[Yuken] — AMN-T-10 Compact Slope Controller
Family ID: YK-AMN-T-10
Yuken compact, lightweight slope controller — about 1/5 the weight and 1/4 the volume of the earlier slope controller, with one-touch (plug-in) wiring. A 4-bit switching signal selects arbitrary level and acceleration/deceleration-time output patterns. Output channels 1; output voltage range 0–+5 V (factory), 0–+10 V, ±5 V, ±10 V; max slope time 1–9999 s (slope-constant or time-constant, 1 s steps); slope shapes 1 linear + 3 curves; setting resolution 0.1% over 0–±99.9%; 4-bit binary input giving 15 output patterns. Sequence input 10 mA/24 V (10–28 V range), sequence output 50 mA / 32 V. Supply DC24V (20–30 V incl. ripple), 3 W, mass 0.2 kg.
1 product code available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| AMN-T-10 | Yuken AMN-T-10 compact 1-channel slope controller | Yuken | Type: Compact slope controller | Brand: Yuken | Model: AMN-T-10 | Output Channels: 1 | Output Voltage Range: 0–+5 / 0–+10 / ±5 / ±10 V | Max Slope Time: 1–9999 s (slope- or time-constant, 1 s steps) | Slope Shapes: 1 linear + 3 curves | Setting Resolution: 0.1% over 0–±99.9% | Output Patterns: 4-bit binary input → 15 patterns | Sequence Input: 10 mA/24 V (10–28 V range) | Sequence Output: 50 mA / 32 V max | Power Supply: DC24V (20–30 V incl. ripple) | Power Consumption: 3 W | Mass: 0.2 kg | Features: 1/5 weight & 1/4 volume vs previous, one-touch wiring | Design No.: 10 |
