[Yuken] — AMC-T-20 Multifunction Slope Controller
Family ID: YK-AMC-T-20
Yuken multifunction slope controller that outputs arbitrary 2-channel analog voltage patterns and supports both slope-constant and time-constant ramping. The two channels can be used independently and can also serve as a setter for 04E-control variable piston pumps. Output channels 2 (A, B); output range 0–+5 V / 0–±5 V / 0–+10 V / 0–±10 V (DIP-selectable); slope shapes 4 (1 linear + 3 curves, DIP-selectable); max slope time 5/20/50/100 s; setting resolution 0.1% over 0–±99.9%. Control modes: mode 1 (4-bit binary, 15 patterns) with stop mode, mode 2 (6-bit binary, 63 patterns), mode 3 (timer, 9 patterns × 4). Control input: current 10 mA/bit or voltage DC8–48 V photo-coupler isolated; output: transistor open collector max 30 V/50 mA. Settings stored in EEP-ROM (no battery). Common AC100/200V (85–260 V) 50/60 Hz, 10 VA, mass 1 kg.
1 product code available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| AMC-T-20 | Yuken AMC-T-20 multifunction 2-channel slope controller | Yuken | Type: Multifunction slope controller | Brand: Yuken | Model: AMC-T-20 | Output Channels: 2 (A, B) | Output Voltage Range: 0–+5 / 0–±5 / 0–+10 / 0–±10 V (DIP) | Slope Mode: slope-constant or time-constant (DIP) | Slope Shapes: 4 (1 linear + 3 curves, DIP) | Max Slope Time: 5 / 20 / 50 / 100 s (DIP) | Setting Resolution: 0.1% over 0–±99.9% | Control Modes: mode1 4-bit (15 patterns, stop mode) / mode2 6-bit (63 patterns) / mode3 timer (9×4) | Control Input: current 10 mA/bit or voltage DC8–48 V (photo-coupler isolated) | Control Output: transistor open collector max 30 V/50 mA | Data Storage: EEP-ROM (no battery) | Power Supply: AC100/200V common (85–260 V) 50/60 Hz | Power Consumption: 10 VA | Mass: 1 kg | Also usable as: setter for 04E-control variable piston pumps | Design No.: 20 |
