[GGM] — KGC BLDC Planetary Gearmotor KB3640S1-T (Ø37, DC 12V, 1/2–1/2430, with Brake)
Brushless DC Motors GGM

[GGM] — KGC BLDC Planetary Gearmotor KB3640S1-T (Ø37, DC 12V, 1/2–1/2430, with Brake)

Family ID: GGM-KGC-3640-S1-T

GGM KGC Ø37 BLDC planetary gearmotor KB3640S1-T, DC 12V, 32 gear ratios from 1/2 to 1/2430. Integrated brake and FG feedback (6 pulses/rev), 300 mm leads (no-PCB control), PWM speed control (GUN-type), max output torque 6 kgf·cm, output same direction as motor.

32 product codes available in this family

RFQ Cart (0)

Product Codes & Specifications

Product Code Description Brand Spec
KGC-0002-KB3640S1-T KGC BLDC gearmotor KB3640S1-T, 1/2, 2250 rpm / 0.4 kgf·cm (DC 12V) GGM Gear Ratio: 1/2 | Output Speed: 2250 rpm (at max. eff.) | Output Torque: 0.4 kgf·cm
KGC-0003-KB3640S1-T KGC BLDC gearmotor KB3640S1-T, 1/3, 1500 rpm / 0.6 kgf·cm (DC 12V) GGM Gear Ratio: 1/3 | Output Speed: 1500 rpm (at max. eff.) | Output Torque: 0.6 kgf·cm
KGC-0005-KB3640S1-T KGC BLDC gearmotor KB3640S1-T, 1/5, 900 rpm / 1 kgf·cm (DC 12V) GGM Gear Ratio: 1/5 | Output Speed: 900 rpm (at max. eff.) | Output Torque: 1 kgf·cm
KGC-0010-KB3640S1-T KGC BLDC gearmotor KB3640S1-T, 1/10, 450 rpm / 2 kgf·cm (DC 12V) GGM Gear Ratio: 1/10 | Output Speed: 450 rpm (at max. eff.) | Output Torque: 2 kgf·cm
KGC-0015-KB3640S1-T KGC BLDC gearmotor KB3640S1-T, 1/15, 300 rpm / 2.7 kgf·cm (DC 12V) GGM Gear Ratio: 1/15 | Output Speed: 300 rpm (at max. eff.) | Output Torque: 2.7 kgf·cm
KGC-0020-KB3640S1-T KGC BLDC gearmotor KB3640S1-T, 1/20, 225 rpm / 3.6 kgf·cm (DC 12V) GGM Gear Ratio: 1/20 | Output Speed: 225 rpm (at max. eff.) | Output Torque: 3.6 kgf·cm
KGC-0025-KB3640S1-T KGC BLDC gearmotor KB3640S1-T, 1/25, 180 rpm / 4.5 kgf·cm (DC 12V) GGM Gear Ratio: 1/25 | Output Speed: 180 rpm (at max. eff.) | Output Torque: 4.5 kgf·cm
KGC-0030-KB3640S1-T KGC BLDC gearmotor KB3640S1-T, 1/30, 150 rpm / 5.4 kgf·cm (DC 12V) GGM Gear Ratio: 1/30 | Output Speed: 150 rpm (at max. eff.) | Output Torque: 5.4 kgf·cm
KGC-0040-KB3640S1-T KGC BLDC gearmotor KB3640S1-T, 1/40, 112.5 rpm / 6 kgf·cm (DC 12V) GGM Gear Ratio: 1/40 | Output Speed: 112.5 rpm (at max. eff.) | Output Torque: 6 kgf·cm
KGC-0050-KB3640S1-T KGC BLDC gearmotor KB3640S1-T, 1/50, 90 rpm / 6 kgf·cm (DC 12V) GGM Gear Ratio: 1/50 | Output Speed: 90 rpm (at max. eff.) | Output Torque: 6 kgf·cm
KGC-0060-KB3640S1-T KGC BLDC gearmotor KB3640S1-T, 1/60, 75 rpm / 6 kgf·cm (DC 12V) GGM Gear Ratio: 1/60 | Output Speed: 75 rpm (at max. eff.) | Output Torque: 6 kgf·cm
KGC-0070-KB3640S1-T KGC BLDC gearmotor KB3640S1-T, 1/70, 64 rpm / 6 kgf·cm (DC 12V) GGM Gear Ratio: 1/70 | Output Speed: 64 rpm (at max. eff.) | Output Torque: 6 kgf·cm
KGC-0083-KB3640S1-T KGC BLDC gearmotor KB3640S1-T, 1/83, 54 rpm / 6 kgf·cm (DC 12V) GGM Gear Ratio: 1/83 | Output Speed: 54 rpm (at max. eff.) | Output Torque: 6 kgf·cm
KGC-0090-KB3640S1-T KGC BLDC gearmotor KB3640S1-T, 1/90, 50 rpm / 6 kgf·cm (DC 12V) GGM Gear Ratio: 1/90 | Output Speed: 50 rpm (at max. eff.) | Output Torque: 6 kgf·cm
