Converter Units
MITSUBISHI ELECTRIC
[MITSUBISHI ELECTRIC] — FREQROL FR-CC2-H Converter Unit (400V, 315-630kW, for FR-A842 inverter)
Family ID: MEL-FRCC2-H
Mitsubishi FREQROL FR-CC2-H converter unit for the FR-A842 separate-converter inverter, three-phase 400V, 315-630kW. DC 430-780V bus output, built-in DC reactor, IP00, forced-air cooling.
7 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| FR-CC2-H315K | FR-CC2-H315K converter unit, 315kW, DC430-780V, for FR-A842 | MITSUBISHI ELECTRIC | Type: Converter unit (for FR-A842 separate-converter inverter) · Applied Motor: 315 kW · Overload Rating: 200% 60s / 250% 3s · DC Output Voltage: DC 430-780V · Rated Input Current: 610 A · Power Supply Capacity: 465 kVA · Input: 3-phase 380-500V 50/60Hz · DC Reactor: Built-in · Cooling: Forced-air cooling · Protection: IP00 (open chassis) · Weight: 210 kg | ||
| FR-CC2-H355K | FR-CC2-H355K converter unit, 355kW, DC430-780V, for FR-A842 | MITSUBISHI ELECTRIC | Type: Converter unit (for FR-A842 separate-converter inverter) · Applied Motor: 355 kW · Overload Rating: 200% 60s / 250% 3s · DC Output Voltage: DC 430-780V · Rated Input Current: 683 A · Power Supply Capacity: 521 kVA · Input: 3-phase 380-500V 50/60Hz · DC Reactor: Built-in · Cooling: Forced-air cooling · Protection: IP00 (open chassis) · Weight: 213 kg | ||
| FR-CC2-H400K | FR-CC2-H400K converter unit, 400kW, DC430-780V, for FR-A842 | MITSUBISHI ELECTRIC | Type: Converter unit (for FR-A842 separate-converter inverter) · Applied Motor: 400 kW · Overload Rating: 200% 60s / 250% 3s · DC Output Voltage: DC 430-780V · Rated Input Current: 770 A · Power Supply Capacity: 587 kVA · Input: 3-phase 380-500V 50/60Hz · DC Reactor: Built-in · Cooling: Forced-air cooling · Protection: IP00 (open chassis) · Weight: 282 kg | ||
| FR-CC2-H450K | FR-CC2-H450K converter unit, 450kW, DC430-780V, for FR-A842 | MITSUBISHI ELECTRIC | Type: Converter unit (for FR-A842 separate-converter inverter) · Applied Motor: 450 kW · Overload Rating: 200% 60s / 250% 3s · DC Output Voltage: DC 430-780V · Rated Input Current: 866 A · Power Supply Capacity: 660 kVA · Input: 3-phase 380-500V 50/60Hz · DC Reactor: Built-in · Cooling: Forced-air cooling · Protection: IP00 (open chassis) · Weight: 285 kg | ||
| FR-CC2-H500K | FR-CC2-H500K converter unit, 500kW, DC430-780V, for FR-A842 | MITSUBISHI ELECTRIC | Type: Converter unit (for FR-A842 separate-converter inverter) · Applied Motor: 500 kW · Overload Rating: 150% 60s / 200% 3s · DC Output Voltage: DC 430-780V · Rated Input Current: 962 A · Power Supply Capacity: 733 kVA · Input: 3-phase 380-500V 50/60Hz · DC Reactor: Built-in · Cooling: Forced-air cooling · Protection: IP00 (open chassis) · Weight: 288 kg | ||
| FR-CC2-H560K | FR-CC2-H560K converter unit, 560kW, DC430-780V, for FR-A842 | MITSUBISHI ELECTRIC | Type: Converter unit (for FR-A842 separate-converter inverter) · Applied Motor: 560 kW · Overload Rating: 120% 60s / 150% 3s · DC Output Voltage: DC 430-780V · Rated Input Current: 1094 A · Power Supply Capacity: 833 kVA · Input: 3-phase 380-500V 50/60Hz · DC Reactor: Built-in · Cooling: Forced-air cooling · Protection: IP00 (open chassis) · Weight: 293 kg | ||
| FR-CC2-H630K | FR-CC2-H630K converter unit, 630kW, DC430-780V, for FR-A842 | MITSUBISHI ELECTRIC | Type: Converter unit (for FR-A842 separate-converter inverter) · Applied Motor: 630 kW · Overload Rating: 110% 60s / 120% 3s · DC Output Voltage: DC 430-780V · Rated Input Current: 1212 A · Power Supply Capacity: 924 kVA · Input: 3-phase 380-500V 50/60Hz · DC Reactor: Built-in · Cooling: Forced-air cooling · Protection: IP00 (open chassis) · Weight: 294 kg |
