![[GGM] — KWC-3429-P2 Worm Geared Motor (DC 24V, 1/25–1/1500)](https://img.prosourcemro.com/2026/06/0609-6-1024x808.png)
DC
GGM
[GGM] — KWC-3429-P2 Worm Geared Motor (DC 24V, 1/25–1/1500)
Family ID: GGM-KWC-3429-P2
GGM KWC round-flange worm geared motor, KD3429P2 base, DC 24V. 19 gear ratios 1/25 to 1/1500, output torque 0.2–6 kgf·cm; ø12 output shaft, P.C.D ø46 flange mount.
19 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| KWC-0025-KD3429P2 | KWC worm gearhead KD3429P2, 1/25, DC 24V | GGM | Gear Ratio: 1/25 · Output Speed: 320 rpm · Output Torque: 0.2 kgf·cm | ||
| KWC-0030-KD3429P2 | KWC worm gearhead KD3429P2, 1/30, DC 24V | GGM | Gear Ratio: 1/30 · Output Speed: 267 rpm · Output Torque: 0.3 kgf·cm | ||
| KWC-0050-KD3429P2 | KWC worm gearhead KD3429P2, 1/50, DC 24V | GGM | Gear Ratio: 1/50 · Output Speed: 160 rpm · Output Torque: 0.4 kgf·cm | ||
| KWC-0060-KD3429P2 | KWC worm gearhead KD3429P2, 1/60, DC 24V | GGM | Gear Ratio: 1/60 · Output Speed: 133 rpm · Output Torque: 0.5 kgf·cm | ||
| KWC-0075-KD3429P2 | KWC worm gearhead KD3429P2, 1/75, DC 24V | GGM | Gear Ratio: 1/75 · Output Speed: 107 rpm · Output Torque: 0.6 kgf·cm | ||
| KWC-0100-KD3429P2 | KWC worm gearhead KD3429P2, 1/100, DC 24V | GGM | Gear Ratio: 1/100 · Output Speed: 80 rpm · Output Torque: 0.8 kgf·cm | ||
| KWC-0125-KD3429P2 | KWC worm gearhead KD3429P2, 1/125, DC 24V | GGM | Gear Ratio: 1/125 · Output Speed: 64 rpm · Output Torque: 1 kgf·cm | ||
| KWC-0150-KD3429P2 | KWC worm gearhead KD3429P2, 1/150, DC 24V | GGM | Gear Ratio: 1/150 · Output Speed: 53 rpm · Output Torque: 1.2 kgf·cm | ||
| KWC-0200-KD3429P2 | KWC worm gearhead KD3429P2, 1/200, DC 24V | GGM | Gear Ratio: 1/200 · Output Speed: 40 rpm · Output Torque: 1.4 kgf·cm | ||
| KWC-0250-KD3429P2 | KWC worm gearhead KD3429P2, 1/250, DC 24V | GGM | Gear Ratio: 1/250 · Output Speed: 32 rpm · Output Torque: 1.7 kgf·cm | ||
| KWC-0300-KD3429P2 | KWC worm gearhead KD3429P2, 1/300, DC 24V | GGM | Gear Ratio: 1/300 · Output Speed: 26.7 rpm · Output Torque: 2.1 kgf·cm | ||
| KWC-0375-KD3429P2 | KWC worm gearhead KD3429P2, 1/375, DC 24V | GGM | Gear Ratio: 1/375 · Output Speed: 21.3 rpm · Output Torque: 2.6 kgf·cm | ||
| KWC-0500-KD3429P2 | KWC worm gearhead KD3429P2, 1/500, DC 24V | GGM | Gear Ratio: 1/500 · Output Speed: 16 rpm · Output Torque: 3.5 kgf·cm | ||
| KWC-0600-KD3429P2 | KWC worm gearhead KD3429P2, 1/600, DC 24V | GGM | Gear Ratio: 1/600 · Output Speed: 13.3 rpm · Output Torque: 3.8 kgf·cm | ||
| KWC-0750-KD3429P2 | KWC worm gearhead KD3429P2, 1/750, DC 24V | GGM | Gear Ratio: 1/750 · Output Speed: 10.7 rpm · Output Torque: 4.7 kgf·cm | ||
| KWC-0900-KD3429P2 | KWC worm gearhead KD3429P2, 1/900, DC 24V | GGM | Gear Ratio: 1/900 · Output Speed: 8.9 rpm · Output Torque: 6 kgf·cm | ||
| KWC-1050-KD3429P2 | KWC worm gearhead KD3429P2, 1/1050, DC 24V | GGM | Gear Ratio: 1/1050 · Output Speed: 7.6 rpm · Output Torque: 6 kgf·cm | ||
| KWC-1350-KD3429P2 | KWC worm gearhead KD3429P2, 1/1350, DC 24V | GGM | Gear Ratio: 1/1350 · Output Speed: 5.9 rpm · Output Torque: 6 kgf·cm | ||
| KWC-1500-KD3429P2 | KWC worm gearhead KD3429P2, 1/1500, DC 24V | GGM | Gear Ratio: 1/1500 · Output Speed: 5.3 rpm · Output Torque: 6 kgf·cm |
