[OMRON] — TL-W Flat Inductive Proximity Sensor (Unshielded/Shielded, DC 2-Wire/3-Wire)
Family ID: OMRON-TL-W
OMRON TL-W Series standard flat inductive proximity sensor. Unshielded: DC 2-wire 5mm (NO/NC), DC 3-wire NPN/PNP 1.5mm/3mm/5mm/20mm. Shielded: DC 3-wire NPN/PNP 5mm. Pre-wired 2m. Frequency variant models available (add '5' before output code, e.g. TL-W5MD15).
18 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| TL-W5MD1 2M | TL-W Unshielded 5 mm DC 2-wire --- NO 2m | OMRON | Shield: Unshielded | Sensing Distance: 5 mm | Wire: DC 2-wire | Output: --- | Operation Mode: NO | Connection: Pre-wired 2 m | Note: Frequency variant available (e.g. TL-W5MD15 2M) | ||
| TL-W5MD2 2M | TL-W Unshielded 5 mm DC 2-wire --- NC 2m | OMRON | Shield: Unshielded | Sensing Distance: 5 mm | Wire: DC 2-wire | Output: --- | Operation Mode: NC | Connection: Pre-wired 2 m | Note: Frequency variant available (e.g. TL-W5MD15 2M) | ||
| TL-W1R5MC1 2M | TL-W Unshielded 1.5 mm DC 3-wire NPN NO 2m | OMRON | Shield: Unshielded | Sensing Distance: 1.5 mm | Wire: DC 3-wire | Output: NPN | Operation Mode: NO | Connection: Pre-wired 2 m | Note: Frequency variant available (e.g. TL-W5MD15 2M) | ||
| TL-W1R5MB1 2M | TL-W Unshielded 1.5 mm DC 3-wire PNP NO 2m | OMRON | Shield: Unshielded | Sensing Distance: 1.5 mm | Wire: DC 3-wire | Output: PNP | Operation Mode: NO | Connection: Pre-wired 2 m | Note: Frequency variant available (e.g. TL-W5MD15 2M) | ||
| TL-W3MC1 2M | TL-W Unshielded 3 mm DC 3-wire NPN NO 2m | OMRON | Shield: Unshielded | Sensing Distance: 3 mm | Wire: DC 3-wire | Output: NPN | Operation Mode: NO | Connection: Pre-wired 2 m | Note: Frequency variant available (e.g. TL-W5MD15 2M) | ||
| TL-W3MC2 2M | TL-W Unshielded 3 mm DC 3-wire NPN NC 2m | OMRON | Shield: Unshielded | Sensing Distance: 3 mm | Wire: DC 3-wire | Output: NPN | Operation Mode: NC | Connection: Pre-wired 2 m | Note: Frequency variant available (e.g. TL-W5MD15 2M) | ||
| TL-W3MB1 2M | TL-W Unshielded 3 mm DC 3-wire PNP NO 2m | OMRON | Shield: Unshielded | Sensing Distance: 3 mm | Wire: DC 3-wire | Output: PNP | Operation Mode: NO | Connection: Pre-wired 2 m | Note: Frequency variant available (e.g. TL-W5MD15 2M) | ||
| TL-W3MB2 2M | TL-W Unshielded 3 mm DC 3-wire PNP NC 2m | OMRON | Shield: Unshielded | Sensing Distance: 3 mm | Wire: DC 3-wire | Output: PNP | Operation Mode: NC | Connection: Pre-wired 2 m | Note: Frequency variant available (e.g. TL-W5MD15 2M) | ||
| TL-W5MC1 2M | TL-W Unshielded 5 mm DC 3-wire NPN NO 2m | OMRON | Shield: Unshielded | Sensing Distance: 5 mm | Wire: DC 3-wire | Output: NPN | Operation Mode: NO | Connection: Pre-wired 2 m | Note: Frequency variant available (e.g. TL-W5MD15 2M) | ||
| TL-W5MC2 2M | TL-W Unshielded 5 mm DC 3-wire NPN NC 2m | OMRON | Shield: Unshielded | Sensing Distance: 5 mm | Wire: DC 3-wire | Output: NPN | Operation Mode: NC | Connection: Pre-wired 2 m | Note: Frequency variant available (e.g. TL-W5MD15 2M) | ||
| TL-W5MB1 2M | TL-W Unshielded 5 mm DC 3-wire PNP NO 2m | OMRON | Shield: Unshielded | Sensing Distance: 5 mm | Wire: DC 3-wire | Output: PNP | Operation Mode: NO | Connection: Pre-wired 2 m | Note: Frequency variant available (e.g. TL-W5MD15 2M) | ||
| TL-W5MB2 2M | TL-W Unshielded 5 mm DC 3-wire PNP NC 2m | OMRON | Shield: Unshielded | Sensing Distance: 5 mm | Wire: DC 3-wire | Output: PNP | Operation Mode: NC | Connection: Pre-wired 2 m | Note: Frequency variant available (e.g. TL-W5MD15 2M) | ||
| TL-W20ME1 2M | TL-W Unshielded 20 mm DC 3-wire NPN NO 2m | OMRON | Shield: Unshielded | Sensing Distance: 20 mm | Wire: DC 3-wire | Output: NPN | Operation Mode: NO | Connection: Pre-wired 2 m | Note: Frequency variant available (e.g. TL-W5MD15 2M) | ||
| TL-W20ME2 2M | TL-W Unshielded 20 mm DC 3-wire NPN NC 2m | OMRON | Shield: Unshielded | Sensing Distance: 20 mm | Wire: DC 3-wire | Output: NPN | Operation Mode: NC | Connection: Pre-wired 2 m | Note: Frequency variant available (e.g. TL-W5MD15 2M) | ||
| TL-W5E1 2M | TL-W Shielded 5 mm DC 3-wire NPN NO 2m | OMRON | Shield: Shielded | Sensing Distance: 5 mm | Wire: DC 3-wire | Output: NPN | Operation Mode: NO | Connection: Pre-wired 2 m | Note: Frequency variant available (e.g. TL-W5MD15 2M) | ||
| TL-W5E2 2M | TL-W Shielded 5 mm DC 3-wire NPN NC 2m | OMRON | Shield: Shielded | Sensing Distance: 5 mm | Wire: DC 3-wire | Output: NPN | Operation Mode: NC | Connection: Pre-wired 2 m | Note: Frequency variant available (e.g. TL-W5MD15 2M) | ||
| TL-W5F1 2M | TL-W Shielded 5 mm DC 3-wire PNP NO 2m | OMRON | Shield: Shielded | Sensing Distance: 5 mm | Wire: DC 3-wire | Output: PNP | Operation Mode: NO | Connection: Pre-wired 2 m | Note: Frequency variant available (e.g. TL-W5MD15 2M) | ||
| TL-W5F2 2M | TL-W Shielded 5 mm DC 3-wire PNP NC 2m | OMRON | Shield: Shielded | Sensing Distance: 5 mm | Wire: DC 3-wire | Output: PNP | Operation Mode: NC | Connection: Pre-wired 2 m | Note: Frequency variant available (e.g. TL-W5MD15 2M) |
