[OMRON] — ZW-SQ Series Confocal Fiber Displacement Sensor Head (Square Right-angle, Ultra-compact)
Family ID: OMRON-ZW-SQ-RANGLE
OMRON ZW-SQ Series ultra-compact square right-angle confocal fiber displacement sensor heads. Compatible with ZW-5000T controller. Static resolution 0.25 μm. ZW-SQR5007 (18μm spot), ZW-SQR5020 (40μm), ZW-SQR5040 (80μm). Cable 2 m and 0.3 m. Extension fiber cables ZW-XF50xxR sold separately.
6 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| ZW-SQR5007 2M | ZW-SQ square right-angle 18 μm dia. 2m | OMRON | Shape: Square right-angle | Spot Diameter: 18 μm dia. | Measuring Range: Refer to datasheet | Required Controller: ZW-5000T (EtherCAT, 24VDC, NPN/PNP) | Static Resolution: 0.25 μm (with ZW-5000T) | Extension Cable: ZW-XF5002R~30R (sold separately, Fiber Adapter ZW-XFC2 included) | Note: Ultra-compact and ultra-lightweight design | Cable Length: 2 m | ||
| ZW-SQR5007 0.3M | ZW-SQ square right-angle 18 μm dia. 0.3m | OMRON | Shape: Square right-angle | Spot Diameter: 18 μm dia. | Measuring Range: Refer to datasheet | Required Controller: ZW-5000T (EtherCAT, 24VDC, NPN/PNP) | Static Resolution: 0.25 μm (with ZW-5000T) | Extension Cable: ZW-XF5002R~30R (sold separately, Fiber Adapter ZW-XFC2 included) | Note: Ultra-compact and ultra-lightweight design | Cable Length: 0.3 m | ||
| ZW-SQR5020 2M | ZW-SQ square right-angle 40 μm dia. 2m | OMRON | Shape: Square right-angle | Spot Diameter: 40 μm dia. | Measuring Range: Refer to datasheet | Required Controller: ZW-5000T (EtherCAT, 24VDC, NPN/PNP) | Static Resolution: 0.25 μm (with ZW-5000T) | Extension Cable: ZW-XF5002R~30R (sold separately, Fiber Adapter ZW-XFC2 included) | Note: Ultra-compact and ultra-lightweight design | Cable Length: 2 m | ||
| ZW-SQR5020 0.3M | ZW-SQ square right-angle 40 μm dia. 0.3m | OMRON | Shape: Square right-angle | Spot Diameter: 40 μm dia. | Measuring Range: Refer to datasheet | Required Controller: ZW-5000T (EtherCAT, 24VDC, NPN/PNP) | Static Resolution: 0.25 μm (with ZW-5000T) | Extension Cable: ZW-XF5002R~30R (sold separately, Fiber Adapter ZW-XFC2 included) | Note: Ultra-compact and ultra-lightweight design | Cable Length: 0.3 m | ||
| ZW-SQR5040 2M | ZW-SQ square right-angle 80 μm dia. 2m | OMRON | Shape: Square right-angle | Spot Diameter: 80 μm dia. | Measuring Range: Refer to datasheet | Required Controller: ZW-5000T (EtherCAT, 24VDC, NPN/PNP) | Static Resolution: 0.25 μm (with ZW-5000T) | Extension Cable: ZW-XF5002R~30R (sold separately, Fiber Adapter ZW-XFC2 included) | Note: Ultra-compact and ultra-lightweight design | Cable Length: 2 m | ||
| ZW-SQR5040 0.3M | ZW-SQ square right-angle 80 μm dia. 0.3m | OMRON | Shape: Square right-angle | Spot Diameter: 80 μm dia. | Measuring Range: Refer to datasheet | Required Controller: ZW-5000T (EtherCAT, 24VDC, NPN/PNP) | Static Resolution: 0.25 μm (with ZW-5000T) | Extension Cable: ZW-XF5002R~30R (sold separately, Fiber Adapter ZW-XFC2 included) | Note: Ultra-compact and ultra-lightweight design | Cable Length: 0.3 m |
