Relief Valves
Yuken
[Yuken] — Relief Valve High Pressure (B3G-03/06)
Family ID: YUK-PC-RV-B3G
Relief Valves (High Pressure Type). Max. operating pressure: 35 MPa. Pressure adjustment range: to 35 MPa. Max. flow: 250 L/min (03) / 500 L/min (06). Sub-plate mounting. High-vent type (-V) available.
4 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| B3G-03-10 | High Pressure Relief Valve B3G-03, sub-plate | Yuken | Type: Relief Valve (High Pressure Type) | Mounting: Sub-plate | Valve Size: 03 | High-Vent Type: No | Max. Operating Pressure: 35 MPa | Pressure Adjustment Range: to 35 MPa | Max. Flow: 250 L/min | Mass: 4.1 kg | Design No.: 10 | ||
| B3G-03-V-10 | High Pressure Relief Valve B3G-03-V, sub-plate, high-vent | Yuken | Type: Relief Valve (High Pressure Type) | Mounting: Sub-plate | Valve Size: 03 | High-Vent Type: Yes (-V) | Max. Operating Pressure: 35 MPa | Pressure Adjustment Range: to 35 MPa | Max. Flow: 250 L/min | Mass: 4.1 kg | Design No.: 10 | ||
| B3G-06-10 | High Pressure Relief Valve B3G-06, sub-plate | Yuken | Type: Relief Valve (High Pressure Type) | Mounting: Sub-plate | Valve Size: 06 | High-Vent Type: No | Max. Operating Pressure: 35 MPa | Pressure Adjustment Range: to 35 MPa | Max. Flow: 500 L/min | Mass: 5.1 kg | Design No.: 10 | ||
| B3G-06-V-10 | High Pressure Relief Valve B3G-06-V, sub-plate, high-vent | Yuken | Type: Relief Valve (High Pressure Type) | Mounting: Sub-plate | Valve Size: 06 | High-Vent Type: Yes (-V) | Max. Operating Pressure: 35 MPa | Pressure Adjustment Range: to 35 MPa | Max. Flow: 500 L/min | Mass: 5.1 kg | Design No.: 10 |
