB | Voltage: DC 2.4V | Gear Ratio: 1/1024 | Output Speed (max eff.): 9.8 rpm | Output Torque (max eff.): 2000 gf·cm | No-load Speed: 12500 rpm | Stall Torque: 23 gf·cm | Frame: ø12mm | Output Shaft: ø3mm, 2-M2 TAP DP2.5 | Gearhead Length L: 28.2 mm | Type: DC planetary geared motor | ||
| K12-4096-KD1230LB | GGM K12-1230 DC 2.4V planetary geared motor, ratio 1/4096, 2.4 rpm / 2000 gf·cm @ max eff. | GGM | Motor: KD1230LB | Voltage: DC 2.4V | Gear Ratio: 1/4096 | Output Speed (max eff.): 2.4 rpm | Output Torque (max eff.): 2000 gf·cm | No-load Speed: 12500 rpm | Stall Torque: 23 gf·cm | Frame: ø12mm | Output Shaft: ø3mm, 2-M2 TAP DP2.5 | Gearhead Length L: 31.5 mm | Type: DC planetary geared motor | ||
| K12-0004-KD1230LC | GGM K12-1230 DC 3V planetary geared motor, ratio 1/4, 2575 rpm / 18 gf·cm @ max eff. | GGM | Motor: KD1230LC | Voltage: DC 3V | Gear Ratio: 1/4 | Output Speed (max eff.): 2575 rpm | Output Torque (max eff.): 18 gf·cm | No-load Speed: 12500 rpm | Stall Torque: 25 gf·cm | Frame: ø12mm | Output Shaft: ø3mm, 2-M2 TAP DP2.5 | Gearhead Length L: 15 mm | Type: DC planetary geared motor | ||
| K12-0016-KD1230LC | GGM K12-1230 DC 3V planetary geared motor, ratio 1/16, 643 rpm / 57 gf·cm @ max eff. | GGM | Motor: KD1230LC | Voltage: DC 3V | Gear Ratio: 1/16 | Output Speed (max eff.): 643 rpm | Output Torque (max eff.): 57 gf·cm | No-load Speed: 12500 rpm | Stall Torque: 25 gf·cm | Frame: ø12mm | Output Shaft: ø3mm, 2-M2 TAP DP2.5 | Gearhead Length L: 18.3 mm | Type: DC planetary geared motor | ||
| K12-0064-KD1230LC | GGM K12-1230 DC 3V planetary geared motor, ratio 1/64, 160 rpm / 183 gf·cm @ max eff. | GGM | Motor: KD1230LC | Voltage: DC 3V | Gear Ratio: 1/64 | Output Speed (max eff.): 160 rpm | Output Torque (max eff.): 183 gf·cm | No-load Speed: 12500 rpm | Stall Torque: 25 gf·cm | Frame: ø12mm | Output Shaft: ø3mm, 2-M2 TAP DP2.5 | Gearhead Length L: 21.6 mm | Type: DC planetary geared motor | ||
| K12-0256-KD1230LC | GGM K12-1230 DC 3V planetary geared motor, ratio 1/256, 40 rpm / 587 gf·cm @ max eff. | GGM | Motor: KD1230LC | Voltage: DC 3V | Gear Ratio: 1/256 | Output Speed (max eff.): 40 rpm | Output Torque (max eff.): 587 gf·cm | No-load Speed: 12500 rpm | Stall Torque: 25 gf·cm | Frame: ø12mm | Output Shaft: ø3mm, 2-M2 TAP DP2.5 | Gearhead Length L: 24.9 mm | Type: DC planetary geared motor | ||
| K12-1024-KD1230LC | GGM K12-1230 DC 3V planetary geared motor, ratio 1/1024, 10 rpm / 1880 gf·cm @ max eff. | GGM | Motor: KD1230LC | Voltage: DC 3V | Gear Ratio: 1/1024 | Output Speed (max eff.): 10 rpm | Output Torque (max eff.): 1880 gf·cm | No-load Speed: 12500 rpm | Stall Torque: 25 gf·cm | Frame: ø12mm | Output Shaft: ø3mm, 2-M2 TAP DP2.5 | Gearhead Length L: 28.2 mm | Type: DC planetary geared motor | ||
