[OMRON] — E3C-LDA Laser Photoelectric Sensor Head (Diffuse / Retro-reflective, Spot/Line/Area)
Family ID: OMRON-E3C-LD-HEAD
OMRON E3C-LDA series laser photoelectric sensor heads with separate digital amplifier. Variable laser beam — spot, line, or area detection. E3C-LD11N 2M: diffuse-reflective, variable spot, sensing distance 1 m, Class 2. E3C-LR11N 2M: coaxial retro-reflective with MSR function, variable spot, 7 m, Class 2 (requires reflector E39-R12/R13/R14/RS4/RS5, sold separately). E3C-LR12N 2M: coaxial retro-reflective with MSR function, 2.0 mm fixed spot, 7 m, Class 1. Beam Units (E39-P11/P21 for LD11N, E39-P31/P41 for LR11N) for line/area beam sold separately. Compatible amplifier: E3C-LDA series only. Cable length: 2 m.
3 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| E3C-LD11N 2M | Diffuse-reflective laser sensor head, variable spot, 1m, Class 2, 2m cable | OMRON | Model: E3C-LD11N 2M | Sensing Method: Diffuse-reflective | Beam Shape: Spot (variable) | Sensing Distance: 1 m | Laser Class: Class 2 | Cable Length: 2 m | Compatible Amplifier: E3C-LDA series only | Optional Beam Unit: E39-P11 (line beam) / E39-P21 (area beam) — sold separately | ||
| E3C-LR11N 2M | Retro-reflective MSR laser sensor head, variable spot, 7m, Class 2, 2m cable | OMRON | Model: E3C-LR11N 2M | Sensing Method: Coaxial Retro-reflective with MSR function | Beam Shape: Spot (variable) | Sensing Distance: 7 m | Laser Class: Class 2 | Cable Length: 2 m | Compatible Amplifier: E3C-LDA series only | Required Reflector: E39-R12 (23x23mm) / E39-R13 (7x7mm) / E39-R14 (transparent) / E39-RS4/RS5 sheet — sold separately | Optional Beam Unit: E39-P31 (line beam) / E39-P41 (area beam) — sold separately | Note: Use E39-R12/R13 for dist 400mm or more; E39-R14 for less than 400mm | ||
| E3C-LR12N 2M | Retro-reflective MSR laser sensor head, 2.0mm fixed spot, 7m, Class 1, 2m cable | OMRON | Model: E3C-LR12N 2M | Sensing Method: Coaxial Retro-reflective with MSR function | Beam Shape: Spot (2.0 mm fixed dia.) | Sensing Distance: 7 m | Laser Class: Class 1 | Cable Length: 2 m | Compatible Amplifier: E3C-LDA series only | Required Reflector: E39-R12 / E39-R13 / E39-R14 / E39-RS4 / E39-RS5 — sold separately |
