![[OMRON] — E6F-C Rugged Incremental Rotary Encoder (60mm dia., Complementary/NPN, 12~24VDC)](https://img.prosourcemro.com/2026/05/001-412-1024x683.png)
Rotary Encoder
Omron
[OMRON] — E6F-C Rugged Incremental Rotary Encoder (60mm dia., Complementary/NPN, 12~24VDC)
Family ID: OMRON-E6F
OMRON E6F-C Series 60mm rugged incremental rotary encoder. 12~24 VDC. Cable 2m. Complementary output: 100/200/360/500/600/1,000 P/R. NPN open-collector output: 1,000 P/R. A/B/Z phases.
7 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| E6F-CWZ5G 100P/R 2M | E6F-C Complementary 100P/R 2m | OMRON | Output Type: Complementary output | Power Supply: 12~24 VDC | Resolution: 100P/R | Output Phases: A, B, Z | Cable: 2 m | Encoder Type: Incremental | Diameter: 60 mm | ||
| E6F-CWZ5G 200P/R 2M | E6F-C Complementary 200P/R 2m | OMRON | Output Type: Complementary output | Power Supply: 12~24 VDC | Resolution: 200P/R | Output Phases: A, B, Z | Cable: 2 m | Encoder Type: Incremental | Diameter: 60 mm | ||
| E6F-CWZ5G 360P/R 2M | E6F-C Complementary 360P/R 2m | OMRON | Output Type: Complementary output | Power Supply: 12~24 VDC | Resolution: 360P/R | Output Phases: A, B, Z | Cable: 2 m | Encoder Type: Incremental | Diameter: 60 mm | ||
| E6F-CWZ5G 500P/R 2M | E6F-C Complementary 500P/R 2m | OMRON | Output Type: Complementary output | Power Supply: 12~24 VDC | Resolution: 500P/R | Output Phases: A, B, Z | Cable: 2 m | Encoder Type: Incremental | Diameter: 60 mm | ||
| E6F-CWZ5G 600P/R 2M | E6F-C Complementary 600P/R 2m | OMRON | Output Type: Complementary output | Power Supply: 12~24 VDC | Resolution: 600P/R | Output Phases: A, B, Z | Cable: 2 m | Encoder Type: Incremental | Diameter: 60 mm | ||
| E6F-CWZ5G 1,000P/R 2M | E6F-C Complementary 1,000P/R 2m | OMRON | Output Type: Complementary output | Power Supply: 12~24 VDC | Resolution: 1,000P/R | Output Phases: A, B, Z | Cable: 2 m | Encoder Type: Incremental | Diameter: 60 mm | ||
| E6F-CWZ5C 1,000P/R 2M | E6F-C NPN OC 1000P/R 2m | OMRON | Output Type: NPN open-collector output | Power Supply: 12~24 VDC | Resolution: 1,000 P/R | Output Phases: A, B, Z | Cable: 2 m | Encoder Type: Incremental | Diameter: 60 mm |
