[OMRON] — K2CM Motor Protective Relay (Voltage Reverse-phase, Instantaneous, 8~160A, 200~240VAC)
Monitoring Relays Omron

[OMRON] — K2CM Motor Protective Relay (Voltage Reverse-phase, Instantaneous, 8~160A, 200~240VAC)

Family ID: OMRON-K2CM-V-INST

Solid-state Relay Enables Choice of Three Operating Functions (Overcurrent, Openphase, and Reverse-phase)

6 product codes available in this family

RFQ Cart (0)

Product Codes & Specifications

Product Code Description Brand Spec
K2CM-Q2LV K2CM Voltage Rev-phase Instantaneous 8~26A 200~240V Manual OMRON Type: Motor Protective Relay | Detection: Voltage reverse-phase | Trip Characteristic: Instantaneous | Current Range: 8~26A | Voltage: 200/220/240 VAC | Reset: Manual
K2CM-Q2MV K2CM Voltage Rev-phase Instantaneous 20~65A 200~240V Manual OMRON Type: Motor Protective Relay | Detection: Voltage reverse-phase | Trip Characteristic: Instantaneous | Current Range: 20~65A | Voltage: 200/220/240 VAC | Reset: Manual
K2CM-Q2HV K2CM Voltage Rev-phase Instantaneous 50~160A 200~240V Manual OMRON Type: Motor Protective Relay | Detection: Voltage reverse-phase | Trip Characteristic: Instantaneous | Current Range: 50~160A | Voltage: 200/220/240 VAC | Reset: Manual
K2CM-Q2LAV K2CM Voltage Rev-phase Instantaneous 8~26A 200~240V Automatic OMRON Type: Motor Protective Relay | Detection: Voltage reverse-phase | Trip Characteristic: Instantaneous | Current Range: 8~26A | Voltage: 200/220/240 VAC | Reset: Automatic
K2CM-Q2MAV K2CM Voltage Rev-phase Instantaneous 20~65A 200~240V Automatic OMRON Type: Motor Protective Relay | Detection: Voltage reverse-phase | Trip Characteristic: Instantaneous | Current Range: 20~65A | Voltage: 200/220/240 VAC | Reset: Automatic
K2CM-Q2HAV K2CM Voltage Rev-phase Instantaneous 50~160A 200~240V Automatic OMRON Type: Motor Protective Relay | Detection: Voltage reverse-phase | Trip Characteristic: Instantaneous | Current Range: 50~160A | Voltage: 200/220/240 VAC | Reset: Automatic
