![[OMRON] — S8VK-WB Switch Mode Power Supply (240~960W, 3-phase/2-phase 380~480VAC, 24V/48VDC, Push-In Plus)](https://img.prosourcemro.com/2026/05/001-659-1024x684.png)
Power Supplies
Omron
[OMRON] — S8VK-WB Switch Mode Power Supply (240~960W, 3-phase/2-phase 380~480VAC, 24V/48VDC, Push-In Plus)
Family ID: OMRON-S8VK-WB
Even more compact three-phase 380 to 480V input power supplies. Reduces wiring work with the Push-In Plus terminals. 24VDC and 48VDC output line-up. 240W/480W/960W variants. Three-phase/two-phase 380~480VAC input (320~576VAC allowable). Boost current support.
6 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| S8VK-WB24024 | 240W, 3-phase/2-phase 380~480VAC, 24VDC 10A (boost 15A) | OMRON | Type: Switch Mode Power Supply | Capacity: 240W | Input: Three-phase/Two-phase 380~480VAC (320~576VAC) / 450~810VDC | Output: 24VDC 10A | Boost Current: 15A | Terminal: Push-In Plus | ||
| S8VK-WB24048 | 240W, 3-phase/2-phase 380~480VAC, 48VDC 5A (boost 7.5A) | OMRON | Type: Switch Mode Power Supply | Capacity: 240W | Input: Three-phase/Two-phase 380~480VAC (320~576VAC) / 450~810VDC | Output: 48VDC 5A | Boost Current: 7.5A | Terminal: Push-In Plus | ||
| S8VK-WB48024 | 480W, 3-phase/2-phase 380~480VAC, 24VDC 20A (boost 30A) | OMRON | Type: Switch Mode Power Supply | Capacity: 480W | Input: Three-phase/Two-phase 380~480VAC (320~576VAC) / 450~810VDC | Output: 24VDC 20A | Boost Current: 30A | Terminal: Push-In Plus | ||
| S8VK-WB48048 | 480W, 3-phase/2-phase 380~480VAC, 48VDC 10A (boost 15A) | OMRON | Type: Switch Mode Power Supply | Capacity: 480W | Input: Three-phase/Two-phase 380~480VAC (320~576VAC) / 450~810VDC | Output: 48VDC 10A | Boost Current: 15A | Terminal: Push-In Plus | ||
| S8VK-WB96024 | 960W, 3-phase/2-phase 380~480VAC, 24VDC 40A (boost 60A) | OMRON | Type: Switch Mode Power Supply | Capacity: 960W | Input: Three-phase/Two-phase 380~480VAC (320~576VAC) / 450~810VDC | Output: 24VDC 40A | Boost Current: 60A | Terminal: Push-In Plus | ||
| S8VK-WB96048 | 960W, 3-phase/2-phase 380~480VAC, 48VDC 20A (boost 30A) | OMRON | Type: Switch Mode Power Supply | Capacity: 960W | Input: Three-phase/Two-phase 380~480VAC (320~576VAC) / 450~810VDC | Output: 48VDC 20A | Boost Current: 30A | Terminal: Push-In Plus |
