DC
GGM
[GGM] — KGP-3429-S2 Flange Geared DC Motor (DC 24V, 5200rpm base, 2 ratios 1/62-1/116)
Family ID: GGM-KGP3429-S2
GGM KGP-3429-S2 flange-mount geared DC motor, DC 24V (5200 rpm base motor). 2 gear ratios 1/62-1/116, output torque up to 2.7 kgf·cm, ø10.5 output bore with ø3 spring pin, 4-ø4.5 flange mounting. Output rotation same as motor.
2 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| KGP-0062-KD3429S2-FL | KGP-3429-S2 Flange geared, 1/62, 72.6rpm, 1.5kgf·cm | GGM | Gear Ratio: 1/62 | Output Speed: 72.6 rpm | Output Torque: 1.5 kgf·cm | Mount/Output: Flange, ø10.5 bore | ||
| KGP-0116-KD3429S2-FL | KGP-3429-S2 Flange geared, 1/116, 38.8rpm, 2.7kgf·cm | GGM | Gear Ratio: 1/116 | Output Speed: 38.8 rpm | Output Torque: 2.7 kgf·cm | Mount/Output: Flange, ø10.5 bore |
