[Yuken] — AR Series Variable Displacement Piston Pump (Pressure Compensator, 15.8 / 22.2 cm3/rev)
Piston Pumps Yuken

[Yuken] — AR Series Variable Displacement Piston Pump (Pressure Compensator, 15.8 / 22.2 cm3/rev)

Family ID: YUKEN-AR

"AR" Series Variable Displacement Piston Pumps - Single Pump, Pressure Compensator Type.

8 product codes available in this family

RFQ Cart (0)

Product Codes & Specifications

Product Code Description Brand Spec
AR16-FR01B-22 Yuken AR16 (15.8 cm3/rev), Flange mount, Axial port, pressure range B (1.2-7 MPa) Yuken Series: AR | Frame: AR16 | Geometric Displacement: 15.8 cm3/rev | Min. Adjustment Flow: 6.0 cm3/rev | Mounting: Flange | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: Pressure Compensator | Pressure Adjustment Range: 1.2-7 MPa | Port Position: Axial port | Design Number: 22 | Rated Pressure: 16 MPa | Allowable Speed: 600-1800 r/min | Mass: 11.8 kg | Port Connections: Suction S dia.19 (flange), Delivery P Rc3/4, Drain DR Rc3/8, Gauge PG Rc1/4
AR16-FR01BS-22 Yuken AR16 (15.8 cm3/rev), Flange mount, Side port, pressure range B (1.2-7 MPa) Yuken Series: AR | Frame: AR16 | Geometric Displacement: 15.8 cm3/rev | Min. Adjustment Flow: 6.0 cm3/rev | Mounting: Flange | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: Pressure Compensator | Pressure Adjustment Range: 1.2-7 MPa | Port Position: Side port | Design Number: 22 | Rated Pressure: 16 MPa | Allowable Speed: 600-1800 r/min | Mass: 11.8 kg | Port Connections: Suction S dia.19 (flange), Delivery P Rc3/4, Drain DR Rc3/8, Gauge PG Rc1/4
AR16-FR01C-22 Yuken AR16 (15.8 cm3/rev), Flange mount, Axial port, pressure range C (2.0-16 MPa) Yuken Series: AR | Frame: AR16 | Geometric Displacement: 15.8 cm3/rev | Min. Adjustment Flow: 6.0 cm3/rev | Mounting: Flange | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: Pressure Compensator | Pressure Adjustment Range: 2.0-16 MPa | Port Position: Axial port | Design Number: 22 | Rated Pressure: 16 MPa | Allowable Speed: 600-1800 r/min | Mass: 11.8 kg | Port Connections: Suction S dia.19 (flange), Delivery P Rc3/4, Drain DR Rc3/8, Gauge PG Rc1/4
AR16-FR01CS-22 Yuken AR16 (15.8 cm3/rev), Flange mount, Side port, pressure range C (2.0-16 MPa) Yuken Series: AR | Frame: AR16 | Geometric Displacement: 15.8 cm3/rev | Min. Adjustment Flow: 6.0 cm3/rev | Mounting: Flange | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: Pressure Compensator | Pressure Adjustment Range: 2.0-16 MPa | Port Position: Side port | Design Number: 22 | Rated Pressure: 16 MPa | Allowable Speed: 600-1800 r/min | Mass: 11.8 kg | Port Connections: Suction S dia.19 (flange), Delivery P Rc3/4, Drain DR Rc3/8, Gauge PG Rc1/4
AR22-FR01B-22 Yuken AR22 (22.2 cm3/rev), Flange mount, Axial port, pressure range B (1.2-7 MPa) Yuken Series: AR | Frame: AR22 | Geometric Displacement: 22.2 cm3/rev | Min. Adjustment Flow: 8.5 cm3/rev | Mounting: Flange | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: Pressure Compensator | Pressure Adjustment Range: 1.2-7 MPa | Port Position: Axial port | Design Number: 22 | Rated Pressure: 16 MPa | Allowable Speed: 600-1800 r/min | Mass: 12.5 kg | Port Connections: Suction S dia.19 (flange), Delivery P Rc3/4, Drain DR Rc3/8, Gauge PG Rc1/4
AR22-FR01BS-22 Yuken AR22 (22.2 cm3/rev), Flange mount, Side port, pressure range B (1.2-7 MPa) Yuken Series: AR | Frame: AR22 | Geometric Displacement: 22.2 cm3/rev | Min. Adjustment Flow: 8.5 cm3/rev | Mounting: Flange | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: Pressure Compensator | Pressure Adjustment Range: 1.2-7 MPa | Port Position: Side port | Design Number: 22 | Rated Pressure: 16 MPa | Allowable Speed: 600-1800 r/min | Mass: 12.5 kg | Port Connections: Suction S dia.19 (flange), Delivery P Rc3/4, Drain DR Rc3/8, Gauge PG Rc1/4
AR22-FR01C-22 Yuken AR22 (22.2 cm3/rev), Flange mount, Axial port, pressure range C (2.0-16 MPa) Yuken Series: AR | Frame: AR22 | Geometric Displacement: 22.2 cm3/rev | Min. Adjustment Flow: 8.5 cm3/rev | Mounting: Flange | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: Pressure Compensator | Pressure Adjustment Range: 2.0-16 MPa | Port Position: Axial port | Design Number: 22 | Rated Pressure: 16 MPa | Allowable Speed: 600-1800 r/min | Mass: 12.5 kg | Port Connections: Suction S dia.19 (flange), Delivery P Rc3/4, Drain DR Rc3/8, Gauge PG Rc1/4
AR22-FR01CS-22 Yuken AR22 (22.2 cm3/rev), Flange mount, Side port, pressure range C (2.0-16 MPa) Yuken Series: AR | Frame: AR22 | Geometric Displacement: 22.2 cm3/rev | Min. Adjustment Flow: 8.5 cm3/rev | Mounting: Flange | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: Pressure Compensator | Pressure Adjustment Range: 2.0-16 MPa | Port Position: Side port | Design Number: 22 | Rated Pressure: 16 MPa | Allowable Speed: 600-1800 r/min | Mass: 12.5 kg | Port Connections: Suction S dia.19 (flange), Delivery P Rc3/4, Drain DR Rc3/8, Gauge PG Rc1/4
