Relays
Omron
[OMRON] — G3FM SSR (100μA Leakage, No Bleeder Resistor, 0.5A AC/DC, 5/12/24VDC)
Family ID: OMRON-G3FM
100-μA-max. Leakage Current, No Bleeder Resistor Required
16 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| G3FM-2R5SLN DC5 | G3FM 0.5A AC/DC 5 VDC | OMRON | Type: G3FM SSR (Photo-voltage coupler) | Load: 0.5A / 24-240VAC or 24-110VDC | Input Voltage: 5 VDC | Zero Cross: No | Indicator: Yes | Leakage Current: 100 μA max. | Isolation: Photo-voltage coupler | Note: Specify rated input voltage (5/12/24 VDC) when ordering | ||
| G3FM-2R5SLN DC12 | G3FM 0.5A AC/DC 12 VDC | OMRON | Type: G3FM SSR (Photo-voltage coupler) | Load: 0.5A / 24-240VAC or 24-110VDC | Input Voltage: 12 VDC | Zero Cross: No | Indicator: Yes | Leakage Current: 100 μA max. | Isolation: Photo-voltage coupler | Note: Specify rated input voltage (5/12/24 VDC) when ordering | ||
| G3FM-2R5SLN DC24 | G3FM 0.5A AC/DC 24 VDC | OMRON | Type: G3FM SSR (Photo-voltage coupler) | Load: 0.5A / 24-240VAC or 24-110VDC | Input Voltage: 24 VDC | Zero Cross: No | Indicator: Yes | Leakage Current: 100 μA max. | Isolation: Photo-voltage coupler | Note: Specify rated input voltage (5/12/24 VDC) when ordering | ||
| PYFZ-08 | G3FM Socket Front Screw (t | OMRON | Type: G3FM Connection Socket | Terminal: Screw (terminal cover) | Mounting: Front | ||
| PYFZ-08-E | G3FM Socket Front Screw M3 | OMRON | Type: G3FM Connection Socket | Terminal: Screw M3 finger-protect | Mounting: Front | ||
| PYF08A-N | G3FM Socket Front Screw M3 | OMRON | Type: G3FM Connection Socket | Terminal: Screw M3 finger-protect | Mounting: Front | ||
| PYF-08-PU | G3FM Socket Front Push-In | OMRON | Type: G3FM Connection Socket | Terminal: Push-In Plus | Mounting: Front | ||
| PY08-02 | G3FM Socket Back PCB | OMRON | Type: G3FM Connection Socket | Terminal: PCB | Mounting: Back | ||
| PYC-A1 | G3FM Hold-down Clip (front, set of 2) | OMRON | Type: G3FM Accessory | Description: Hold-down Clip (front, set of 2) | ||
| PYC-P | G3FM Hold-down Clip (back PCB) | OMRON | Type: G3FM Accessory | Description: Hold-down Clip (back PCB) | ||
| PYCZ-C08 | G3FM Terminal Cover for PYFZ-08 (2 pcs/set) | OMRON | Type: G3FM Accessory | Description: Terminal Cover for PYFZ-08 (2 pcs/set) | ||
| PFP-100N | G3FM DIN Track 1m | OMRON | Type: G3FM Accessory | Description: DIN Track 1m | ||
| PFP-50N | G3FM DIN Track 0.5m | OMRON | Type: G3FM Accessory | Description: DIN Track 0.5m | ||
| PFP-100N2 | G3FM DIN Track Deep 1m | OMRON | Type: G3FM Accessory | Description: DIN Track Deep 1m | ||
| PFP-M | G3FM End Plate | OMRON | Type: G3FM Accessory | Description: End Plate | ||
| PFP-S | G3FM Spacer | OMRON | Type: G3FM Accessory | Description: Spacer |
