Photoelectric
Omron
[OMRON] — E3NC-LA Compact Laser Sensor Amplifier Unit (NPN/PNP, Pre-wired / Wire-saving / M8 / Network)
Family ID: OMRON-E3NC-LA
OMRON E3NC-L Series laser sensor amplifier units. Compatible sensor head: E3NC-LH series only. Pre-wired 2 m (E3NC-LA21/51 2M): 2 outputs + 1 input, NPN/PNP. Wire-saving Connector (E3NC-LA7/9): 1 output + 1 input, NPN/PNP (requires E3X-CN21 master + E3X-CN22 slave connector, sold separately). M8 Connector (E3NC-LA24/54): 1 output + 1 input, NPN/PNP (requires XS3F-M421/422 cable, sold separately). E3NC-LA0: for Sensor Communications Unit (E3NW-ECT/CRT/CCL), network connection only. Mounting bracket E39-L143 and DIN track PFP-100N/50N sold separately.
7 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| E3NC-LA21 2M | L-series amplifier NPN 2out+1in pre-wired 2m | OMRON | Model: E3NC-LA21 2M | Output: NPN 2 outputs + 1 input | Connection: Pre-wired 2 m | Compatible Head: E3NC-LH series only | Cover: E39-G24 (sold separately) | ||
| E3NC-LA51 2M | L-series amplifier PNP 2out+1in pre-wired 2m | OMRON | Model: E3NC-LA51 2M | Output: PNP 2 outputs + 1 input | Connection: Pre-wired 2 m | Compatible Head: E3NC-LH series only | Cover: E39-G24 (sold separately) | ||
| E3NC-LA7 | L-series amplifier NPN 1out+1in Wire-saving Connector | OMRON | Model: E3NC-LA7 | Output: NPN 1 output + 1 input | Connection: Wire-saving Connector | Required Connector: E3X-CN21 master + E3X-CN22 slave (sold separately) | Compatible Head: E3NC-LH series only | Cover: E39-G24 (sold separately) | ||
| E3NC-LA9 | L-series amplifier PNP 1out+1in Wire-saving Connector | OMRON | Model: E3NC-LA9 | Output: PNP 1 output + 1 input | Connection: Wire-saving Connector | Required Connector: E3X-CN21 master + E3X-CN22 slave (sold separately) | Compatible Head: E3NC-LH series only | Cover: E39-G24 (sold separately) | ||
| E3NC-LA24 | L-series amplifier NPN 1out+1in M8 Connector | OMRON | Model: E3NC-LA24 | Output: NPN 1 output + 1 input | Connection: M8 Connector | Required Cable: XS3F-M421-402-A (2m) / XS3F-M421-405-A (5m) straight or XS3F-M422 L-shaped (sold separately) | Compatible Head: E3NC-LH series only | Cover: E39-G24 (sold separately) | ||
| E3NC-LA54 | L-series amplifier PNP 1out+1in M8 Connector | OMRON | Model: E3NC-LA54 | Output: PNP 1 output + 1 input | Connection: M8 Connector | Required Cable: XS3F-M421-402-A (2m) / XS3F-M421-405-A (5m) straight or XS3F-M422 L-shaped (sold separately) | Compatible Head: E3NC-LH series only | Cover: E39-G24 (sold separately) | ||
| E3NC-LA0 | L-series amplifier for Sensor Communications Unit (E3NW-ECT/CRT/CCL network) | OMRON | Model: E3NC-LA0 | Output: Network only (no standalone output) | Connection: Connector for Sensor Communications Unit | Compatible Head: E3NC-LH series only | Required: E3NW-ECT / E3NW-CRT / E3NW-CCL Sensor Communications Unit | Cover: E39-G24 (sold separately) |
