[GGM] — K42 BLDC Planetary Gearmotor KB4260S1 (Ø42, DC 12V, 1/4–1/3600, with Brake)

Family ID: GGM-K42-4260-S1

GGM K42 Ø42 BLDC planetary gearmotor KB4260S1, DC 12V, 21 gear ratios from 1/4 to 1/3600. Integrated brake and FG feedback (6 pulses/rev), PWM speed control (GUN-type controller), max output torque 30 kgf·cm, output rotates same direction as motor.

21 product codes available in this family

RFQ Cart (0)

Product Codes & Specifications

Product Code Description Brand Spec
K42-0004-KB4260S1 K42 BLDC gearmotor KB4260S1, 1/4, 1000 rpm / 1.4 kgf·cm GGM Gear Ratio: 1/4 | Output Speed: 1000 rpm (at max. eff.) | Output Torque: 1.4 kgf·cm
K42-0014-KB4260S1 K42 BLDC gearmotor KB4260S1, 1/14, 286 rpm / 4.4 kgf·cm GGM Gear Ratio: 1/14 | Output Speed: 286 rpm (at max. eff.) | Output Torque: 4.4 kgf·cm
K42-0017-KB4260S1 K42 BLDC gearmotor KB4260S1, 1/17, 235 rpm / 5.3 kgf·cm GGM Gear Ratio: 1/17 | Output Speed: 235 rpm (at max. eff.) | Output Torque: 5.3 kgf·cm
K42-0024-KB4260S1 K42 BLDC gearmotor KB4260S1, 1/24, 167 rpm / 7.5 kgf·cm GGM Gear Ratio: 1/24 | Output Speed: 167 rpm (at max. eff.) | Output Torque: 7.5 kgf·cm
K42-0049-KB4260S1 K42 BLDC gearmotor KB4260S1, 1/49, 82 rpm / 14 kgf·cm GGM Gear Ratio: 1/49 | Output Speed: 82 rpm (at max. eff.) | Output Torque: 14 kgf·cm
K42-0061-KB4260S1 K42 BLDC gearmotor KB4260S1, 1/61, 66 rpm / 17 kgf·cm GGM Gear Ratio: 1/61 | Output Speed: 66 rpm (at max. eff.) | Output Torque: 17 kgf·cm
K42-0084-KB4260S1 K42 BLDC gearmotor KB4260S1, 1/84, 48 rpm / 24 kgf·cm GGM Gear Ratio: 1/84 | Output Speed: 48 rpm (at max. eff.) | Output Torque: 24 kgf·cm
K42-0104-KB4260S1 K42 BLDC gearmotor KB4260S1, 1/104, 38 rpm / 29 kgf·cm GGM Gear Ratio: 1/104 | Output Speed: 38 rpm (at max. eff.) | Output Torque: 29 kgf·cm
K42-0144-KB4260S1 K42 BLDC gearmotor KB4260S1, 1/144, 28 rpm / 30 kgf·cm GGM Gear Ratio: 1/144 | Output Speed: 28 rpm (at max. eff.) | Output Torque: 30 kgf·cm
K42-0212-KB4260S1 K42 BLDC gearmotor KB4260S1, 1/212, 18.9 rpm / 30 kgf·cm GGM Gear Ratio: 1/212 | Output Speed: 18.9 rpm (at max. eff.) | Output Torque: 30 kgf·cm
K42-0263-KB4260S1 K42 BLDC gearmotor KB4260S1, 1/263, 15.2 rpm / 30 kgf·cm GGM Gear Ratio: 1/263 | Output Speed: 15.2 rpm (at max. eff.) | Output Torque: 30 kgf·cm
K42-0294-KB4260S1 K42 BLDC gearmotor KB4260S1, 1/294, 13.6 rpm / 30 kgf·cm GGM Gear Ratio: 1/294 | Output Speed: 13.6 rpm (at max. eff.) | Output Torque: 30 kgf·cm
K42-0504-KB4260S1 K42 BLDC gearmotor KB4260S1, 1/504, 7.9 rpm / 30 kgf·cm GGM Gear Ratio: 1/504 | Output Speed: 7.9 rpm (at max. eff.) | Output Torque: 30 kgf·cm
K42-0624-KB4260S1 K42 BLDC gearmotor KB4260S1, 1/624, 6.4 rpm / 30 kgf·cm GGM Gear Ratio: 1/624 | Output Speed: 6.4 rpm (at max. eff.) | Output Torque: 30 kgf·cm
K42-0720-KB4260S1 K42 BLDC gearmotor KB4260S1, 1/720, 5.6 rpm / 30 kgf·cm GGM Gear Ratio: 1/720 | Output Speed: 5.6 rpm (at max. eff.) | Output Torque: 30 kgf·cm
K42-0864-KB4260S1 K42 BLDC gearmotor KB4260S1, 1/864, 4.6 rpm / 30 kgf·cm GGM Gear Ratio: 1/864 | Output Speed: 4.6 rpm (at max. eff.) | Output Torque: 30 kgf·cm
K42-1062-KB4260S1 K42 BLDC gearmotor KB4260S1, 1/1062, 3.8 rpm / 30 kgf·cm GGM Gear Ratio: 1/1062 | Output Speed: 3.8 rpm (at max. eff.) | Output Torque: 30 kgf·cm
K42-1470-KB4260S1 K42 BLDC gearmotor KB4260S1, 1/1470, 2.7 rpm / 30 kgf·cm GGM Gear Ratio: 1/1470 | Output Speed: 2.7 rpm (at max. eff.) | Output Torque: 30 kgf·cm
K42-2500-KB4260S1 K42 BLDC gearmotor KB4260S1, 1/2500, 1.6 rpm / 30 kgf·cm GGM Gear Ratio: 1/2500 | Output Speed: 1.6 rpm (at max. eff.) | Output Torque: 30 kgf·cm
K42-3000-KB4260S1 K42 BLDC gearmotor KB4260S1, 1/3000, 1.3 rpm / 30 kgf·cm GGM Gear Ratio: 1/3000 | Output Speed: 1.3 rpm (at max. eff.) | Output Torque: 30 kgf·cm
K42-3600-KB4260S1 K42 BLDC gearmotor KB4260S1, 1/3600, 1.1 rpm / 30 kgf·cm GGM Gear Ratio: 1/3600 | Output Speed: 1.1 rpm (at max. eff.) | Output Torque: 30 kgf·cm