| K12-4096-KD1230LC | GGM K12-1230 DC 3V planetary geared motor, ratio 1/4096, 2.5 rpm / 2000 gf·cm @ max eff. | GGM | Motor: KD1230LC | Voltage: DC 3V | Gear Ratio: 1/4096 | Output Speed (max eff.): 2.5 rpm | Output Torque (max eff.): 2000 gf·cm | No-load Speed: 12500 rpm | Stall Torque: 25 gf·cm | Frame: ø12mm | Output Shaft: ø3mm, 2-M2 TAP DP2.5 | Gearhead Length L: 31.5 mm | Type: DC planetary geared motor | ||
| K12-0004-KD1230H1 | GGM K12-1230 DC 13V planetary geared motor, ratio 1/4, 2150 rpm / 17 gf·cm @ max eff. | GGM | Motor: KD1230H1 | Voltage: DC 13V | Gear Ratio: 1/4 | Output Speed (max eff.): 2150 rpm | Output Torque (max eff.): 17 gf·cm | No-load Speed: 11800 rpm | Stall Torque: 22 gf·cm | Frame: ø12mm | Output Shaft: ø3mm, 2-M2 TAP DP2.5 | Gearhead Length L: 15 mm | Type: DC planetary geared motor | ||
| K12-0016-KD1230H1 | GGM K12-1230 DC 13V planetary geared motor, ratio 1/16, 537 rpm / 55 gf·cm @ max eff. | GGM | Motor: KD1230H1 | Voltage: DC 13V | Gear Ratio: 1/16 | Output Speed (max eff.): 537 rpm | Output Torque (max eff.): 55 gf·cm | No-load Speed: 11800 rpm | Stall Torque: 22 gf·cm | Frame: ø12mm | Output Shaft: ø3mm, 2-M2 TAP DP2.5 | Gearhead Length L: 18.3 mm | Type: DC planetary geared motor | ||
| K12-0064-KD1230H1 | GGM K12-1230 DC 13V planetary geared motor, ratio 1/64, 134 rpm / 177 gf·cm @ max eff. | GGM | Motor: KD1230H1 | Voltage: DC 13V | Gear Ratio: 1/64 | Output Speed (max eff.): 134 rpm | Output Torque (max eff.): 177 gf·cm | No-load Speed: 11800 rpm | Stall Torque: 22 gf·cm | Frame: ø12mm | Output Shaft: ø3mm, 2-M2 TAP DP2.5 | Gearhead Length L: 21.6 mm | Type: DC planetary geared motor | ||
| K12-0256-KD1230H1 | GGM K12-1230 DC 13V planetary geared motor, ratio 1/256, 33 rpm / 566 gf·cm @ max eff. | GGM | Motor: KD1230H1 | Voltage: DC 13V | Gear Ratio: 1/256 | Output Speed (max eff.): 33 rpm | Output Torque (max eff.): 566 gf·cm | No-load Speed: 11800 rpm | Stall Torque: 22 gf·cm | Frame: ø12mm | Output Shaft: ø3mm, 2-M2 TAP DP2.5 | Gearhead Length L: 24.9 mm | Type: DC planetary geared motor | ||
| K12-1024-KD1230H1 | GGM K12-1230 DC 13V planetary geared motor, ratio 1/1024, 8.4 rpm / 1810 gf·cm @ max eff. | GGM | Motor: KD1230H1 | Voltage: DC 13V | Gear Ratio: 1/1024 | Output Speed (max eff.): 8.4 rpm | Output Torque (max eff.): 1810 gf·cm | No-load Speed: 11800 rpm | Stall Torque: 22 gf·cm | Frame: ø12mm | Output Shaft: ø3mm, 2-M2 TAP DP2.5 | Gearhead Length L: 28.2 mm | Type: DC planetary geared motor | ||
| K12-4096-KD1230H1 | GGM K12-1230 DC 13V planetary geared motor, ratio 1/4096, 2.1 rpm / 2000 gf·cm @ max eff. | GGM | Motor: KD1230H1 | Voltage: DC 13V | Gear Ratio: 1/4096 | Output Speed (max eff.): 2.1 rpm | Output Torque (max eff.): 2000 gf·cm | No-load Speed: 11800 rpm | Stall Torque: 22 gf·cm | Frame: ø12mm | Output Shaft: ø3mm, 2-M2 TAP DP2.5 | Gearhead Length L: 31.5 mm | Type: DC planetary geared motor |