KGC-0100-KB3640S1-T KGC BLDC gearmotor KB3640S1-T, 1/100, 45 rpm / 6 kgf·cm (DC 12V) GGM Gear Ratio: 1/100 | Output Speed: 45 rpm (at max. eff.) | Output Torque: 6 kgf·cm
KGC-0120-KB3640S1-T KGC BLDC gearmotor KB3640S1-T, 1/120, 37.5 rpm / 6 kgf·cm (DC 12V) GGM Gear Ratio: 1/120 | Output Speed: 37.5 rpm (at max. eff.) | Output Torque: 6 kgf·cm
KGC-0150-KB3640S1-T KGC BLDC gearmotor KB3640S1-T, 1/150, 30 rpm / 6 kgf·cm (DC 12V) GGM Gear Ratio: 1/150 | Output Speed: 30 rpm (at max. eff.) | Output Torque: 6 kgf·cm
KGC-0180-KB3640S1-T KGC BLDC gearmotor KB3640S1-T, 1/180, 25 rpm / 6 kgf·cm (DC 12V) GGM Gear Ratio: 1/180 | Output Speed: 25 rpm (at max. eff.) | Output Torque: 6 kgf·cm
KGC-0200-KB3640S1-T KGC BLDC gearmotor KB3640S1-T, 1/200, 22.5 rpm / 6 kgf·cm (DC 12V) GGM Gear Ratio: 1/200 | Output Speed: 22.5 rpm (at max. eff.) | Output Torque: 6 kgf·cm
KGC-0210-KB3640S1-T KGC BLDC gearmotor KB3640S1-T, 1/210, 21.4 rpm / 6 kgf·cm (DC 12V) GGM Gear Ratio: 1/210 | Output Speed: 21.4 rpm (at max. eff.) | Output Torque: 6 kgf·cm
KGC-0240-KB3640S1-T KGC BLDC gearmotor KB3640S1-T, 1/240, 18.7 rpm / 6 kgf·cm (DC 12V) GGM Gear Ratio: 1/240 | Output Speed: 18.7 rpm (at max. eff.) | Output Torque: 6 kgf·cm
KGC-0300-KB3640S1-T KGC BLDC gearmotor KB3640S1-T, 1/300, 15 rpm / 6 kgf·cm (DC 12V) GGM Gear Ratio: 1/300 | Output Speed: 15 rpm (at max. eff.) | Output Torque: 6 kgf·cm
KGC-0360-KB3640S1-T KGC BLDC gearmotor KB3640S1-T, 1/360, 12.5 rpm / 6 kgf·cm (DC 12V) GGM Gear Ratio: 1/360 | Output Speed: 12.5 rpm (at max. eff.) | Output Torque: 6 kgf·cm
KGC-0400-KB3640S1-T KGC BLDC gearmotor KB3640S1-T, 1/400, 11.2 rpm / 6 kgf·cm (DC 12V) GGM Gear Ratio: 1/400 | Output Speed: 11.2 rpm (at max. eff.) | Output Torque: 6 kgf·cm
KGC-0500-KB3640S1-T KGC BLDC gearmotor KB3640S1-T, 1/500, 9 rpm / 6 kgf·cm (DC 12V) GGM Gear Ratio: 1/500 | Output Speed: 9 rpm (at max. eff.) | Output Torque: 6 kgf·cm
KGC-0600-KB3640S1-T KGC BLDC gearmotor KB3640S1-T, 1/600, 7.5 rpm / 6 kgf·cm (DC 12V) GGM Gear Ratio: 1/600 | Output Speed: 7.5 rpm (at max. eff.) | Output Torque: 6 kgf·cm
KGC-0750-KB3640S1-T KGC BLDC gearmotor KB3640S1-T, 1/750, 6 rpm / 6 kgf·cm (DC 12V) GGM Gear Ratio: 1/750 | Output Speed: 6 rpm (at max. eff.) | Output Torque: 6 kgf·cm
KGC-0900-KB3640S1-T KGC BLDC gearmotor KB3640S1-T, 1/900, 5 rpm / 6 kgf·cm (DC 12V) GGM Gear Ratio: 1/900 | Output Speed: 5 rpm (at max. eff.) | Output Torque: 6 kgf·cm
KGC-1080-KB3640S1-T KGC BLDC gearmotor KB3640S1-T, 1/1080, 4.1 rpm / 6 kgf·cm (DC 12V) GGM Gear Ratio: 1/1080 | Output Speed: 4.1 rpm (at max. eff.) | Output Torque: 6 kgf·cm
KGC-1350-KB3640S1-T KGC BLDC gearmotor KB3640S1-T, 1/1350, 3.3 rpm / 6 kgf·cm (DC 12V) GGM Gear Ratio: 1/1350 | Output Speed: 3.3 rpm (at max. eff.) | Output Torque: 6 kgf·cm
KGC-1620-KB3640S1-T KGC BLDC gearmotor KB3640S1-T, 1/1620, 2.7 rpm / 6 kgf·cm (DC 12V) GGM Gear Ratio: 1/1620 | Output Speed: 2.7 rpm (at max. eff.) | Output Torque: 6 kgf·cm
KGC-2430-KB3640S1-T KGC BLDC gearmotor KB3640S1-T, 1/2430, 1.8 rpm / 6 kgf·cm (DC 12V) GGM Gear Ratio: 1/2430 | Output Speed: 1.8 rpm (at max. eff.) | Output Torque: 6 kgf·cm
