Temperature Controller
Omron
[OMRON] — E5AN-H Advanced Digital Temperature Controller (96x96mm, High Resolution, Logic Operations)
Family ID: OMRON-E5AN-H
A New High-performance Controller: High Resolution, High Speed, and High Input Accuracy. Logic Operations and Preventive Maintenance Function. 1/4 DIN 96x96x78mm. Basic and Valve control methods. Requires Control Output Unit (E53-RN/QN/Q3/Q4/C3N/C3DN/V34N/V35N, sold separately).
17 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| E5AN-HAA2HBM-500 | Basic, 2 aux, Control Output ×2, HB:1, 2 event inputs, RSP:4~20mA, 100~240VAC, Black | OMRON | Type: Main Unit | Size: 96x96x78mm | Control Method: Basic | Aux Outputs: 2 | Control Output: Unit×2 | Heater Burnout: 1 | Event Inputs: 2 | RSP: 4~20mA input | Power Supply: 100~240VAC | Case: Black | ||
| E5AN-HAA2HHBFM-500 | Basic, 2 aux, Control Output ×2, HB:2, 2 event inputs, Transfer output, RSP:4~20mA, 100~240VAC, Black | OMRON | Type: Main Unit | Size: 96x96x78mm | Control Method: Basic | Aux Outputs: 2 | Control Output: Unit×2 | Heater Burnout: 2 | Event Inputs: 2 | Transfer Output: 4~20mA | RSP: 4~20mA input | Power Supply: 100~240VAC | Case: Black | ||
| E5AN-HAA3BFM-500 | Basic, 3 aux, Control Output ×2, 2 event inputs, Transfer output, RSP:4~20mA, 100~240VAC, Black | OMRON | Type: Main Unit | Size: 96x96x78mm | Control Method: Basic | Aux Outputs: 3 | Control Output: Unit×2 | Event Inputs: 2 | Transfer Output: 4~20mA | RSP: 4~20mA input | Power Supply: 100~240VAC | Case: Black | ||
| E5AN-HAA2HBMD-500 | Basic, 2 aux, Control Output ×2, HB:1, 2 event inputs, RSP:4~20mA, 24VAC/VDC, Black | OMRON | Type: Main Unit | Size: 96x96x78mm | Control Method: Basic | Aux Outputs: 2 | Control Output: Unit×2 | Heater Burnout: 1 | Event Inputs: 2 | RSP: 4~20mA input | Power Supply: 24VAC/VDC | Case: Black | ||
| E5AN-HAA2HHBFMD-500 | Basic, 2 aux, Control Output ×2, HB:2, 2 event inputs, Transfer output, RSP:4~20mA, 24VAC/VDC, Black | OMRON | Type: Main Unit | Size: 96x96x78mm | Control Method: Basic | Aux Outputs: 2 | Control Output: Unit×2 | Heater Burnout: 2 | Event Inputs: 2 | Transfer Output: 4~20mA | RSP: 4~20mA input | Power Supply: 24VAC/VDC | Case: Black | ||
| E5AN-HAA3BFMD-500 | Basic, 3 aux, Control Output ×2, 2 event inputs, Transfer output, RSP:4~20mA, 24VAC/VDC, Black | OMRON | Type: Main Unit | Size: 96x96x78mm | Control Method: Basic | Aux Outputs: 3 | Control Output: Unit×2 | Event Inputs: 2 | Transfer Output: 4~20mA | RSP: 4~20mA input | Power Supply: 24VAC/VDC | Case: Black | ||
| E5AN-HAA2HBM-W-500 | Basic, 2 aux, Control Output ×2, HB:1, 2 event inputs, RSP:4~20mA, 100~240VAC, Silver | OMRON | Type: Main Unit | Size: 96x96x78mm | Control Method: Basic | Aux Outputs: 2 | Control Output: Unit×2 | Heater Burnout: 1 | Event Inputs: 2 | RSP: 4~20mA input | Power Supply: 100~240VAC | Case: Silver | ||
| E5AN-HAA2HHBFM-W-500 | Basic, 2 aux, Control Output ×2, HB:2, 2 event inputs, Transfer output, RSP:4~20mA, 100~240VAC, Silver | OMRON | Type: Main Unit | Size: 96x96x78mm | Control Method: Basic | Aux Outputs: 2 | Control Output: Unit×2 | Heater Burnout: 2 | Event Inputs: 2 | Transfer Output: 4~20mA | RSP: 4~20mA input | Power Supply: 100~240VAC | Case: Silver | ||
| E5AN-HAA2HBMD-W-500 | Basic, 2 aux, Control Output ×2, HB:1, 2 event inputs, RSP:4~20mA, 24VAC/VDC, Silver | OMRON | Type: Main Unit | Size: 96x96x78mm | Control Method: Basic | Aux Outputs: 2 | Control Output: Unit×2 | Heater Burnout: 1 | Event Inputs: 2 | RSP: 4~20mA input | Power Supply: 24VAC/VDC | Case: Silver | ||
| E53-RN | Output Unit: Relay output, SPST-NO, 250VAC 5A | OMRON | Type: Output Unit | Output: Relay (SPST-NO) | Rating: 250VAC 5A resistive | Electrical Life: 100,000 ops | ||
| E53-QN | Output Unit: Voltage output (SSR), 12VDC PNP, 40mA | OMRON | Type: Output Unit | Output: Voltage (for driving SSR) | Voltage: 12VDC (PNP) | Max Load Current: 40mA | ||
| E53-Q3 | Output Unit: Voltage output (SSR), 24VDC NPN, 20mA | OMRON | Type: Output Unit | Output: Voltage (for driving SSR) | Voltage: 24VDC (NPN) | Max Load Current: 20mA | ||
| E53-Q4 | Output Unit: Voltage output (SSR), 24VDC PNP, 20mA | OMRON | Type: Output Unit | Output: Voltage (for driving SSR) | Voltage: 24VDC (PNP) | Max Load Current: 20mA | ||
| E53-C3N | Output Unit: Current output, 4~20mA DC, 600Ω max | OMRON | Type: Output Unit | Output: Current | Range: 4~20mA DC | Max Load: 600 Ohm | Resolution: approx. 10,000 | ||
| E53-C3DN | Output Unit: Current output, 0~20mA DC, 600Ω max | OMRON | Type: Output Unit | Output: Current | Range: 0~20mA DC | Max Load: 600 Ohm | Resolution: approx. 10,000 | ||
| E53-V34N | Output Unit: Linear voltage output, 0~10VDC, 1kΩ min | OMRON | Type: Output Unit | Output: Linear Voltage | Range: 0~10VDC | Min Load: 1 kOhm | Resolution: approx. 10,000 | ||
| E53-V35N | Output Unit: Linear voltage output, 0~5VDC, 1kΩ min | OMRON | Type: Output Unit | Output: Linear Voltage | Range: 0~5VDC | Min Load: 1 kOhm | Resolution: approx. 10,000 |
